- Page 1 Network Switch Set-up Guide Luxul AMS & XMS Series when used with a 1Gb RTI VIP distribution system (single switch system configuration) Revision: 1.1 - Feb 2021...
-
Page 2: Table Of Contents
SWITCH SET UP GUIDE LUXUL AMS / XMS Contents Introduction Switch Requirements Network Topology for VIP Connecting to the Web GUI Interface Maximum Frame Size IGMP Snooping 06-07 Turning On/Off PoE Apply and Save Settings Changing Your Computer IP Address 10-12 www.rticorp.com... -
Page 3: Introduction
LUXUL AMS / XMS Introduction The 1Gb RTI VIP solutions require a 1Gb managed network switch in order for HDMI distribution to be achieved reliably, and without any loss of performance. The following guide is a step-by-step instruction on how to connect and configure your network switch to support 1Gb VIP-UHD products. -
Page 4: Connecting To The Web Gui Interface
SWITCH SET UP GUIDE LUXUL AMS / XMS Connecting to the Web GUI Interface To login into the Luxul network switch the factory default details are: IP Address: 192.168.0.4 User: admin Password: admin In order to connect to the network switch your computer will need to be physically connected to the Luxul switch using an Ethernet network cable. -
Page 5: Maximum Frame Size
SWITCH SET UP GUIDE LUXUL AMS / XMS Maximum Frame Size To increase the maximum frame size, Within the ‘Configuration’ menu Select ‘Ports’ Select ‘Ports’ Ensure ‘Maximum Frame Size’ is set to 9600 for all ports. Click ‘SAVE’ at the bottom of the page to update the setting Technical Support: Support@rticorp.com | Customer Service:... -
Page 6: Igmp Snooping
SWITCH SET UP GUIDE LUXUL AMS / XMS IGMP Snooping To enable IGMP snooping, there are several steps required to enable this feature: • IGMP Snooping • IPMCv4 Flooding • Fast Leave • IGMP Querier Status • IGMP Querier Election The following pages explain how to update the above settings IGMP Snooping Under ‘Configuration’... - Page 7 SWITCH SET UP GUIDE LUXUL AMS / XMS IGMP Snooping VLAN Configuration Under ‘Configuration’ menu Select ‘IPMC’ Select ‘IGMP Snooping’ Select ‘VLAN Configuration’ Tick ‘Snooping Enabled’ Untick ‘Querier Election’ Change ‘Compatibility’ to Forced IGMPv2 Confirm other settings match those as shown in the above image Click ‘SAVE’...
-
Page 8: Turning On/Off Poe
SWITCH SET UP GUIDE LUXUL AMS / XMS Turning On/Off PoE Not all Luxul AMS switches support PoE. Furthermore, not all ports on the PoE switches support PoE. Please ensure your products are connected to the correct port. If you are unsure of the PoE port setting please follow the below instructions. Under ‘Configuration’... -
Page 9: Apply And Save Settings
To reboot the switch: Under ‘Administration’ menu Select ‘Reboot’’ Click ‘Yes’ to reboot the switch Please note: The switch may take several minutes to reboot but will then be ready to use with the RTI VIP-UHD products Technical Support: Support@rticorp.com | Customer Service:... -
Page 10: Changing Your Computer Ip Address
SWITCH SET UP GUIDE LUXUL AMS / XMS Amending your IP Address in Windows 1. Connect the computer to the network switch using an Ethernet cable 2. Navigate to: CONTROL PANEL / NETWORK & INTERNET / NETWORK CONNECTIONS 3. Double click on the Ethernet connection as highlighted below: 4. - Page 11 SWITCH SET UP GUIDE LUXUL AMS / XMS 5. In the pop-up window that appears, double-click on: INTERNET PROTOCOL VERSION 4 (TCP/IPv4) 5. In the pop-up window that appears, double-click on the button marked: USE THE FOLLOWING IP ADDRESS 6. Enter the details as below: IP Address: 192.168.0.1 Subnet mask: 255.255.255.0 Default gateway: Leave this field blank...
- Page 12 SWITCH SET UP GUIDE LUXUL AMS / XMS Amending your IP Address in Mac OS 1. Connect the Mac to the network switch using an Ethernet cable 2. Click on the Network Connections icon in the toolbar at the top of the desktop 3.
- Page 13 SWITCH SET UP GUIDE LUXUL AMS / XMS 4. Find the active Ethernet connection to the network switch on the left-hand menu tree 5. Use the drop-down box marked: CONFIGURE IPv4 and set to: MANUALLY 6. Enter the details as below: IP Address: 192.168.0.1 Subnet mask: 255.255.255.0 Router: Leave this field blank...
- Page 14 www.rticorp.com...
