Techly LUMINOUS ICE BUCKET Manual

EN
1. INTRODUCTION
Dear Customers,
Thank you for choosing a Techly product. This user's manual provides information for
following Luminous Ice Bucket.
Carefully read all instructions before using and keep this user's manual for future
consultations.
2. WARNINGS AND CAUTIONS
• The charger and remote control are not waterproof and must be kept in a dry location
at all times.
• Never charge the product into water or under the rain; charge in a dry, indoor location.
• Disconnect the charger from main power when not in use.
• Do not stand or jump on this product.
• Do not sit on this product if it is cracked or damaged.
• Keep the product away from chemicals and heat.
• Do not attempt to open the product to avoid the risk of electric shock, opening the
product could cause the loss of closely sealed; opening the product would void the
warranty.
• For charging use only the cable supplied into the package.
• Avoid prolonged stay in the water or in full sun.
3. SPECIFICATION
Water resistance of LED lights
Light battery
Remote control distance
Remote control battery
Ambient temperature for operation
Charging time
Battery autonomy
4. OPERATIONS
Charge the lamp
• Before first use, charge the battery for 5-6 hours.
• Place the lamp on a level surface.
• Use clean and dry cloth to clean the socket of the lamp
• Open the socket cover and insert one adaptor DC5V 1A plug into the socket.
• Connect the external adapter to the electrical outlet
• It will begin to charge and indicator light on the item will change to red.
• Indicator light turns off when the battery is fully charged.
• After charging, disconnect the external adapter from electrical outlet and remove the
lamp from the socket.
5. POWER THE LIGHT ON/OFF
To power on the lamp, you can press ON/OFF the button on the bottom of the lamp or press
the ON button on remote control.
To power off the lamp, you can either press the ON/OFF button or press the OFF button
on remote control.
Change the color by shortly push the ON/OFF or by operating the remote control. See below
instruction of remote control.
WWW.TECHLY.COM
6. MODE SELECTION BY REMOTE CONTROL
Note: first remove the small plastic sheet from the battery cover before below operation.
5
Brightness plus
1
2 Brightness decrease
3 Lamp turn OFF
4 Lamp turn ON
5 Color fixing
7. BATTERY REPLACEMENT (REMOTE CONTROL)
• If the remote control doesn't work, replace the battery (CR2025).
IP54
• Press the tab on the side of battery cover and slide it off.
Lithium 3,7V/2000 mAh
• IMPORTANT! Note polarity (+/-) on the cover when installing battery
• Remove battery if remote will not be used for an extended time period
4m (13feet)
• KEEP BATTERIES OUT OF REACH OF CHILDREN
CR2025 (3V)
• Swallowing may lead to serious injury, due to chemical burns and potential perforation
of the esophagus.
14°C-35°C
• If you suspect your child has swallowed or inserted a button battery, immediately seek
5-6 h
urgent medical assistance.
8 h
• Examine devices and make sure the battery compartment is correctly secured, e.g. that
the screw or other mechanical fastener is tightened. Do not use if compartment is not
secure.
8. MAINTENANCE FOR PRODUCT AND ACCESSORIES
• Always POWER OFF the light after use.
• Use clean water to rinse the light after use, and dry with clean cloth.
• Store the light out of reach of children and direct sunlight.
contaminative and hazardous substances can pollute the environment.
LUMINOUS ICE BUCKET
1 2 3
OFF
G B
R
Flash mode: lamp flashing
6
7 Strobe mode: disco effect
Fade mode: color fades off into
8
another color
Smooth mode: color changing
9
smoothly
In compliance with EU Directive WEEE this product is marked with this
symbol. It means that used electrical and electronic products should not
be mixed with general household waste. There is a separate collections
system for these products in compliance with WEEE directive, otherwise
With the CE sign, Techly ensures that the product is conformed to the basic
®
European standards and directives.
4
ON
W
6
FLASH
7
STROBE
8
FADE
9
SMOOTH
