Summary of Contents for Vision REVO-2.5

  • Page 1 Neil V1.0 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 2: Term Definition

    Over One Hour Backup Time Solution for Three-phase UPS SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 3: Table Of Contents

    4.1 Module description ..........................20 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 4 10.1 Connection overview ........................52 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 5 12.1 HMI monitoring ..........................99 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 6 14.4 About storage ..........................106 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 7: Overview

    1 Overview Range of application This Manual introduces VISION REVO series product, its installation, operation and other relevant aspects. VISION REVO system developed by SHENZHEN CENTER POWER TECH.CO., LTD. is suitable for high-voltage lithium battery system, and widely used in UPS backup power, large energy storage and other applications.

  • Page 8: Product Description

    SHENZHEN CENTER POWER TECH.CO., LTD. 2.2 Solution introduction REVO series uses VISION high-rate LFP batteries and self-developed BMS system, integrated remote cloud management system and intelligent fire protection module, with high reliability, good stability, long service life and excellent safety performance.
  • Page 9 12 * 200AH modules cabinet SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 10: Safety Instruction

    Emphasis and supplement: a quick way to master this step SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 11: Installation Tools

    ESD wrist strap SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 12: Attention Items

    REVO series back panels and front doors are equipped with nameplates that SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 13: Safety Warning Label

    UPS is completely disconnected. SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 14: Electric Measurement

    Insulate the possible electric part of REVO with insulation materials. Insulate SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 15: Safety Notice

    Failure to follow these instructions will result in death or serious injury. DANGER SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 16 Failure to follow these instructions will result in death or serious injury DANGER SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 17 Failure to follow these instructions will result in death or serious injury DANGER SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 18 Failure to follow these instructions will result in death or serious injury. SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 19 NOTICE consequence. If the UPS system remain DE-energized for a long period, VISION recommends to shut down the batteries cabinet completely. Failure to follow these instructions can result in equipment damage.

  • Page 20: Module

    4 Module 4.1 Module description VISION REVO TP series back up batteries adopt the high capacity, high safety LFP battery pack integration in the industry. Modules are structured in TP series, TPH series, and TPL series. Within the module, integrated high-precision BMU units monitor and...

  • Page 21: Cbms

    SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 22: Cbms Specification

    Weight with Package:kgs 29.5 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 23: Cbms Function Panel

    Figure 5.3.1 CBMS define mark LIBVISSG630IEC SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 24 Interface for communication with battery Communication SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 25: Led Indicator Status And Definition

    ● Protect SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 26: Breaker

    Figure 5.5.1 MCB ON SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 27 5 minutes after the circuit breaker trips. SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 28: Battery System Safety Monitoring Module

    SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 29: Gbms Specification

    Unit of measurement: mm SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 30: Gbms Function Panel And Definition

    Table 6.2.2 GBMS panel function definition description SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 31 GBMS running data store 10000 records SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 32: Cabinet

    165kg 193kg SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 33: Communication

    SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 34: System Installation

    REVO lithium battery system has passed the strict and comprehensive testing and quality examination before being put into use. Please make a detailed inspection of the products before accepting the goods. If anything is damaged, please contact Vision and provide details. Suggestions for inspection are as follows: Please check whether the package is intact.
  • Page 35 Step 3: Remove the cover of top SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 36 Remove the carton SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 37 Use a forklift to unload the cabinet to the installation site SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 38 Step 5: Move the module to the designated installation location SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 39 Step 6: Disassemble the module packaging SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 40 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 41 Step 7: Use a lift truck or at least two people to move the module to the cabinet for installation SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 42: Loading List

    Step 2：Remove the upper cover plate and side plate in turn 9.2 Loading list Table 9.2.1 Loading list Item Name Description Ref. LIBVISRAC50AH2000 qty：1 Vision 2000mm LIB rack with 8 x LIBVIS8×50250IEC 50Ah battery modules and 250A LIBVISMOD50 qty：8 CBMS IEC LIBVISSG250IEC qty ：1 LIBVISRAC50AH2000 qty：1 LIBVIS10×50250IEC 10 * 50AH modules cabinet LIBVISMOD50 qty：10...

  • Page 43: Mechanical Installation

    SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 44 Top routing without junction box SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 45 Picture 9.31.2Fixed foot installation SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 46 Step 2: Screw and nut specifications SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 47 Step 4: three installation positions that need to be fixed SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 48 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 49: L-Shaped Rails Disassembly

    CBMS. SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 50 Use a cross screwdriver to loosen the screws and remove the L-shaped shelf SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 51: Module Detection Before Installed

    52.5~53.2V 52.5~53.2V SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 52: Cable Connection

    The battery module terminal figure as below： SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 53: Ground Connection

    Ground(PE) connect SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 54 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 55: Module Installation

    50Ah 8modules SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 56 step2 fix the modules with screws provided, 4pcs M6 each module, torque 7Nm SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 57: Gbms Installation

    Install the GBMS fixing parts with screws SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 58: Interconnection Inside The Cabinet

    The standard torque is 30NM （M10）. SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 59 2.B+ Connection steps SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 60: Connect The B- Power Cable

    1.Fix the cable and adapter to the negative terminal of N/2 +1 with M10 screws SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 61 3.Lock the insulation cover of the adapter with M5 screws SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 62 50Ah 8modules SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 63: Module Communication Cable Connection

    SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 64 Step 2 module to module SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 65 Step 1: Open the cable trough onsite and determine the position of the cable outlet hole. SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 66 Step 3: Connect the output power cable SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 67: Gbms 24V Power Connection

    SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 68 GBMS 24VDC input SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 69: Cbms Parallel Communication Connect

    The figure below is the schematic diagram of REVO series for parallels. The system SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 70 hole details SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 71  Cable routing SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 72 CBMS and GBMS is ON SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 73: Ac Power Connection

    CBMS) SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 74 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 75: Set The Dial Switch

    SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 76 ID：2 ID：3 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 77 CBMS DIP switch setting for single cabinet & parallel cabinets SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 78: Can/Rs485 With Ups

    SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 79: Dry Contact Connection

    If you have special needs, please contact us. SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 80: Gbms Dip Switch Setting

    GBMS DIP switch setting for single cabinet & parallel for Cabinets. SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 81 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 82 Figure for connect for parallels SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 83: Ups Parameter Setting

    Qty in cabinets SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 84: Running Test

    SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 85 Is it determined that it is the cell voltage/temperature/communication failure/CBMS parameter? SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 86 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 87 Step 5: When the self-test is successful, a sound will appear, and the indicator light will turn SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 88 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 89 Proceed to step 6. SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 90 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 91 Proceed to step 6. SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 92 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 93: Troubleshooting

    SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 94 Low temperature Module temperature is below the check the protection parameters setting through LCD or VISION APP. When charging minimum charging temperature. the temperature rises to the reasonable value, the battery will be recharged.
  • Page 95 Check the minimum setting protection voltage of cell, and check the The voltage is cell is below the protection parameters setting through LCD or VISION APP. If it is confirmed Under voltage of cell minimum setting voltage.
  • Page 96 If the above things are fine, please replace the LCD display screen or contact SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 97: Routine Maintenance

    Please clean the outlet and the CBMS panel in time. year SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...
  • Page 98 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 99: System Monitoring

    Number of CBMS supported for management ≤15 SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 100: Homepage

    Click to display the system monitoring page Monitor SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 101: Real-Time Monitoring

    Module number of Maximum value SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 102: Cell Data

    Figure 12.1.5 Cell data preview SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 103: Alarm/Protection Page

    CBMS need to be set. SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 104: Revo 2.0 & Revo2.5 Mixed

    Discharge Cut-off Voltage :480V SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 105: Attention

    SHENZHEN CENTER POWER TECH CO., LTD Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and Ecological Park, Nanshan District, Shenzhen, China Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com Green Our Earth Power Your Vision...

  • Page 106: About Vision

    14.3 About VISION If you have any questions during the use or installation of the product, please contact the relevant personnel of Vision in time. Our company will arrange relevant after-sales service in time. Contact information is as follows Shenzhen Center Power Tech Co., Ltd.
