MODEL 20759, 20759BT
20V MAX CORDLESS
BRUSHLESS 8" POLE SAW
Instruction Manual
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to contact us:
1-847-429-9263 (M-F 8AM-5PM CST)
TECHSUPPORT@WENPRODUCTS.COM
IMPORTANT: Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use
your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
WENPRODUCTS.COM
For replacement parts and the most up-to-date instruction manuals, visit
Advertisement
Table of Contents
Related Manuals for Wen 20759BT
Summary of Contents for Wen 20759BT
- Page 1 1-847-429-9263 (M-F 8AM-5PM CST) TECHSUPPORT@WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
-
Page 2: Table Of Contents
20V 5A Quick Charger (Model 20201Q) WEN plans to continue to add more items to our 20V line. For an up-to-date list of the 20V cordless tools compatible with the included battery and charger, visit wenproducts.com and search model number 20202 (2Ah), 20204 (4Ah),... -
Page 3: Welcome
INTRODUCTION Thanks for purchasing the WEN Pole Saw. We know you are excited to put your tool to work, but first, please take a moment to read through the manual. Safe operation of this tool requires that you read and understand this op- erator’s manual and all the labels affixed to the tool. -
Page 4: Safety
GENERAL SAFETY RULES WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 5 GENERAL SAFETY RULES WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
-
Page 6: Pole Saw Safety Warnings
If you need assistance, put on the protective cover and remove the battery when contact WEN customer service at 1-847-429-9263. transporting or storing the pole saw. Handling the saw with care greatly reduces the risk of accidentally touch-... - Page 7 2. Do not overreach and do not cut above shoulder height. This helps prevent unintended tip contact and enables better control of the pole saw in unexpected situations. 3. Only use replacement bars and chains specified by WEN. Incorrect replacement bars and chains may cause chain breakage and/or kickback.
-
Page 8: Electrical Information (Charger)
ELECTRICAL INFORMATION (CHARGER) DOUBLE-INSULATED CHARGER The charger’s electrical system is double-insulated where two systems of insulation are provided. This eliminates the need for the usual three-wire grounded power cord. Double-insulated tools do not need to be grounded, nor should a means for grounding be added to the product. All exposed metal parts are isolated from the internal metal components with protecting insulation. -
Page 9: Battery & Charger Safety Warnings
Never carry the charger by its cord or yank it by the cord battery chemicals. If the battery or charger are damaged, to disconnect it from the receptacle. Keep the cord away call WEN customer service at 1-847-429-9263 for as- from heat, oil and sharp edges. Make sure the cord will sistance. - Page 10 BATTERY & CHARGER SAFETY WARNINGS ABOUT THE BATTERY 1. The battery pack has to be charged completely before you use the tool for the first time. 2. For optimum battery performance, avoid low discharge cycles by charging the battery pack frequently. 3.
-
Page 11: Before Operating
Components Accessories Shoulder Strap (1) *20V 4.0Ah Battery (1) *20V Charger (1) Pole Saw Head (1) Pole Saw Handle (1) *NOTE: Battery and charger only included with model 20759. 20759BT does not include a battery or charger. -
Page 12: Know Your Pole Saw
TOOL PURPOSE Easily limb trees and clean up branches with your WEN 20V Pole Saw. Refer to the following diagrams to become familiarized with all the parts and controls of your pole saw. The components will be referred to later in the manual for assembly and operation instructions. -
Page 13: Assembly & Adjustments
NOTE: The battery pack and charger are not included with model 20759BT. 1. Connect charger to a 120V, 60Hz AC outlet. The green lights on the charger will illuminate, indicating that the charger is powered. - Page 14 ASSEMBLY & ADJUSTMENTS WARNING! To avoid injury from accidental startups, be sure that the tool is switched OFF and the battery is removed from the tool before inspecting the unit, making adjustments, or changing accessories. FILLING THE AUTO OIL SYSTEM Fig.
- Page 15 ASSEMBLY & ADJUSTMENTS WARNING! To avoid injury from accidental startups, be sure that the tool is switched OFF and the battery is removed from the tool before inspecting the unit, making adjustments, or changing accessories. TENSIONING THE SAW CHAIN Fig. 4 1/8"...
- Page 16 ASSEMBLY & ADJUSTMENTS WARNING! To avoid injury from accidental startups, be sure that the tool is switched OFF and the battery is removed from the tool before inspecting the unit, making adjustments, or changing accessories. WARNING! When handling saw chains, always wear protective gloves to prevent injury. SAW CHAIN LUBRICATION Make sure that the pole saw is powered OFF and the battery is removed from the battery terminal before making any adjustment.
-
Page 17: Operation & Maintenance
OPERATION PREPARING FOR OPERATION Before each use, check the following items to ensure safe working conditions. POLE SAW: Before beginning work, inspect the pole saw for damage to the housing, the saw chain, and the guide bar. Never use an obviously damaged machine. CHAIN OIL: Check the fill level of the oil tank. - Page 18 OPERATION WARNING! Do not cut down trees in high wind conditions. This can result in injury and should only be per- formed by a trained professional. POWERING ON / OFF Fig. 8 1. Install the battery. Slide the battery pack into the battery port. Make sure the release latch on the rear side of the battery pack snaps into place and the battery is secure before beginning operation.
-
Page 19: Maintenance
WARNING! Any attempt to repair or replace electrical parts on this tool may be hazardous. Servicing of the tool must be performed by a qualified technician. When servicing, use only identical WEN replacement parts. Use of other parts may be hazardous or induce product failure. -
Page 20: Exploded View & Parts List
EXPLODED VIEW & PARTS LIST NOTE: Not all parts may be available for purchase. Parts and accessories that wear down over the course of normal use are not covered under the warranty. - Page 21 EXPLODED VIEW & PARTS LIST PART NO. DESCRIPTION QTY. PART NO. DESCRIPTION QTY. 20759-001 Knob 20759-037 Spring 20759-002 Chain Plate Guard 20759-038 Switch 20759-003 C-clip, 14mm 20759-039 Right Handle Housing 20759-004 Rubber Cover 20759-040 Spring 20759-005 Tension Pin 20759-041 Lock-off Switch 20759-006 Spring Self-tapping Screw,...
-
Page 22: Warranty Statement
(2) years from date of purchase or 500 hours of use; whichever comes first. Ninety days for all WEN products if the tool is used for pro- fessional or commercial use. - Page 23 NOTES...
- Page 24 THANKS FOR REMEMBERING V. 2023.08.21...
