Summary of Contents for Ryobi RHS100

  • Page 1 RHS100...

  • Page 2: Intended Use

    ■ When servicing, use only original manufacturer’s IMPORTANT! replacement parts, accessories and attachments. Use It is essential that you read the instructions in this manual of any other parts may create a hazard or cause product before assembling, operating, and maintaining the product. damage.

  • Page 3: Symbols In This Manual

    PRODUCT SPECIFICATIONS SYMBOLS IN THIS MANUAL Hobby station Note Model RHS100 Weight - excluding battery pack 3490 g Parts or accessories sold separately Lock Unlock Speed, minimum Speed, maximum Without force With force Original Instructions...
  • Page 4 Cord retainer Detent release knob Tool hanger Cord holder Inner tube Depth scale Plunge lever Bevel lock knob Depth stop knob Bevel scale Height and rotation lock lever Tool carrier Outer tube Coupler Vacuum port Accessory tray Accessory storage Fence Hole Base Table...
  • Page 5 1. Slide the table away from the base. 1. Remove the end cap from the outer tube. 2. Insert the hex key into the set screw. 2. Put the outer tube assembly into the hole 3. Rotate the hex key counterclockwise to loosen. of the base.

  • Page 6: Getting Started

    NOTE: The fence can be installed in a vertical NOTE: The fence can be installed in a 1. Open the accessory storage cover. position. diagonal position. 2. Put the accessories into the accessory tray. Ø 35mm 1. Insert the vacuum adaptor into the vaccum 1.

  • Page 7: Operation

    BEVELING THE TOOL CARRIER Hold the tool carrier firmly with one hand. ROTATION 0˚ 15˚ 30˚ 45˚ 60˚75˚ 90˚ 1. Turn the bevel lock knob counterclockwise to loosen it. Remove the detent release knob from the product. 2. Turn the tool carrier until the pointer aligns with the preferred angle on the bevel scale.
  • Page 8 Techtronic Industries Australia Pty Ltd 31 Gilby Road, Mount Waverley, VIC 3149 Melbourne, Australia Techtronic Industries N.Z. Limited Unit C, 70 Business Parade South, Highbrook, Auckland 2013, New Zealand RYOBI is a trade mark of Ryobi Limited, and is used under license. 961075780-01...
