Summary of Contents for JXCT JXBS-4001 Series
- Page 1 Portable ammonia gas detector instruction manual JXBS-4001-Gas Ver1.0...
-
Page 2: Product Overview
第 1 章 Product introduction 1.1 Product overview JXBS-4001 series portable gas detector adopts the latest digital integrated circuit technology international gas detection technology design into a new intelligent gas detector. The portable gas detector uses a large-size full-color LCD screen to display readings in real time. The probe selects a well-known brand manufacturer probe in the industry. -
Page 3: Main Parameters
One-stop IoT supply platform the manufacturer can customize the detected gas types according to customer needs. It has a variety of units, including ppm, mg/m3, Vol%, LEL%, PPB and many other units to switch freely. Rich man-machine interface, full-color interface designed based on the latest embedded ideas, can query, record and display gas data in real time. -
Page 4: Probe Parameters
Recovery time ≤ 30 seconds Working -20 ℃ to 50 ℃ temperature Working <95% RH without condensation humidity Working power 3.6VDC ,2000mAh (standard) lithium supply battery Display mode 2.2 inch LCD Communication USB (charging and communication) method Data storage Standard 15,000 data storage space Protection level IP65 Explosion-proof... -
Page 5: Product Structure
One-stop IoT supply platform Ammonia 0-100ppm 0.1ppm 20ppm 1.5 Product structure As shown in the figure below, the product is mainly composed of Shell, display screen, alarm light, buzzer, probe, Button, back clip and other parts. 第 2 章 Basic use of the product 2.1 Basic button of the device The portable gas detector itself has three buttons to operate, as shown in the figure below, the button on the... - Page 6 left is power key, Press for three seconds and release to turn on or off. According to the length of time pressed, the middle and right buttons have two functions respectively: when you press it for a short time, the middle button represents turn the page to the left, the right button represents turn the page to the right;...
- Page 7 One-stop IoT supply platform 12:31 on the left side of the status bar is the current time, and the current time is 12:31. There are three icons on the right. The first icon is the storage icon. The icon appears after the storage function is turned on. The icon will automatically turn green every time it is stored.
- Page 8 The first interface is shown in the figure below, which is an all-in-one gas interface, under which real-time data of all gases can be displayed concisely. When the gas is in the pre-heating period after power-on, the gas will display "--.-", please wait for the preheater to end and display the data.
- Page 9 One-stop IoT supply platform mark will appear, at the same time, the gas changes from a normal white font to a red font. There is an instrument line at the bottom of the center of the screen. The greater the gas concentration, the longer the instrument line. Below are the minimum and maximum concentrations for the measurement period.
- Page 10 is composed of two acquisition intervals, and the vertical axis represents the gas concentration, the red discount is a real-time line chart of the data collected during the last 20 collection intervals. 2.4 Product alarm and alarm When the product detects that the concentration exceeds the alarm limit, the instrument will trigger the alarm state.
- Page 11 One-stop IoT supply platform In the alarm state, short pressing the "page left/cancel button" will cancel the alarm and turn off the alarm state of the buzzer and alarm light, but the red number and alarm icon on the screen will not disappear. If another gas triggers the alarm again in the alarm state, the buzzer and the alarm light will still indicate the alarm until the alarm is lifted or the alarm is manually eliminated.
- Page 12 In the function menu, short press "turn page left/cancel key" to turn the page to the left or decrease the value, and short press "turn page right/confirm key" to turn the page to the right or increase the value. Long press the "page left/cancel key"...
- Page 13 One-stop IoT supply platform Select the status editing status 3.2 System Settings menu There are six settings under the system settings menu: "Time setting": used to set the current time. Generally, it does not need to be set. It has been automatically calibrated at the factory.
-
Page 14: Alarm Setting Menu
setting range is 0-15 minutes, and the factory default is set to 0 minutes, that is, it does not automatically shut down. "Backlight Brightness": Used to set the backlight brightness of the display screen. There are a total of 4 brightness levels, of which 0 is the darkest and 3 is the brightest. - Page 15 One-stop IoT supply platform Among them, "sound and light alarm" is used to set whether to turn on the sound and light alarm, the degree of alarm sound after turning on the sound and light alarm, set 0 to turn off the sound and light alarm, and 1-5 represents different emergency procedures, the sound of 1 is the most compact, and the sound of 5 is longer.
-
Page 16: Concentration Calibration
3.4 Concentration calibration The concentration calibration function is a more professional function, please do not operate this item for non-professionals. Please refer separate instructions for concentration calibration. 3.5 Restore factory settings There are two options to restore the factory settings. The factory settings for setting and alarm reply are basic recovery, and other configuration items except the probe coefficient and probe zero point are restored to the... - Page 17 One-stop IoT supply platform equipment is inaccurate, the equipment can be corrected, in a normal natural environment with good ventilation, the equipment will be completed within about 1 minute after selecting the equipment to zero. 3.7 Data record parameter settings There are four items under the Data Recording menu, namely "automatic recording switch", "recording interval setting", "data usage"...
-
Page 18: Drive Installation
record once. "Data usage": You can tell the customer how many pieces of data have been stored and how many pieces of data can be stored. "Record data emptying": Data that can be stored in a situation. Please note that the emptying process is irreversible, so please operate with caution. - Page 19 One-stop IoT supply platform bit system). 4.2 Data software usage First use the USB-Mini data cable provided to connect the device to the computer, in the device status bar after the USB insert icon, open the portable data reading software, select the correct serial number, click to connect the device.
- Page 20 At the same time, the software can be used to calibrate the time of the device with one key, and the function of clearing data with one key. When the device is connected, click the relevant button to check the time or clear the data with one key.
- Page 21 One-stop IoT supply platform...
