PORTABLE CARPET AND UPHOLSTERY CLEANER
Thank you for buying a HAUSHOF PORTABLE CARPET AND UPHOLSTERY CLEANER. It has been
engineered and manufactured to HAUSHOF's high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator's
manual before using this products. HOUSEHOLD USE ONLY!
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATION MANUAL
HH23112A
Distributed by :
Hangzhou GreatStar Industrial Co., Ltd.
No.35 Jiuhuan Road, Jiubao Town,
Hangzhou 310019, China
www.greatstartools.com
MADE IN CHINA
Advertisement
Table of Contents
Summary of Contents for HAUSHOF HH23112A
- Page 1 PORTABLE CARPET AND UPHOLSTERY CLEANER OPERATION MANUAL Thank you for buying a HAUSHOF PORTABLE CARPET AND UPHOLSTERY CLEANER. It has been engineered and manufactured to HAUSHOF's high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
-
Page 2: Important Safeguards
Attentions IMPORTANT SAFEGUARDS • Store your vacuum cleaner indoors in a cool, dry area. When using an electrical appliance, basic • Keep your work area well lit. precautions should always be followed, including the following: • Move or unplug other electrical appliances near the area to be cleaned that may get wet. -
Page 3: Parts Name
Symbols Waste electrical products must not To reduce the risk of injury, user must be disposed of with household waste. read instruction manual Please recycle where facilities exist. Check with your local authorities or retailer for recycling advice. To indicate connection to or disconnec- tion from the mains. - Page 4 Parts Name Accessories Suction Suction inlet inlet Water outlet Brush Water outlet Water sucker with brush, Gap brush, for narrow space. Spot & stain cleaner for carpet, etc. 50ml 40ml 30ml 20ml 10ml Screw cap of the clean water bucket Measuring cup...
- Page 5 Preparation Open the upper cover of clean water bucket, take out the spot & stain cleaner, screw the screw cap of the clean water bucket, and inject clean water. The maximum water capacity is about 1.5L(50FL OZ). If deep cleaning is required, pour in the special cleaning solution.
- Page 6 Instructions Absorb water, spray clean water Plug it in, turn on the power (start). Press the watering button to spray clean water. Spray the stain while absorbing sewage. Press with clean water to let it surface. the water suction inlet on the Do not spray continuously at the stain, bring the water and dirt to same spot.
- Page 7 For stubborn dirt For deep cleaning, add HUASHOF cleaner into the water at specified ratio (1(formula):33(water)). For more details, see the description on spot & stain cleaner bottle. 50ml 40ml 30ml 20ml 10ml Recommended Not appropriate Detergent Strong alkaline ionized water Neutral detergent for kitchen use Baking soda Strongly alkaline detergent...
-
Page 8: Cleaning And Maintenance
Cleaning and Maintenance Cleaning of bucket Watering button Take out the clean water bucket in Install the empty bucket and then Tilt the machine and pour away the direction of arrow, open the upper turn on the power again, press the the remaining water at the bottom. - Page 9 Cleaning and Maintenance Press the button and pull out After use every time, remove them Disassembly of water sucker. Disassembly of water sucker cover. from the body, rinse thoroughly with water and air dry. Nozzle Installation of water sucker cover: When cleaning the water sucker, Check the hose for breakage and 1.
- Page 10 Consumables, Fault and Handling The consumables can be removed and replaced when damaged or lost. Be sure to install and use Seal ring for upper cover Inlet air sponge Screw cap of the clean water bucket In the event of exceptions in use, read this manual carefully and confirm the following points before repair. Status Fault cause analysis Handling...
-
Page 11: Environment Friendly Disposal
Environment Friendly Disposal Disposal of the Appliance This product has been marked with a symbol relating to removing electric and electronic waste. This means that this product shall not be discarded with household waste but that it shall be returned to a collection system. It will then be recycled or dismantled in order to reduce the impact on the environment.
