Leica GEB371
User Manual
Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GEB371 and is the answer not in the manual?

Questions and answers

Summary of Contents for Leica GEB371

  • Page 1 Leica GEB371 User Manual Version 1.0...
  • Page 2 GEB371, Introduction Introduction Read and follow the User Manual of the main product before using the product or the accessories delivered with the product.
  • Page 3: Description Of The System

    Description of the System Delivery Contents and Optional Accessories GEV242 GEB371 GEB371 Power-Cable (depending on type of instrument) Y-Cable for UPS (GEV277) 007793_001 GEB371, Description of the System...
  • Page 4 GEB371, Description of the System Activating the Battery before First-time Usage ...8h GEV242 007796_001...
  • Page 5 Battery Components Standard port (LEMO-1, 5 pin) 007794_001 GEB371, Description of the System...
  • Page 6 GEB371, Description of the System Cabling Options 100-240 V GEV242 Power Cable Instrument GEV242 100-240 V GEV277 Power Cable Instrument 007795_001...
  • Page 7: Operation

    Operation LED-Indication of Battery Level 1%-30% 31%-60% 61%-90% 91%-100% 007797_001 GEB371, Operation...
  • Page 8 GEB371, Operation Charging the Battery ...8h 0%-30% 31%-60% GEV242 61%-90% 91%-100% ...100% 007798_001...
  • Page 9 Battery Power Supply (with Power Cable) Power Cable Instrument (depending on type of instrument) GEB371 http://accessories.leica-geosystems.com/ Cables 007799_001 GEB371, Operation...
  • Page 10 GEB371, Operation Uninterruptible Power Supply (with Y-Cable, Power Cable and GEV242) GEV242 100-240 V GEV277 Power Cable Instrument 007800_001...
  • Page 11 Operating Temperature 45°C 0°C 100-240 V GEV242 65°C -35°C Power Cable Instrument 009268_001 GEB371, Operation...
  • Page 12: Troubleshooting

    GEB371, Troubleshooting Troubleshooting Error Indication 45°C 0°C GEV242 007801_001...
  • Page 13: Fcc Statement, Applicable In U.s

    • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by Leica Geosystems for compli- WARNING ance could void the user's authority to operate the equipment. GEB371, FCC Statement, Applicable in U.S.
  • Page 14 GEB371, FCC Statement, Applicable in U.S. Type Plate Labelling GEB371 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 15: Dangerous Goods Regulations

    Leica Geosystems has developed Guidelines on “How to carry Leica prod- ucts” and “How to ship Leica products” with Lithium batteries. Before any transportation of a Leica product, we ask you to consult these guidelines on our web page (http://www.leica-geosystems.com/dgr) to ensure that you are in accordance with the IATA Dangerous Goods Regulations and that the Leica products can be transported correctly.
  • Page 16 Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Phone +41 71 727 31 31 www.leica-geosystems.com...
