Next Gen JuiceBox
User Manual
ENGLISH
755-000215 Rev F

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the enel way Next Gen and is the answer not in the manual?

Questions and answers

Summary of Contents for Juicebox enel way Next Gen

  • Page 1 Next Gen JuiceBox User Manual ENGLISH 755-000215 Rev F...

  • Page 2: Table Of Contents

    Table of contents Welcome to JuiceBox IMPORTANT SAFETY INSTRUCTIONS INSTRUCTIONS PERTAINING TO A RISK OF FIRE OR ELECTRIC SHOCK FCC Compliance RF Exposure Package Contents Required Tools Installation Instructions Installation Prerequisites Installation Load Balancing Locking Your JuiceBox Operation Wi-Fi Setup...

  • Page 3: Welcome To Juicebox

    WARNING: Do not operate the JuiceBox outside its operating temperature rating indicated on the JuiceBox label. WARNING: Do not use solvents to clean the JuiceBox as they may degrade or damage the plastic enclosure. INSTRUCTIONS PERTAINING TO A RISK OF FIRE OR ELECTRIC SHOCK WARNING: Do not put fingers into the electric vehicle connector.

  • Page 4: Fcc Compliance

    FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.

  • Page 5: Package Contents

    Package Contents > JuiceBox NOTE: In some markets, JuiceBox arrives secured to a cable holder that includes keys. > Wall bracket > 2 wall bracket screws (#10 self-tapping Phillips head wood screws) > 2 screws to hang JuiceBox onto wall bracket (#10-32 Phillips head machine screws).

  • Page 6: Installation Instructions

    JuiceBox requires either a hardwired electrical connection, NEMA 6-50 outlet, or a NEMA 14-50 outlet. The JuiceBox power supply must be connected to a circuit breaker that is rated for at least 125% of the device’s continuous load. NOTE: Ensure that all power connection wiring conforms to the rules and regulations of any national and local codes.

  • Page 7: Installation

    INSTRUCTIONS at the beginning of this document. The JuiceBox is intended to be mounted to a solid surface using the included mounting screws and wall bracket. 1. Turn off the circuit breaker to the NEMA 14-50 outlet, NEMA 6-50 outlet, or hardwired...
  • Page 8 WARNING: Do not continue this installation until the circuit breaker is turned off. 2. Use a stud sensor to determine an appropriate mounting location, then use the 2 screws to secure the wall bracket. 3. Insert the enclosure screws into the enclosure, as shown. Tighten the screws until approximately 2 mm of thread are visible.
  • Page 9 4. Hang the JuiceBox onto the wall bracket. NOTE: If the JuiceBox does not hang securely, adjust the screws that were installed in step 3. Few JuiceBox models are hardwire only and do not have a plug as shown. 5. Connect the JuiceBox: >...

  • Page 10: Load Balancing

    = 40 amp continuous load allowed) (NEC 625.41 & 42) 2017 code. > Per NEC 625.42 additional outlets per circuit can be added due to the JuiceNet Automated Load Management System. Locking Your JuiceBox After installing your JuiceBox, use the included keys to lock the JuiceBox to the wall frame.

  • Page 11: Operation

    Wi-Fi Setup Wi-Fi Setup - Mobile Device For best results, perform this procedure while standing within 5 ft (1.6m) of the JuiceBox. 1. Download and install the “Enel X Way” app onto your mobile device. 2. Log into the Enel X Way app. If you do not have an account, create one.
  • Page 12 4. Tap START CONFIGURATION. NOTE: You can allow the Enel X Way app to access your device’s camera to scan the QR code to avoid manually entering the charging station’s serial number.
  • Page 13 Serial Number and enter it manually. Then, select “→” button. 6. Have your Wi-Fi network password ready and tap CONTINUE, then “→” button. NOTE: If the JuiceBox LED is not flashing blue color, disconnect it from power source and re-connect before proceeding.
  • Page 14 NOTE: After powering the JuiceBox, steps 7 through 10 must be completed within 2 minutes. 7. Navigate to the Wi-Fi settings on your mobile device. Connect to the “JuiceNet-###” or “EXW-###” Wi-Fi network. If the network requires a password, use the password “GoElectric”...
  • Page 15 9. In the Enel X Way app, select the desired local Wi-Fi network. 10. Enter the Wi-Fi network password, if necessary. Then, select CONNECT CHARGER TO WIFI.
  • Page 16 11. The app connects the JuiceBox to the Wi-Fi network. 12. Enter the charger’s name and address. Then, select “→” button.
  • Page 17 13. Select between Unlock to charge or Connect and charge. Then, select “→” button. 14. You did it! The JuiceBox is now online and ready to charge. NOTE: Once getting online, JuiceBox checks its firmware and performs any necessary updates. Wait 10 minutes before plugging in a vehicle.
  • Page 18 NOTE: The following steps must be completed within 2 minutes of plugging in the JuiceBox. 2. Open the Wi-Fi settings on your personal computer. Connect to the “JuiceBox-###” or “JuiceNet-###” Wi-Fi network using the password “GoElectric” (case-sensitive). NOTE: The actual name of the network varies by device, such as “JuiceBox-123”.
  • Page 19 NOTE: After connecting, JuiceBox checks its firmware version and performs any necessary updates. Wait 10 minutes before plugging in a vehicle. Set Up JuiceNet Dashboard 1. Log into the dashboard. 2. Select Add JuiceNet Device. 3. Enter the JuiceNet ID and select Add JuiceNet Device.

  • Page 20: Pairing Alexa

    Moving and Storage > To prevent risk of fire or electric shock during subsequent use, do not lift or carry the JuiceBox by holding the AC input or output cable. > Storage Temperature: -40°F to 158°F (-40°C to 70°C).

  • Page 21: Specifications

    Specifications Characteristics 32A max: Up to 7.7 kW, 32A, 1-phase OUTPUT POWER 40A max: Up to 9.6 kW, 40A, 1-phase 48A max: Up to 11.5 kW, 48A, 1-phase INPUT VOLTAGE 120/240 VAC LEDs Dynamic LEDs displaying charging status IP66/NEMA 4X PROTECTION AC 20mA Ground Fault Detection TEMPERATURE...

  • Page 22: Dimensions

    Dimensions...

  • Page 24: Led Indicator

    LED Indicator COLOR PATTERN MEANING Flashing Setup Mode Blue Solid Wi-Fi setup device connected Booting after power Solid (Note: During booting, solid Yellow may be followed by Purple before going to Setup Mode) Yellow Vehicle plugged in, not charging Flashing (Note: EV not ready to charge or charging suspended (ToU) or in earlier releases: charging finished)
