HSE 7110 Instruction Manual

1.0 INTRODUCTION
1.1 General Description:
The Model 7110 is a single radiator antenna that is compatible with any of the
High Sierra Electronics receivers or transmitters. The Model 7110 has been tuned at the
factory for optimal performance at frequencies between 169 and 173 MHz. Other
frequency ranges are available. Contact High Sierra Electronics for details.
1.2 Receiving , Inspection and Unpacking:
The Model 7110 is a rugged unit; however, you should still exercise care during
unpacking and installation. Remove the Model 7110 carefully from the box and identify
each component listed in section 1.3 below. Should any parts be missing, notify High
Sierra Electronics Customer Service, please have your packing list available when you call.
If any of the parts are received in damaged condition, notify the carrier
immediately and request an inspection. You must notify the carrier within 15 days of
shipment. If a claim is not made within that time period, then the carrier will not
acknowledge any claim for the lost or damaged goods.
1.3 Parts List:
(1) Antenna Assembly
55" Antenna with
SO-239 connector;
1
3/8"
(2) #10 x ½" self tapping screws
(1) 2x2 moisture tape
(2) #40 hose clamps (optional mounting hardware)
1.4 Specifications:
Antenna Type:
Frequency:
Power Rating:
Gain:
Impedence:
VSWR:
Max Overall Length :
Connector:
Shipping Weight:
Model 7110-01(C) June 2008
Model 7110 VHF Omni Antenna
Instruction Manual 60-7110-01(C)
brass antenna feedmatch.
1/8"
and "dust cover
5/8
Omni Directional
169 to 173 MHz (Optional frequency bands available)
500 Watts
3 dB
50Ω Nominal
< 1.5:1
54 Inches
SO-239
5 pounds
1
