- Page 1 I N S T R U C T I O N M A N U A L PB20VLIB2 & PB20VLIB4 20 Volt Battery Part Numbers: PB20VLIB2 & PB20VLIB4 IMPORTANT: Read before using.
- Page 2 Keep these instructions with the accompanying tool for the life of the tool. Read all of the instructions before assembling, operating or maintaining this tool. This manual has been compiled by The Original Pink Box Tools describing the purpose for which this tool has been designed, and contains all the necessary information to ensure its correct and safe use.
- Page 3 GENERAL WARNINGS & DISPOSAL To reduce the risk of injury, the user must read the instruction manual. This symbol is used throughout this manual to warn the user about potential risks. Please read & understand these sections before using the device. The device must not be exposed to rain or immersed in water.
-
Page 4: Table Of Contents
CONTENTS BATTERY SAFETY ..............5 COMPONENT LIST ..............6 BATTERY TECHNICAL DATA ..........6 OPERATING INSTRUCTIONS..........7 Intended Use ................7 Battery..................8 Maintenance ................9 Transport and Storage............. 9 www.theoriginalpinkbox.com - 4 -... -
Page 5: Battery Safety
WARNING: Read all safety warnings, instructions and specifications provided with this battery. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. Recharge only with the The Original Pink Box PB20VLIC charger. A charger that is ▲... -
Page 6: Component List
LITHIUM ION BATTERY TECHNICAL DATA Part No. Voltage Battery Charge Capacity Time PB20VLIB2 2.0A.h 45 mins. PB20VLIB4 4.0A.h 100 mins Times given as a guide only. Battery charge and discharge times dependant on age, usage and condition. www.theoriginalpinkbox.com - 6 -... -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS INTENDED USE This lithium-ion battery pack is indended for use only with a compatible 20V power tool & charger. The component must not be modified or used for any other purposes than the ones described in these instructions. BATTERY ▲... -
Page 8: Battery
BATTERY CHARGE LEVEL Green Battery Charge Status Charger is connected to power supply Connected battery is charging Connected battery is fully charged Connected battery has a charging fault Charger is outside correct operating temperature range (<32°F / > 104°F) IF THE LEDS ON THE CHARGER DO NOT COME ON WHEN CHARGING: Check that the charger is properly plugged into the electrical outlet and that the ▲... -
Page 9: Maintenance
MAINTENANCE WARNING: Remove the battery pack from the tool or charger before cleaning and maintenance. This helps avoid the risk of electric shocks and accidental injury. Wipe the battery pack with a dry or damp cloth. Do not use a wet cloth. Do not use ▲...
