Summary of Contents for Hyundai power products HYTIG200
- Page 1 DC INVERTER TIG WELDER HYTIG160 & HYTIG200 Instruction Manual WARNING: Read the instructions carefully before use.
- Page 2 TIG-160/200 We are still constantly improving this welder, therefore, some parts of this welder may be changed in order to achieve the better quality, but the main functions and operations will not be alternated and changed. Your understanding would be greatly appreciated.
-
Page 3: Table Of Contents
tig-160/200 Table of Contents Safety ................................General Description ............................. Main Parameters ............................Operation Control and Description ......................Installation Debugging and Operation ......................Caution ................................. Maintenance ..............................Troubleshooting ............................Exploded Drawing ............................Hyundai... -
Page 4: Safety
tig-160/200 1. Safety Welding is dangerous, and may cause damage to you and others, so take good protection when welding. For details, please refer to the operator safety guidelines in conformity with the accident prevention requirements of the manufacturer. Professional training is needed before operating the machine. Use labor protection welding supplies authorized by national security supervision department. - Page 5 tig-160/200 Hot work piece may cause severe scalding. Do not contact hot work piece with bare hands. ● Cooling is needed during continuous use of the welding torch. ● Magnetic fields affect cardiac pacemaker. Pacemaker users should be away from the welding spot before medical consultation. ●...
-
Page 6: General Description
tig-160/200 2. General Description The welding machine has the most advanced inverter technology adopting rectifier. The development of inverter gas-shielded welding equipment profits from the development of the inverter power supply theory and components. Inverter gas-shielded welding power source utilizes high-power component MOSFET to transfer 50/60Hz frequency up to 100KHz, then reduce the voltage and commutate, and output high-power voltage via PWM technology. -
Page 7: Operation Control And Description
tig-160/200 4. Operation Control and Description The panel picture below is for reference only. If any difference with the real machine, please follow with the real machine. TIG Welding Description 1) Turn on the power switch at the back panel, digital current meter is normal, fan begins to wheel. 2) Open the valve of argon cylinder, adjust the volume of flow meter and make it is adequate to welding. -
Page 8: Installation Debugging And Operation
tig-160/200 5. Installation Debugging and Operation The machine is equipped with power voltage compensation equipment. When power voltage moves between ± 15% of rated voltage, it still can work normally. When using long cable, in order to prevent voltage from going down, bigger section cable is suggested. If cable is too long, it may affect the performance of the power system. -
Page 9: Caution
tig-160/200 6. Caution Environment 1) The machine can perform in environment in dry condition with a dampness level of max 90%. 2) Ambient temperature is between 10 to 40 3) Avoid welding in sunshine or rain. 4) Do not use the machine in environment where condition is polluted with conductive dust on the air or corrosiveness gas on the air 5) Avoid gas welding in the environment of strong airflow. -
Page 10: Maintenance
tig-160/200 Caution : Creep age-protecting switch. The machine is mainly used in industrial site. It will produce radio wave, so the worker should be fully prepared for protection. should be added when using the machine Warning : BEFORE CHECKING : Blind experiment and careless repair may lead to more problem of the machine that will make formal check and repair more difficult. -
Page 11: Troubleshooting
tig-160/200 8. Troubleshooting Fittings, welding materials, environment factor, supply powers maybe have something to do with welding. User must try to improve welding environment. A. Black welding spot Welding spot is not protected from oxidizing. User may check as following: 1. - Page 12 tig-160/200 Common Malfunction Analysis and Solution: Malfunction Cause and Solution 1. Power switch is out of work. Power indicator is not lit, fan does 2. Check if electrify wire net (which is connected to input cable) is in work. not work and no welding output. 3.
-
Page 13: Exploded Drawing
tig-160/200 9. Exploded Drawing TIG-160/200 1. Silicone rubber 13. Bottom 25. Vertical beam 2. LED 14. Cover 26. Middle PCB 3. Power switch 15. Front panel 27. PCB 4. Switch 16. Side shield plate 28. Top PCB 5. Fan net 17. - Page 14 DC Inverter TIG Welder HyuNDAI Declaration Conformity 2016 We : HyuNDAI Corporation 25, Yulgok-ro 2-gil, Jongno-gu, Seoul 03143 Korea Declare that the product detailed below : DC INVERTER TIG WELDER MODEL : TIG-160/200 Satisfies the requirements of the Council Directives : EC-Low voltage directive 2014/35/EU EC Directive of Electromagnetic Compatibility 2014/30/EU RoHS Directive 2011/65/EU...
- Page 16 For Inquiries, Please Contact: GENPOWER LTD Isaac Way, London Road, Pembroke Dock, UK, SA72 4RW. T: +44 (0) 1646 687 880 E: info@hyundaipowerproducts.co.uk www.hyundaipowerproducts.co.uk Imported / Distributed by Genpower Ltd for Licensed by Hyundai Corporation Holdings, Korea the United Kingdom & Ireland...
