orbia Netafim GrowSphere ONE Quick Setup Manual

Field monitoring unit
Hide thumbs Also See for Netafim GrowSphere ONE:

Advertisement

Table of Contents

GrowSphere
Operating System
GrowSphere
ONE
™
Field Monitoring Unit
GrowSphere™ ONE is a stand-alone monitoring unit that can be
connected to a wide range of sensors to collect real-time data
from the field, enabling optimal irrigation management
Quick Setup Guide
May 2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Netafim GrowSphere ONE and is the answer not in the manual?

Questions and answers

Related Manuals for orbia Netafim GrowSphere ONE

Summary of Contents for orbia Netafim GrowSphere ONE

  • Page 1 GrowSphere Operating System GrowSphere ™ Field Monitoring Unit GrowSphere™ ONE is a stand-alone monitoring unit that can be connected to a wide range of sensors to collect real-time data from the field, enabling optimal irrigation management Quick Setup Guide May 2024...
  • Page 2 Technical Assets...

  • Page 3: Technical Specifications

    Technical specifications Solar panel 5.5 Watt Battery rechargeable li-ion pack 3.7V 5200mAh Outdoor installation IP65, UV protected Standard compliance CE & FCC* * Certification in process Environmental Supported sensors specifications • • Working temperature -10°C to Analog input (X3) 55°C (14°F to 131°F) •...

  • Page 4: What's In The Box

    What's in the box GrowSphere™ GrowSphere™ integrated solar external solar panel panel monitoring unit + bracket monitoring unit External solar panel 5.5W + 5m extension cable Integrated solar panel 5.5W Antenna Charging cable Base plate Bird spikes Metal cable ties Plastic bands Magnetic screwdriver 2.0 x 50mm...

  • Page 5: Initial Setup

    Initial setup GrowSphere™ ONE integrated solar panel Connect the unit to the panel Connect the antenna and solar panel to the ONE unit Cellular antenna connector Solar panel connector / Charging cable Connect the bird spikes to the solar panel if required Netafim™...
  • Page 6 GrowSphere™ ONE external solar panel Connect the antenna and solar Connect the bird spikes to the panel to the ONE unit solar panel if required Cellular antenna connector Solar panel connector / Charging cable Netafim™ | GrowSphere™ ONE QSG 2024...

  • Page 7: Sensor Wiring Diagram

    Sensor Wiring Diagram SM150T Rain Soil Moisture Water Tension Soil Moisture Dendrometer Pressure Collector SM150T Tensiometer NetaSense sensor (+) (AI) (-) (+) (AI) (-) (+) (AI) (-) (+) (AI) (-) (+) (AI) (-) Analog Digital Inputs Inputs Water Meter Technician Solar Panel Cable Input / Charging...

  • Page 8: Prior To Configuration

    Prior to configuration Ensure the unit is charged for a minimum of 5 hours, by using the provided charging cable (as demonstrated in the diagram above). A blue led will indicate battery charging. After charging, disconnect the cable and connect the solar-panel cable instead.
  • Page 9 ONE installation Integrated solar panel External solar panel, 5m cable Towards sunlight Towards sunlight In the App folder, click on the EXE. file. The user-name and password are not required. Instead, click on the 'Login' Select Device TechApp Select your device Configure your unit by following the instructions below, based on the sensors you wish to connect.
  • Page 10 Unit Parameters The parameters are read-only. Click 'Save' Netafim™ | GrowSphere™ ONE QSG 2024...
  • Page 11 Sensors Configuration Port Config for Serial sensors Select the sensors you wish Define the Sensor Type and Sensor to connect Depth. Check the Active box and then click Save * It is recommended at this stage to physically connect the sensors to the device Netafim™...
  • Page 12 Port Config for Digital sensors Port Config for Analog sensors Define the Sensor Type, Sensor Define the Sensor Type, Sensor Name and Pulse Volume. Check Name and Sensor Depth. the Active box and then click Save. Check the Active box and then Please note: Metric / Imperial units click Save can be selected...
  • Page 13 Network Now you can disconnect the cable, the unit is ready for field installation. Please note, from the moment the unit is activated, it will stay active for 15 minutes. If Modem Status is "Not connected", you can use the magnet or select 'Read' and then 'Connect' to activate it Netafim™...
  • Page 14 Sign-up to GrowSphere™ Cloud Create your GrowSphere™ account or log in to an existing account. A link was sent to you by your Netafim representative Log-in to your GrowSphere™ Cloud account Netafim™ | GrowSphere™ ONE QSG 2024...
  • Page 15 Setup your Farm Navigate to 'Add device' Netafim™ | GrowSphere™ ONE QSG 2024...
  • Page 16 Add Device • Choose 'ONE' • Input your unit's MAC address • Click 'Connect' MAC address Device is active and connected MAC address Netafim™ | GrowSphere™ ONE QSG 2024...
  • Page 17 Process completed Congratulations! The set-up process is now completed View your Device Your device and the connected sensors will appear on the menu, in the 'Devices Management' screen Netafim™ | GrowSphere™ ONE QSG 2024...
  • Page 18 Recommended next steps • You can name each device - By default, the device name will be its serial number • Define thresholds for relevant sensors according to your preferences • Create Irrigation Blocks and Crop Units • Assign the devices to their relevant Irrigation Block •...
  • Page 19 GrowSphere GrowSphere Operating System Operating System www.netafim.com...
