Soroya Angel-B-CN430B+ Quick Operation Manual

Quick
Operation Guide
Angel-B-CN430B+
In-The-Ear hearing aid
Please read the rehabilitation plan first
Technical Parameter
Max.OSPL90 HF Avg.OSPL90 Max gain
≤107±3dB 104±3dB 31±4dB
Battery
Noise Level Frequency Range
Current
≤32dB 500-4000Hz ≤2mA
Power On/Off
Power ON: Take the device out of the charging box.
Power OFF: Put the device into the charging box.
Please distinguish the right ear and the left ear
according to the color. Blue for the left and red
for the right.
Note: For the first use, please remove the film
from the device.
Hearing Aid
Microphone
Accessories
1 Earplugs s\m\l
3 Wax Guard 4
How to replace ear tips
HFA Gain At the time of purchase, an M size ear tip is
attached. lf it does not fityour ears, the sound is
difficult to hear, or you hear beeping, replace
28±4dB
theeartips with the supplied s size or L size.
Total Distort
≤3%
Turn the umbrella partof the ear tip over
Hold the base andpull it off.
Hold the hearing aid with your hand.
Insert the eartip straight and insert it gently as
faras it will go.
Pull the eartip lightly to make sure it
does not come off
Multi-function button
Earplug
Speaker
Charging Point
Charging Point
1
2 Cleaning brush
x1 x1
Charging Cable
2
Do not pull the umbrella
because it is thin. It may
be damaged.
3
4
5
Charging Box
Hearing aid
charging indicator
2
x1
3
x1
x1
How to use
1
Pinch the hearing aid with your thumb and index
finger, and place the earplug side in the ear canal.
Rotate the hearing aid to snap it into the ear.
2
●Click the hearing aid button once: increase the
volume by one level. Two beeps are heard, which
is the highest volume level.
●Long press the hearing aid button for 3 seconds:
One beep means simulation scene 1(general mode) .
Two beeps mean simulation scene 2 (noise reduction).
Three beeps mean simulation scene 3 (outdoors ).
The hearing aid has a memory function, and there
is no need to repeatedly adjust the volume and
mode next time.
Mirror
Charging
box indicator
Charging Port
x1
4
