Summary of Contents for Enmind VV-100
- Page 1 VV-100 Vein Viewer User Manual Shenzhen Enmind Technology Co.,Ltd.
- Page 2 All components and accessories as well as consumables for repairing are provided by manufacturer. 4. Description on Revision of User Manual The copyright of this User Manual belongs to Shenzhen ENMIND Technology Co., Ltd. Without permission any institute or individual are prohibited to copy, modify or translate the contents speculated in this User Manual.
-
Page 3: Table Of Contents
Content Chapter 1 Safety Instruction ....................... 1 1.1 Warning ..........................1 1.2 Equipment safety classification: ..................1 1.3 Electromagnetic interference: ....................1 1.4 Environmental protection: ....................2 1.5 Symbols ..........................2 Chapter 2 Product Description ....................3 2.1 Definition ..........................3 2.2 Working Principle ........................ -
Page 4: Chapter 1 Safety Instruction
Chapter 1 Safety Instruction 1.1 Warning Before using, please check the equipment, connecting wire and accessories to ensure that it can work normally and safely. If there’s anything abnormal, immediately stop working and contact our after sale service department. Additionally, the adhesion or intrusion of fluid/drug may possibly cause the equipment fault and malfunction. -
Page 5: Environmental Protection
1.4 Environmental protection: When discarding products, packaging materials or accessories at the end of product life, make sure that the discarded products do not pollute the environment or are disposed of in accordance with relevant laws and regulations. 1.5 Symbols Not all of the below symbols are existed in the equipment you have purchased. -
Page 6: Chapter 2 Product Description
Chapter 2 Product Description 2.1 Definition Venipuncture is a commonly used medical method. This blood vessel imaging device can make it easier for doctors and nurses to find veins, improve the success rate of venipuncture in children and obese people, and reduce the pain caused by the failure of venipuncture. 2.2 Working Principle This product is developed on the basis of the specific absorption spectrum of deoxyhemoglobin. -
Page 7: Chapter 3 Appearance
Chapter 3 Appearance 3.1 Front View ① Display ② Menu [UP] ③Select [FORWARD] ④Menu [DOWN] ⑤ Select [BACK] ⑥ Power... -
Page 8: Back View
3.2 Back View ① ② ① Camera ② Stand Connector... -
Page 9: Display
3.3 Display 3.3.1 Size: S(Small)/M(Medium)/L(Large) 3.3.2 Color: 3.3.2.1 Normal Mode White/Yellow/Pink/Red/Light Blue/Green/Deep Blue 3.3.2.2 Enhancement Mode Purple/Blue/Yellow 3.3.3 Inverse Mode: Inverse/Non-Inverse 3.3.4 Brightness: L(Low)/M(Medium)/H(High) -
Page 10: Chapter 4 Use Instruction
Chapter 4 Use Instruction 1) The instrument was placed about 20-25CM above the patient's puncture site. The lens is aligned to the applicable location and blood vessels. Turn on the power supply, press the power button for a long time until the boot-up interface appears on the screen, the machine starts to work, and the projector lights up. -
Page 11: Chapter 6 After Sale Service
3) The fault and damages caused by fire, salt injury, toxic gas, earthquake, windstorm, flood, abnormal voltage and other natural disasters. For the damages or faults mentioned above, our company provides repair services but charge at repair cost. Manufacturer: Shenzhen Enmind Technology Co., Ltd. Room 201,Block A,No.1,Qianhai Road 1,Qianhaishen Port Cooperative District, Shenzhen, 518000,Guangdong,China Site included: 5th Floor, Block A, Defengsheng Building, No.41 Dabao Road, Bao'an District 23, Shenzhen,...
