Summary of Contents for ADIRhome ADI315-01-WHI
- Page 1 SPACE-SAVING BUILT-IN HAMPER USER GUIDE ADI315-01-WHI...
- Page 2 Thank you for your purchase. AdirHome maintains a strong practice of ongoing development of products and commercial research. We understand starting and maintaining a business is expensive enough. We can help you make it cost effective and beautiful. Plus, our expert team makes sure everything you need works as efficiently as possible.
-
Page 3: Table Of Contents
Table of Contents Specifications Parts List Hardware List Tools Needed (But Not included) Assembly Instructions Warranty Notes... -
Page 4: Specifications
Specifications Weight: 20.28 lb Weight Capacity: 33 lb. Dimensions: 38.19” H x 16.61”W x 7.09” D Hamper Opening: 13.25” x 6.69” Recessed Opening Dimensions: 36.61” H x 14.56” L x 4.05” D Material: Powder Coated Steel... -
Page 5: Parts List
Parts List Hamper Hardware List Plastic Anchor Screw (6mm) (x4) (8 mm) (x4) -
Page 6: Tools Needed (But Not Included)
Tools Needed (But Not Included) Measuring Tape Pencil Hammer or Rubber Electric Drill Mallet Screwdriver Level... -
Page 7: Assembly Instructions
Assembly Instructions Step 1: A. Determine where you would like to install your Hamper. B. The wall needs to be recessed in order for this product to be mounted. a. If you do not have a recessed wall, it is recommended you contact a professional to help build one. - Page 8 Step 2: A. The Hamper is installed using four Screws (1), two per side. B. Insert the Hamper (A) into the cut-out to guarantee a secure fit. C. Mark the four drill holes with a pencil onto the wall. D. Remove the Hamper (A) and drill four holes.
- Page 9 Step 3: A. Insert the four Plastic Anchors (2) into the predrilled holes. B. Gently tap them in with a hammer or rubber mallet.
- Page 10 Step 4: A. Put the Hamper (A) back into the wall. B. Insert the four Screws (1) through the two holes, per side, of the Hamper and into the Plastic Anchor (2). C. Using an electric screwdriver or hand-held Philips screwdriver, secure all four Screws (1) into place.
- Page 11 Step 5: A. Clean up any dust and debris from the installation with a shop vac, and your Space-Saving, Built-In Hamper is ready to use.
-
Page 12: Warranty
Warranty Adir Corp (the “Company” or “Tiger Companies”) warrants to the purchaser that the product will be free from defects in workmanship and materials for a period of 1 year from the date of purchase. The warranty period is not extended if we repair, replace, exchange, or provide a refund for the product (as determined in our sole discretion). -
Page 13: Notes
Notes... - Page 14 ADI315-01-WHI © 2024 Adir Corp adircorp.com...
