Summary of Contents for DRY GEAR XL500
- Page 1 XL500 HEPA 500 Air Scrubber User Manual & Limited Warranty PLEASE READ BEFORE USE Purchased On: ______________ Purchased At: _______________ Serial Number: ______________...
- Page 2 0.3 microns. The XL500 utilizes up to 3 stages of filtration including a pre-filter, optional 2nd stage, and a HEPA filter. The XL500 will create cleaner air in any environment.
- Page 3 WARNINGS ALWAYS HANDLE WITH CARE TO AVOID CAUSING DAMAGE OR INJURY KEEP AWAY FROM OPEN FLAMES AND HEAT SOURCES DO NOT OPERATE THIS UNIT NEAR COMBUSTIBLE GASSES OR OTHER COMBUSTIBLE OR FLAMMABLE MATERIALS, INCLUDING BUT NOT LIMITED TO GASOLINE, SOLVENTS, THINNERS, OR NEAR ANY HEAT SOURCE, AS A MELTING UNIT MAY CAUSE FIRE OR OTHER ELECTRICAL HAZARD RESULTING IN SERIOUS INJURY NEVER ALLOW CHILDREN NEAR THIS UNIT...
- Page 4 Do not alter or modify this unit in any way. Alterations or modifications to this unit may void your warranty, if any. Use only replacement parts authorized by DRY GEAR. Failure to do so may void your warranty, if any.
- Page 5 Operating the XL500 Place the XL500 Air Scrubber upright on a level and stable surface with the handle up. Remove the dust cover. Plug the unit into a grounded 115-volt outlet with the correct voltage and amperage. For maximum protection against electrical shock, ALWAYS use a circuit that is protected by a ground fault circuit interrupter.
- Page 6 Open door by releasing sliding latches outward, away from the air scrubber body. Remove used filters and install new filters. Latch door closed and plug the unit in a grounded outlet before operating. XL500 Specifications Fan Speed: 500-2400 rpm Certifications: ETL, CE, SSA Motor Rating: .33 hp...
- Page 7 XL500 PARTS LIST Part Number Description Qty Req PJ-TT501 Removable Dust Cover PJ-TT502 Inlet Housing PJ-TT503 Housing PJ-TT504 Outlet Grill PJ-TT505 Airflow Guide PJ-TT506 1/3 HP Motor PJ-TT507 Motor Support PJ-TT508 Motor Seal Panel PJ-TT509 Switch Panel PJ-TT510 GFCI Panel PJ-TTYPC30 Power Cord - 30’...
-
Page 8: Troubleshooting
Troubleshooting ISSUE CORRECTIVE ACTION Unit does not turn on Switch not turned on – turn on Circuit breaker or GFCI has tripped - push reset button No power to scrubber – make sure unit is plugged in; check power supply Faulty switch - replace Unit starts and then shuts off Obstructed inlet/outlet –... -
Page 9: Limited Warranty
In no event will Dry Gear, its agents or assigns, be liable for loss of use of the product, loss of profits, direct damages, indirect damages, consequential damages, and/or incidental damages by reason of injury to any person, due to any defect or the malfunction of unit or any part(s) thereof, or for any other reason.
