Eclipse Home EHBG-36B Owner's Manual

Flat panel electric fireplace heater
Hide thumbs

Advertisement

Table of Contents

FLAT PANEL ELECTRIC FIREPLACE HEATER
Model#:
EHBG-36B
EHBG-60B
Wall Mounted / Built-in Electric Fireplace
WARNING
CAUTION
EHBG-45B
EHBG-65B
OWNER'S MANUAL
36"/45"/50"/55"/60"/65"/72"/100"
AC 220-240V 50Hz 1400-1600W
Read and understand this entire owner's manual, including all safety
information, before plugging in or using this product. Failure to do so could
result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
product away, make sure this manual accompanies this product.
EHBG-50B
EHBG-72B
EHBG-55B
EHBG-100B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EHBG-36B and is the answer not in the manual?

Questions and answers

Summary of Contents for Eclipse Home EHBG-36B

  • Page 1 FLAT PANEL ELECTRIC FIREPLACE HEATER Model#: EHBG-36B EHBG-45B EHBG-50B EHBG-55B EHBG-60B EHBG-65B EHBG-72B EHBG-100B OWNER’S MANUAL 36"/45"/50"/55"/60"/65"/72"/100" Wall Mounted / Built-in Electric Fireplace AC 220-240V 50Hz 1400-1600W Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could WARNING result in fire, electric shock, or serious personal injury.

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION! WARNING  Read all instructions before using this heater!  This heater is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. If provided, use handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the front of the heater, and keep them away from the sides and rear.

  • Page 3: Parts And Hardware

     ALWAYS turn this heater off before unplugging it from the outlet.  ALWAYS disconnect this unit from the power supply before performing any assembly or cleaning, or before relocating the electric fireplace.  NEVER leave this heater unattended. ALWAYS unplug this heater when not in use. ...

  • Page 4: Specification And Dimension

    Assemble with mantel Voltage 220V AC Watts 1600W Amps AMP Grounded Circuit PRODUCT DIMENSIONS Model Number 36" 21.46" 5.51" 32.48" 20.51" 12" 30.91" EHBG-36B 91.5cm 54.4cm 14cm 82.5cm 52.1cm 30.5cm 78.5cm 45" 21.46" 5.51" 39.88" 20.51" 12" 38.31" EHBG-45B 114.3cm 54.4cm...
  • Page 5 MINIMUM MANTEL CLEARANCES WARNING WHEN USING PAINT OR LACQUER TO FINISH THE MANTEL, THE PAINT OR LACQUER MUST BE HEAT RESISTANT TO PREVENT DISCOLOURATION.
  • Page 6 ( B ) STEP A. Selection a dry wall to open a hole for fireplace box. Size of hole as below chart Figure ( A ) Framing Hole Size Model Number EHBG-36B 33” (83.82CM) 20.75” (52.71CM) EHBG-45B 40” (101.6CM) 20.75” (52.71CM) EHBG-50B 47”...
  • Page 7 ( C ) STEP C. Take off the two screws in both sides of the glass panel. Figure ( C ) STEP D. Have two person to take the glass panel out of the fireplace box. Place it to a soft and clean place.

  • Page 8: Wall Mounted Installation

    Wall Mounted Installation Due to the many different materials used on different walls, it is highly recommended that you consult your local builder before you install this appliance on the wall. A.Select a location that is not prone to moisture and is located at least 36" (914mm) away from combustible materials such as curtain drapes, furniture, bedding, paper, etc.
  • Page 9 EHBG-72 / 65 / 100B Wall Bracket Illustrated Log set / Crystal / Pebble Ember Installation (NOTE:Please make the installation according to the embers which you bought or selected.) Glass front must be removed and the appliance must be mounted in its final location before the log set / crystal / pebble embers are installed.

  • Page 10: Operation

    Figure 1. Figure 2. Figure 3. (Crystal medias) Figure 3. (Pebbles medias) Operation Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could result in electric shock, fire, serious injury, or death.
  • Page 11 Before operating, please review the IMPORTANT SAFETY INFORMATION on Pages 2 and 3, and heed all warnings. Small remote control Touch Panel Touch Panel / Remote Control Operation BUTTON FUNCTION ACTION & INDICATION ON: Enables control panel functions and 1. Press once. Indicator light turns on. remote control.

  • Page 12: Care And Maintenance

    1. Press once. Indicator lights up. HEATER button: Turns heater on and off. Fan blows cool air for 10 seconds. 750W NOTE: The heater only works when the heater turns on and blows warm air. flame effect is on. If the flame effect is off, 2.
  • Page 13 Metal:  Buff using a soft cloth, slightly dampened with a citrus oil-based product.  DO NOT use brass polish or household cleaners as these products will damage the metal trim. Glass:  Use a good quality glass cleaner sprayed onto the cloth or towel. Dry thoroughly with a paper towel or lint-free cloth.
