- Page 1 OPERATION MANUAL OPERATION MANUAL JSHA-20 JSHA-20: S-Series Handheld Hydraulic Cutter Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. 2105 Corporate Dr Unit B Addison, IL 60101 Phone 800-860-6170 Fax 800-345-3767...
-
Page 2: Table Of Contents
REGISTRATION/ TABLE OF CONTENTS THANK YOU... Table of Contents for purchasing a Huskie Tools product. Our Registration/ Contents......2 mission is to supply the finest steel cable connecting and cutting tools and cable-related Warranty..........3 products to the transmission and distribution markets. -
Page 3: Warranty
WARRANTY Warranty Huskie Tools products carry a warranty that makes us a leader in the tool industry. No other manufacturer dares to back its tools as we do. All Huskie REC-SERIES battery operated products carry a 5 year warranty. The ECO-SERIES battery operated products carry a 1 year warranty. -
Page 4: Safety
SAFETY Wear eye protection: Safety Alert Symbol: when operating this tool. Failure to wear eye protec- tion could result in serious eye injury from flying debris. This safety alert symbol indicates a potential per- sonal injury hazard; it is not used for messages related to property damage only. - Page 5 JSHA-20 S-Series Huskie’s tools cut anything from guy wire* to anchor rod and most overhead and underground cables. The S-series cutters are portable, lightweight, and made to last years under the toughest field conditions. They feature a two stage pumping piston for rapid advance. The new S-240CC, S-32CC and SP-24CC hydraulic cutters were specially engineered to cut the toughest EHS guy wire, ground and anchor rods.
-
Page 6: Specifications
SPECIFICATIONS JSHA-20 Specifications Cutting Capabilities 6 Ton Output Wire Rope 20mm, 3/4” 6.5 lbs Weight Soft Steel Bolts 17mm, 11/16” 14” L Size Reba, Ground & Anchor 13mm, 1/2” Jaw Opening .75” Cu & Al Wire 20mm, 3/4” ACSR 20mm, 3/4” Standard Guy Wire 14mm, 1/2”... -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS CUTTING 1. Before cutting, make sure the material being cut is within the proper cutting capacity of the tool being used. 2. Open cutter head by lifting latch or removing lock pin, depending on the model being used. 3. -
Page 8: Operating Precautions
OPERATING PRECAUTIONS 1. Stay within the maximum limits of each tool as listed on page 6. 2. Try to keep the cutter head clean. When cleaning, use a spray lubricant to avoid a build up of dirt and sand which will damage the cutter head. 3. -
Page 9: Troubleshooting
TROUBLESHOOTING GUIDE 1. Problem: Small wire strands or pieces of cable or debris get jammed between the cutter head and blade, not allowing the blade to retract. Solution: A) Hold release lever down while tapping on the ram with a block of wood and a ham mer. If this does not work or tool continues to hang up, proceed to step B. - Page 10 MAINTENANCE AND INSPECTION 1. Daily maintenance is required to ensure that the tool is kept in good working condition. 2. Sharpen blades occasionally with a sharpening stone on the back side of the blades to remove any burrs that may occur. 3.
