Preface
Welcome to use Digital Multi-Channel Electrocardiograph Machine (hereinafter referred to as
ECG machine, also referred to as "product", "device", or "unit"). In order to enable you to
skillfully operate the ECG machine as soon as possible, we provide you this accompanying
manual with specific instructions for use. Please read it carefully when you install and use this
device for the first time. Be sure to keep this manual aside the device, if damaged or lost, please
contact the manufacturer for purchase.
This manual is owned by manufacturer, it is the reference material for purpose of the operation
and maintenance of electronic products, any other party may not disclose the contents of this
manual without written permission from manufacturer. All contents of this manual are regarded
as correct; manufacturer is not responsible for any accidental or consequential damage
because of wrongful installation or misoperation. Manufacturer is not providing or transferring
any privilege or copyrights. For any consequence by infringing copyright law or violating the
third party rights, manufacturer is not responsible.
Parts of the contents in this manual may be changed without notice.
The User Manual Version Number：1.0
Date of preparation：2021-03-10
