GEODE JASPER
Rugged Computer System
User Manual
Revision
Date
Comments
0.1
04/06/2024
Initial Version
Copyright 2024
FOR TECHNICAL SUPPORT
Diamond Systems Corporation
PLEASE CONTACT:
158 Commercial Street
Sunnyvale, CA 94086 USA
support@diamondsystems.com
Tel 1-650-810-2500
Fax 1-650-810-2525
www.diamondsystems.com
Advertisement
Table of Contents
Related Manuals for Diamond Systems GEODE JASPER
Summary of Contents for Diamond Systems GEODE JASPER
- Page 1 GEODE JASPER Rugged Computer System User Manual Revision Date Comments 04/06/2024 Initial Version Copyright 2024 FOR TECHNICAL SUPPORT Diamond Systems Corporation PLEASE CONTACT: 158 Commercial Street Sunnyvale, CA 94086 USA support@diamondsystems.com Tel 1-650-810-2500 Fax 1-650-810-2525 www.diamondsystems.com...
-
Page 2: Table Of Contents
J5 – USB3.2 C ........................25 ONNECTOR J2 - I/O C .......................... 26 ONNECTOR GEODE JASPER JUMPER CONFIGURATIONS ..............30 COM C ..................30 UMPERS ON ASPER ARRIER OARD JP1 ........................... 31 ... -
Page 3: Important Safe Handling Information
Check twice before applying power! Geode Jasper User Manual Revision A www.diamondsystems.com Page 3 of 33... -
Page 4: Description
DESCRIPTION Geode Jasper is a rugged COM Express Compact/Basic type 6 carrier board system with MIL . The carrier is designed to support a variety of COM Express modules to provide both rapid product line expansion with a variety of processors and long life by enabling simple replacement of the COM when the designed-in one becomes obsolete. -
Page 5: Operating System Support
Mechanical, Electrical, Environmental Form factor 9.84”x7.05”x3.74” Cooling Conduction Cooling Power input +12V DC / 9 to +36V DSC with Filter Circuit Operating Temp -40°C to +85°C Weight xxx lb Geode Jasper User Manual Revision A www.diamondsystems.com Page 5 of 33... -
Page 6: Product Images
Product Images Geode Jasper User Manual Revision A www.diamondsystems.com Page 6 of 33... -
Page 7: Key Subsystems
2. Using JMM-7525 external power filter board When on board power filter is used, the Geode Jasper can be powered from +12V DC typically. On otherway, Geode Osbourne can be powered from +9V to +36V when external JMM-7525 power filter is used. -
Page 8: Backup Battery
Backup Battery A 2032 coin horizontal battery holder is provided on Jasper Carrier board. The Geode Jasper can boot and function normally without a backup battery as well. RTC of Orin module backup voltage of 3V with 1.8V to 3.46V max is required. -
Page 9: Pci E Minicard Socket Usb
M2 2mm spacer which acts as nut for the Male to Female M2 4mm spacer provided as accessory. 3.10 USB The Geode Jasper supports 2x USB2.0 ports routed to rugged I/O connector J4. Two numbers of USB3.2 are also routed to the rugged USB connector J7. -
Page 10: Sata M.2 Socket
SPI interface. TPM can be used as a root of trust for platform integrity, remote attestation and cryptographic services. This feature will be supported based on the customer requirement and not implemented by default. Geode Jasper User Manual Revision A www.diamondsystems.com Page 10 of 33... -
Page 11: Expansion Io
I/O, and capability for use as counter/timer and PWM circuits. If this option is added, the signals are available on the rugged expansion IO connector J6. Geode Jasper User Manual Revision A www.diamondsystems.com Page 11 of 33... -
Page 12: Key Interfaces
From ALC892-CG Audio CODEC AUDIO – IN, OUT, MIC IN 1x I2C COMe Module Power Power Through external power filter (JMM- 7515) or through onboard power filter on rugged IO board Geode Jasper User Manual Revision A www.diamondsystems.com Page 12 of 33... -
Page 13: System Architecture
SYSTEM ARCHITECTURE Figure 1 provides an overview of the block diagrarm of the Geode Jasper system. Figure 1: System Architecture of Geode Osbourne Geode Jasper User Manual Revision A www.diamondsystems.com Page 13 of 33... -
Page 14: Geode Osbourne Mechanical Drawing And Feature Locations
GEODE OSBOURNE MECHANICAL DRAWING AND FEATURE LOCATIONS The form factor of the system is 9.5”x8.5”x3.85”. Figure 2: Mechanical outline, front view Figure 3: Mechanical outline, top view Geode Jasper User Manual Revision A www.diamondsystems.com Page 14 of 33... - Page 15 Figure 4: Mechanical 3D, side view Geode Jasper User Manual Revision A www.diamondsystems.com Page 15 of 33...
- Page 16 I/O CONNECTORS Following image shows the connector details on Geode Jasper system. Geode Jasper User Manual Revision A www.diamondsystems.com Page 16 of 33...
-
Page 17: J2 - Power Input (Power)
J2 - Power Input (Power) Geode Jasper provides D38999 series circular connector for power input. Connector pinout is as shown below: D38999 Pin no. Signal Ground Ground Geode system Connector type MIL D38999/20WC4PN connector Description Shell type Straight Plug Material... -
Page 18: J3 - Io Connector
J3 – IO Connector Geode Jasper provides four serial ports, Audio In, Audio Out, MIC ports and Expansion IO signals on to D38999 series circular connector. Connector pinout is as shown below: D38999 Pin no. Interface Signal Name TX/TX_P/RX_P RX/RX_P... - Page 19 Keying position Normal Keying Illustration Viewed from exterior Mating connector Connector type MIL D38999/26WE35PN Description Shell type Straight Plug Material Olive Drab Cadmium finish Plated Nickel Base Shell Size Insert Arrangement Geode Jasper User Manual Revision A www.diamondsystems.com Page 19 of 33...
- Page 20 Contact type Keying position Normal Keying Illustration Viewed from rear (terminal insertion side) Geode Jasper User Manual Revision A www.diamondsystems.com Page 20 of 33...
-
Page 21: J4 - Io Connector
J4 – IO Connector Geode Jasper provides two 1G Ethernet, two USB2.0, GPIO, I2C and power signals on to D38999 series circular connector. Connector pinout is as shown below: D38999 Pin no. Interface Signal Name GBE0_TR0_P GBE0_TR0_N GBE0_TR1_P GBE0_TR1_N GBE Port 1... - Page 22 Connector type MIL D38999/20KE35BN connector Description Shell type Straight Receptacle Material Olive Drab Cadmium finish Plated Nickel Base Shell Size Insert Arrangement Contact type Socket Keying position Normal Keying Geode Jasper User Manual Revision A www.diamondsystems.com Page 22 of 33...
- Page 23 Shell type Straight Plug Material Olive Drab Cadmium finish Plated Nickel Base Shell Size Insert Arrangement Contact type Keying position Normal Keying Illustration Viewed from rear (terminal insertion side) Geode Jasper User Manual Revision A www.diamondsystems.com Page 23 of 33...
-
Page 24: J7 - Hdmi Connector
J7 – HDMI Connector Geode Jasper provides HDMI interface signals which are terminated with SJT00RT12 series circular connector. Connector pinout is as shown below: D38999 Pin no. Signal HDMI_DP2_TX0_CON_P HDMI_DP2_TX0_CON_N GND_DIG HDMI_DP2_TX1_CON_P HDMI_DP2_TX1_CON_N GND_DIG HDMI_DP2_TX2_CON_P HDMI_DP2_TX2_CON_N GND_DIG HDMI_DP2_TX3_CON_P HDMI_DP2_TX3_CON_N GND_DIG... -
Page 25: J5 - Usb3.2 Connector
Viewed from rear (terminal insertion side) J5 – USB3.2 Connector Geode Jasper provides 2xUSB3.2 interface signals which are terminated with SJT00RT12 series circular connector. Connector pinout is as shown below: USB Port# D38999 Pin no. Signal USB3_VBUS USB D- USB D+ USB3.0 Port 1... -
Page 26: J2 - I/O Connector
The 1G Eth, 2x CAN, DIO, Audio, 4x Serial ports, 2x USB2.0 and Control Signals of the Geode System are terminated with a D38999 series circular connector. The connector pinouts are as shown below: D38999 Port Type Signal Pin no. GBE0_TR0_P GBE0_TR0_N 1G Ethernet Port GBE0_TR1_P GBE0_TR1_N Geode Jasper User Manual Revision A www.diamondsystems.com Page 26 of 33... - Page 27 Serial Port 3 (RS232) Serial Port 4 (RS232) SYS_RST_IN_N BUTTON_POWER_ON_N Power Signals FORCE_RECOVERY MEM_ERS I2C_CLK_3P3 I2C Signals I2C_ DAT_3P3 CAN0_H CAN1_L CAN Signals CAN0_L CAN1_H DIO_PA0 DIO_PA1 DIO Signals DIO_PA2 DIO_PA3 DIO_PA4 Geode Jasper User Manual Revision A www.diamondsystems.com Page 27 of 33...
- Page 28 Plated Nickel Base Shell Size Insert Arrangement Contact type Socket Keying position Normal Keying Illustration Viewed from exterior Mating connector Connector type MIL D38999/26WF35PN Description Shell type Straight Plug Geode Jasper User Manual Revision A www.diamondsystems.com Page 28 of 33...
- Page 29 Material Olive Drab Cadmium finish Plated Nickel Base Shell Size Insert Arrangement Contact type Keying position Normal Keying Illustration Viewed from rear (terminal insertion side) Geode Jasper User Manual Revision A www.diamondsystems.com Page 29 of 33...
-
Page 30: Geode Jasper Jumper Configurations
USB TO MPCIE/PCIE/104, input voltage selection Serial port mode selection DIO Voltage and PU/PD selection Serial Port 3 & 4 termination selection Serial Port 1 & 2 termination selection Geode Jasper User Manual Revision A www.diamondsystems.com Page 30 of 33... -
Page 31: Jumper Block Jp1
Note: 1. Base address must be selected based on COM module used with Jasper. 2. Whiskey Lake COM supports 0x240 and 0x280 base address. 3. Tiger Lake COM supports 0x240 base address. Geode Jasper User Manual Revision A www.diamondsystems.com Page 31 of 33... -
Page 32: Jumper Block Jp2
Port RS232 RS485 Internal Position RS422 Loop 1&2 OUT* 1&2 3&4 3&4 OUT* *Default Mode Note: Make sure 5V and 3V3 Jumper are not IN at same time. Geode Jasper User Manual Revision A www.diamondsystems.com Page 32 of 33... -
Page 33: Jumper Block Jp5
Position Function Serial Port1 TX Termination Enabled Disabled* Enabled Disabled* Serial Port1 RX Termination Serial Port2 TX Termination Enabled Disabled* Serial Port3 RX Termination Enabled Disabled* *Default Mode Geode Jasper User Manual Revision A www.diamondsystems.com Page 33 of 33...
