WAC Lighting InvisiLED Outdoor Installation Instructions Manual

INSTALLATION INSTRUCTION
InvisiLED Outdoor 100/200
T24-OD
SAFETY INSTRUCTION
IMPORTANT: NEVER attempt any work without shutting off the electricity.
•
Always turn off power at fuse box prior to installation to prevent electrical shock.
•
For installation and serviced by a qualified, licensed electrician.
•
Install in accordance with national electric code, and local regulations.
•
Consult with local inspector to assure compliance.
•
Do not submerge the tape into the water.
•
Only install with a WAC UL listed Class 2 24VDC LED power supply.
•
Do not connect the tape directly to high voltage power
•
Do not exceed maximum run recommended for each tape series
•
Do not connect the tape with 24VAC output Electronics transformer.
CAUTION
•
Read all instructions before installing.
•
Handle product with care.
•
Do not modify or disassemble product beyond instructions or warranty will be void.
•
Cutting anywhere other than the cut point will result in a damage to the tape light
•
Failure to follow safety warnings, and installation instruction will void the warranty
•
Tape light will begin to flash if maximum rated output power from WAC 24VDC power supply is overloaded.
Avoid contact with
sharp objects
Do not cover LED tape light
with any materials
Install on stable clean,
dry surface
Do not fold or twist LED Tape
Do not bend the tape
light to a diameter less
than 4 inches
Do not power the LED tape
while attached to the spool or
tightly coiled
Do not bend the tape
light on a horizontal
plane
1
