- Page 1 Stackable Battery Energy Storage System ESS48400-HSD8H2-R32 U S E R M A N U A L D A K O T A L I T H I U M . C O M...
-
Page 2: Table Of Contents
3.4. Definition of LED indicator lights 3.5. DIP address 3.6. Power On/Off 3.7. WiFi Monitoring Installation 3.8. Application solution for main power supply and photovoltaic Chapter 4: System Maintenance 4.1. Periodic maintenance 4.2. Storage and maintenance 4.3. Product cleaning Stackable Battery Energy Storage System ESS48400-HSD8H2-R32... -
Page 3: Chapter 1: Operation Guide
Thank you very much for choosing the Stackable Battery Energy Storage System (hereafter referred to as “ESS”) developed and produced by Dakota Lithium. Before installing and using this product, please carefully read and understand all the contents of this manual. If you have any suggestions during use, please feel free to contact Support@DakotaLithium.com. -
Page 4: Electric Safety
When the equipment is running, do not block the air vents or heat dissipation system, as it may cause high temperatures and cause fires. The operating life and service life of ESS are related to the operating temperature. It should be installed at a temperature equal to or better than the ambient temperature. Stackable Battery Energy Storage System ESS48400-HSD8H2-R32... -
Page 5: Chapter 2 Product Introduction
Chapter 2 Product Introduction 2.1 PRODUCT DESCRIPTION The Dakota Lithium Stackable Battery ESS household energy storage system adopts a modular design, including battery modules and inverter modules. The energy storage module adopts a Lithium iron phosphate battery with high performance and long service life. Each energy storage module is integrated with an intelligent BMS system internally, making it easy to expand and can be combined into up to 20.48KWh of battery capacity. -
Page 6: Product Appearance And Dimension
Each energy storage module is integrated with an intelligent BMS system internally, making it easy to expand, and can be combined into up to 20.48KWh battery packs. 2.4.1 BATTERY MODULE APPEARANCE 2.4.2 BATTERY MODULE PARAMETER Stackable Battery Energy Storage System ESS48400-HSD8H2-R32... - Page 7 DAKOTA LITHIUM STACKABLE BATTERY MODULE 2.4.3 BATTERY MODULE LCD OPERATION INSTRUCTIONS...
-
Page 8: Battery Module Lcd Operation Instructions
This series features advanced MPPT technology to maximize solar energy, a display screen and indicator light that dynamically displays system data and operating status, reduces no-load losses in power-saving mode, utilizes adjustable speed fans for efficient heat dissipation, and has comprehensive protection functions. Stackable Battery Energy Storage System ESS48400-HSD8H2-R32... -
Page 9: Inverter Module Appearance
2.5.1. INVERTER MODULE APPEARANCE PANEL DISPLAY Operation and display panel. It includes three indicator lights, four function buttons, and a LCD display to indicate the working status and input/output power information. 1. LCD display 2. status indicator 3. Charging indicator light 4. -
Page 10: Chapter 3: Equipment Installation
After installation, check if the equipment is stable and fixed; When handling any heavy objects, be prepared to bear the goods to avoid crushing or twisting; When handling equipment by hand, protective gloves should be worn to avoid injury. Stackable Battery Energy Storage System ESS48400-HSD8H2-R32... -
Page 11: Product Installation
3.3. PRODUCT INSTALLATION Unpacking inspection: Before opening the ESS outer packaging, check for obvious damage on the outer packaging and inspect the ESS. If there is any damage to the ESS packaging or model, please contact us as immeidately. (This manual is used for stacking energy storage ESS48400 with a capacity of 20.48KWh.). Inverter module size 695 * 453 * 200mm, base module size 691 * 453 * 115mm, battery module size 695 * 458 * 200mm. -
Page 12: Inverter Module Parameter
Use a Phillips head screwdriver to lock the outer baffle tightly. Pay attention to placing the wiring harness inside the baffle, and fasten the locking baffle from the first one on the ground, upward in sequence, until all the baffles are securely fastened. Stackable Battery Energy Storage System ESS48400-HSD8H2-R32... -
Page 13: Wiring
2.3.2. WIRING Before the electrical connection please ensure that the energy storage switch is in the “off” state. Otherwise, the high voltage of the ESS device may cause electric shock. Operations related to electrical connections must be carried out by professional electrical technicians. When making electrical connections, operators must wear personal protective equipment. - Page 14 (UL10269/8AWG wires for AC output must comply with the usage standards); Then connect the AC output terminal, correctly connect the AC output line, live wire, and zero wire; Stackable Battery Energy Storage System ESS48400-HSD8H2-R32...
-
Page 15: Definition Of Led Indicator Lights
AC Input Wiring Method: Before wiring, confirm that the WIRING OVERVIEW DIAGRAM external circuit breaker has been disconnected and whether the cable used meets the usage standards (UL10269/8AWG wire with AC input diameter must meet the usage standards); Connect the AC input terminal again, correctly connect the AC input wire, live wire, and zero wire;... -
Page 16: Dip Address
Other addresses and so on. 2. The host needs to be set to 0, and each pack needs to be set to 1-15. NOTE: DIP 5 and 6 are reserved, please do not dial them for normal use Stackable Battery Energy Storage System ESS48400-HSD8H2-R32... -
Page 17: Power On/Off
3.6. POWER ON/OFF PRE-STARTUP INSPECTION: Before starting, check if the wiring is connected correctly and firmly, especially if the ground wire contact is good, whether the positive and negative terminals of the battery input are reversed, whether the positive and negative terminals of the PV input are reversed, and whether the AC input terminal is incorrectly connected to the AC output terminal. -
Page 18: Chapter 4: System Maintenance
If the power supply is disconnected, the battery supplies power to the load through the power module. Chapter 4: System Maintenance 4.1. PERIODIC MAINTENANCE To ensure the long-term good operation of the energy storage system, it is recommended to carry out daily maintenance as described in this section. Stackable Battery Energy Storage System ESS48400-HSD8H2-R32... -
Page 19: Storage And Maintenance
4.2. STORAGE AND MAINTENANCE Do not let the ESS catch fire. Do not open or damage the ESS device. Electrolytes flowing from the ESS device are harmful to the skin and eyes. 1. ESS should be used with caution and damage to the ESS is strictly prohibited. 2. - Page 20 Stackable Battery Energy Storage System ESS48400-HSD8H2-R32 D A K O TA L I T H I U M . C O M I C O N TA C T: S U P P O RT @ D A K O TA L I T H I U M . C O M...
