Summary of Contents for Sola Single-Cell Aluminum Pergola
- Page 1 Installation Manual for Single-Cell Aluminum Pergola...
-
Page 2: Table Of Contents
Table of Contents Before Starting ......................... 2 Important Safety Guidelines ....................2 Tools Required ......................... 3 Part List ............................ 4 Step 1: Connect Posts to Length Beams .................. 6 Step 2: Install Width Beams ....................7 Step 3: Install Center Beam ..................... 8 Step 4: Anchor the Posts ...................... -
Page 3: Before Starting
Before Starting • This may take 3-5 hours. • Make sure you read and review this entire manual thoroughly before starting to assemble your pergola. • Verify that you have received all the parts listed on pages 3 and 4. Refrain from discarding any packaging until you have confirmed the presence of all components. -
Page 4: Tools Required
Tools Required • Work Gloves • Hard Hat • Safety Goggles • Hearing Protection • Utility Knife • Rubber Mallet • Tape Measure • Waterproof Silicone Sealant • Caulk Gun • Impact Drill • Rotary Hammer • Rotary Hammer M8 Drill Bit •... -
Page 5: Part List
Part List Parts Image Description Size code Post 6”x6” Post Base Plate 7.3”x7.3” M8 Wedge Anchor Bolt M8x ½” B1-B4 Beam (w/Gutter) 4.7”x6.7” Center Beam 5.1”x7.1” Louver 1.7”x7.1” 16-24 Connecting Rod 1”x0.6” Louver Slot Cap 32-48 Motor Base Motor Bracket Connection Motor Bracket Motor Cover Screw... - Page 6 Ceiling Fan LED Light Corner Top Cover Top Cover Screws M4x⅝”...
-
Page 7: Step 1: Connect Posts To Length Beams
Step 1: Connect Posts to Length Beams Parts Image code 32-48 1. Before starting, get an understanding of the layout of the location and which side you would like the motor positioned. This will determine the orientation of your pergola. By looking at the edge of the beam and how far the D3 Louver Slot (pre-installed) is to the edge compared to the other side, will tell you which side the louver will open from. -
Page 8: Step 2: Install Width Beams
Step 2: Install Width Beams Parts Image code 1. Insert the B1 and B3 Width Beams by loosening the D8 screws from the fasteners and sliding the beams into the grooves of the A1 Posts. Tighten the D8 Screws once the Beams are in place. -
Page 9: Step 3: Install Center Beam
Step 3: Install Center Beam Parts Image code 1. Install the B5 Center Beams into the D3 Louver slots as shown in the above figure. Pay close attention to the orientation of the B5 Center Beam. -
Page 10: Step 4: Anchor The Posts
Step 4: Anchor the Posts Parts Image code 1. Establish a fixed post by anchoring one of the posts using the A3 Wedge Anchor Bolts (Pre-drill holes into the concrete using a rotary hammer and a drill bit). 2. Next, measure each post for plumb with a level while also making sure the unit is square by measuring the distance between each of the posts. -
Page 11: Step 5: Install The Fan And Led Lights
Step 5: Install the Fan and LED Lights Parts Image code 1. Install the D10 Fan and the D11 LED Lights to the B5 Center Beam. Connect the fan to the fan rod Remove the solar Pass the fan rod through the center and lock with the pin panel cover hole in the center beam... -
Page 12: Step 6: Install The Louvers
Step 6: Install the Louvers Parts Image code 16-24 32-48 32-48 1. Snap both sides of the B6 Louvers into the D3 Louver Slots (pre-installed). NOTE: Pay attention to the orientation of the louver and you may need to use a rubber mallet to knock the Louvers into place. -
Page 13: Step 7: Mount The Motor
Step 7: Mount the Motor Parts Image code 1. Extend the D4 motor to its longest state. Plug the motor into the controller first and use the remote control to extend it. Afterwards, unplug the motor. 2. Attach the D4 motor to each D5 and D6 brackets. The front D6 Connecting Bracket is connected to the D1 Connecting Rod using the D8 Screws connected to the two screw fixtures that were left open in the previous step. - Page 14 4. Install the D7 Motor Cover and fasten it to the beam using D9 Hex Screws. 5. Connect the D4 Motor power cord to the controller. Controller 6. Affix the D12 Top Covers to the corners using the D14 Top Cover Screws.
-
Page 15: Remote Control Operating Instructions
Remote Control Operating Instructions Up/On Down/Off Fan Light Fan Speed Louvers Beam Light Roller Shade 3/4 Roller Shade 1/2 Turn on the Fan: Press the Fan Speed button. The fan speed indicator will light up on the LCD screen. Pressing the Up/On button will toggle through the 3 speeds of the fan.
