- Page 1 AquiTron AT-SD-LTE Speech Dialler BA S IC S E TU P A ND PR OG RA M M I NG...
- Page 2 SD-LTE Basic Set up - Programming and SIM Card Requirement (A Product Support Guide) Connections Supply voltage (Can be between 12 - 28VDC) 12v and 0v are normally used to power the SD-LTE this could be taken from the AUX (12v power) on an alarm control panel (These are the same terminals used to supply power the PIR detectors) or from a communicator wiring harness etc.
- Page 3 SIM Card for use with the SD-LTE SIM card - The SIM card must only be fitted/or removed when the SD-LTE is powered down. The SIM card needs to be a micro-SIM and registered to the required network. - The SIM Card should have the PIN Code disabled. - We would advise having a Contract SIM, although “Pay as you go”...
- Page 4 Installing the SIM Card Fit the SIM card into the SIM holder as shown by the icon on the bottom right of the photo below. Double check that you have fitted the SIM card in the correct orientation. NOTE: Take care when inserting the SIM not to damage the pins within the SIM Card holder – See “SIM Holder Undamaged and Damaged”...
-
Page 5: Antenna Installation
Antenna Installation The supplied antenna lead is 3 metre long, this should not be cut or extended. The antenna should be installed vertically with the lead halfway up, the lead should travel horizontally for 5-10cm before dropping down to connect to the SD-LTE. - Page 6 COM-ANT-02 (alternative antenna) COM-ANT-02 is compatible with all Eaton Security GSM and 4G dialers, communicators etc. The antenna = approximately 22cm. The cable is approximately 5 metre long. The COM-ANT-02 is supplied with an adapter cable (see photo below). The COM-ANT-02 is supplied with a right-angled mounting bracket and fixings.
- Page 7 Commissioning / Loading the Defaults When beginning a new installation, it is advisable to perform a factory reset of the SD-LTE unit to ensure that any existing settings are removed. Note: The initial power up sequence may take a few minutes, the SD-LTE will display “Starting…”...
- Page 8 Checking the Signal Strength The GSM Signal Strength can be checked from: - Test Options – Mobile Phone Phone Utils – Signal Strength: - Signal Strength Low ***** If “Not Registered” is displayed, this could be caused by one or more of the following: - The SIM Card is not registered.
- Page 9 Programming The SD-LTE should not take long for basic programming: - Contact Details (Person(s) that you wish to contact) NOTE: If you require voice AND Text messages to be sent, if would be advisable to select the Text Contacts first (Contact 01 etc.), and then the Voice contacts as later (Contact 02 in this example).
- Page 10 Messages (Voice) NOTE: The “Site” message should always be programmed this would normally be the address / location. In addition, the individual messages (A, B, & C etc.) can then be programmed if required; however, they are normally only required if you are triggering more than one input.
- Page 11 Messages (Text) NOTE: The “Site” message should always be programmed this would normally be the address / location. In addition, the individual messages (A, B, & C etc.) can then be programmed if required; however, they are normally only required if you are triggering more than one input.
- Page 12 Typical Operation As default the unit will typically respond as follow: - When triggered, the unit will call each number in numerical order and repeat a total of three time and then shut down. However, upon receiving a call, a person can acknowledge and shut down the calls by pressing the number eight (8) button on their phone.
- Page 13 SIM Holder Undamaged and Damaged The following photos will show: - Photo 1 - An undamaged SIM holder Photo 2 - A damaged SIM holder. Photo 1 The Sim holder is shown here with NO damage (the contact pins / levers are intact) : -...
- Page 14 Photo 2 The Sim holder is shown here WITH damage(the contact pins / levers have been snaped off): -...
- Page 15 Please note the above is not an official Eaton Security Business Document but has been written as an aid- memoir for the author. The information is believed to be correct but as with all programming and set-ups the system should be tested on site to ensure correct operation. This document may be subject to change without notification.
- Page 16 The only obligations of Aquilar Limited are those in the Aquilar Standard Terms and Conditions of Sale for this product, and in no case will Aquilar Limited be liable for any incidental, indirect, or consequential damages arising from the AquiTron is a trademark of AquiTron Limited Aquilar is a trademark of Aquilar Limited...
