- Page 1 MOVING HEAD ERA BEAM-150 LED MANUAL ENDLESS TILT DUAL OVERLAPPING PRISM LINEAR FROST www.light-inc.nl...
- Page 2 IP20 For indoor events Never look directly into the projecting lens when the fixture is switched on. The light can cause epileptic seizures in light-sensitive people or people with epilepsy. Extreme caution and compliance with these safety instructions are required, especially with beam effects.
- Page 3 2. INSTALLATION 2. INSTALLATION 2. INSTALLATION cord through the holes at the bottom of the base and around the truss. cord through the holes at the bottom of the base and around the truss. Rigging Rigging cord through the holes at the bottom of the base and around the truss. Rigging 1.
- Page 4 DMX terminator 3. SETUP AND CONFIGURATION Front panel operation DMX Address: System Settings:...
- Page 5 • Voice control: running the program set by the manufacturer is controlled by sound 6. Electronic light lighting: 7. Horizontal reverse: select “Open”, reverse the rotation direction of the Pan motor, select “Close”, and press the rotation direction at the factory 8.
- Page 6 4. OPERATION MENU 1. Address setting, 2. Setting, 3. Info , 4. Manual, 5. Status, 6. 7. Reset, 8. Level 1 Level 2 Level 3 Level 4 Content Address Setting 1 - 512 Dis_Reve Natu/Rev1 Language Engh/Chin 14CH/16CH RunMode DimCurve Squa/Pres/SCur/Line SETTING ShortCut...
- Page 7 Level 1 Level 2 Level 3 Level 4 Content Address Setting 1 - 512 Natu/Err Effect DMX Natu/Err Focus Hall Natu/Err Color Hall Natu/Err Gobo Hall Natu/Err STATUS Current status of lamps and lanterns Natu/Err Natu/Err Natu/Err NTC Temp Natu/Err Return CheckGod AD SET...
- Page 8 Level 1 Level 2 Level 3 Level 4 Content Address Setting 1 - 512 0-255 PanFine 0-255 Tilt 0-255 TiltFine 0-255 T-nonpolar 0-255 0-255 Strobe 0-255 Dimmer 0-255 DMX LEVEL Color 0-255 StaticGB 0-255 Prism 0-255 PrismRot1 0-255 PrismRot2 0-255 Frost 0-255 Focus...
- Page 9 DMX Channel Value Function Short mode Standard Mode Strobe Close Strobe: Slow->Fast 104-107 Open 108-207 Pulse strobe: Slow->Fast 208-212 Open Strobe at random: slow speed Strobe at random: medium speed Strobe at random: fast speed 252-255 Open Dimmer 0-255 0-100% Colors Open Open+Color1...
- Page 10 DMX Channel Value Function Short mode Standard Mode Gobo Open Gobo1 8-10 Gobo2 14-16 Gobo4 17-19 Gobo5 20-22 Gobo6 Gobo7 26-28 Gobo8 Gobo9 Gobo10 Gobo11 Gobo12 44-54 Open 55-62 Shake from slow to fast: Gobo 1 Shake from slow to fast: Gobo 2 71-78 79-86 Shake from slow to fast: Gobo 4...
- Page 11 14colors, each code no. stands for one color, colors start Color wheel from red and so on 50502-00164 50502-00165 50502-00166 50502-00167 50502-00168 50502-00169 50502-00170 Fixed gobo wheel 70502-00015 Switching power supply 50400-00016 Light Source 50201-00019 LED drive power supply 50400-00041...
- Page 12 Light source: 150W white led engine Input power: Color temperature: 7800k±200k Power factor: Rated life: pf>0.90 Color Fixed gobo wheel 1 white light + 14 colors. • Variable speed bidirectional rainbow effect • • Step/linear conversion color optional • •...
- Page 13 • High temperature and anti-uv abs and aluminum Dimmer /strobe • IP Rating • 0-100% linear dimmer • IP20 Head movement Net weight • Pan 540º • 10.2 kg • Operation temperature Beam angle • • 2° Light Output Dimensions...
- Page 14 9. TROUBLE SHOOTING Problem Action Check the fuse on the power socket. Check the lamp. to the controller Make sure the fan is working well or fans and their shields are not blocked. Make sure the LED is within its lifespan. Beam appears dim, Low in brightness Remove dust or grease from the lenses.
