Lumos X-Loupe AgileLite User Manual

X-Loupe
About this product
The main component of AgileLite system include
AgileLite Ring; all the main component come with a ring magnet mount, is easily and
quickly used in combination with camera.
For more information and downloading this manual, please visit our website at
www.x-loupe.com. Please read the copyright declaration prior to the usage of
any part of the content in this booklet.
X-Core (Plus) Control unit
Display Switch
Segment Dimming
control control
Power
Press 2 secs
to turn on / off
Battery check **
Segment display
**Battery percentage:
It is to display the actual battery percentage
only after completing the assembly of the
AgileLite Ring / 4X4 Barrel
Illumination setting
Step1
switch the 【Channel Switch】to【W】for white light / inner circle
Step2
Segment Control Setting
Set the 【Display Switch】to【
move 【Adjustment lever】leftwards /
rightwards, in turn to change the lighting
position by quadrant order; lighting
modes are shown in turn as below.
full ring
Right half only
Diagonal
upper left /
lower right
Left half flashing
upper right only
[Notice]:
1. are on the mode of 1:2 brightness ratios, the blink indicates the brightness is lower.
~
2.lighting mode in use: X-Core with 11-segment lighting modes (
X-Core Plus with 15-segment lighting modes (
3.*Dimming intensity: X-Core: 1~100% with 5-step dimming
X-Core Plus: 10~100% with 10-step dimming
®
AgileLite System User Guide 2024
control unit: X-Core (or X-Core Plus);
Channel Switch
【W】= white light
【F】 = functional light: Blue light
Move leftwards / rightwards in turn
Segment control / Dimming control
Channel display
【Main】
【Sub】
Status Display
【F】for functional light / outer circle
Dimming Control Setting
Set the 【Display Switch】to
】,
】, move
【
leftwards / rightwards, in turn to
regulate the lighting intensity.
left half only
Under half only
Right half flashing
Upper half flashing
lower right only
(or Green light)
Adjustment Lever
for adjusting the
For FUJIFILM cameras)
(
: W channel intensity*
: F channel intensity*
【Adjustment lever】
Upper half only
Diagonal
upper right /
lower left
1
Under half flashing
2
upper left only
lower left only 3
4
~ )
~ )
5
Product parts
and assembly diagram
X-Core (Plus)
Control unit
FUJIFILM camera X-T30
+ XF60mm F2.4R Macro Lens
Adapter ring
Align the mark on one side of the【Adapter
ring】with the white line on the lens, and
then rotate to connect with the lens; the
other side of the Adapter ring is magnetic
and can be firmly attached to the
AgileLite Ring light when close by.
AgileLite Ring Assembly
Take the camera, mount the Adapter ring on the
camera lens port.
Mount the X-Core (Plus) to camera accessory shoe, and
screw the locking ring in clockwise direction to tighten.
Put the camera assembly directly connect to the end of
AgileLite Ring; it will be firmly attached with the magnetic
power by the ring magnet mount on the barrel end.
Connect the charge-only sync & charge cable on
AgileLite Ring to the connection port on X-Core (Plus).
Rotate the barrel until the symbol
camera accessory shoe. ( This step is to set the
illumination regions right on the quadrant position)
AgileLite Ring
align to the
