- Page 1 MINIX IPC RIC SJ64 Series User Manual Version 1.0 Published 2023 Copyright 2023 Minix Technology Ltd. All rights reserved.
- Page 2 COPYRIGHT The documentation and the software included with this product are copy- righted 2021 by MINIX Technology Ltd. All rights are reserved. MINIX Technol- ogy Ltd. reserves the right to make improvements in the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of MINIX Technology Ltd.
-
Page 3: Table Of Contents
CONTENT Chapter 1 Introduction 1.1 Initial Inspection -----------------------------------------------------------------------------1 1.2 Product Specification ---------------------------------------------------------------------2 1.3 System Overview and Dimensions ---------------------------------------------------3 1.3.1 Front View -------------------------------------------------------------------------------3 1.3.2 Rear View -------------------------------------------------------------------------------3 Chapter 2 Installation of Components 2.1 Installation SSD & Memory -------------------------------------------------------------6-7 2.2 Installation M.2 B-Key Card --------------------------------------------------------------8 2.3 Installation Mounting Bracket -----------------------------------------------------------9 Chapter 3 BIOS Setup Utility 3.1 Introduction ----------------------------------------------------------------------------------11... -
Page 4: Chapter 1 Introduction
CHAPTER 1 Introduction RIC SJ64... -
Page 5: Initial Inspection
1.1 Initial Inspection Before you begin installing your computer, please make sure that the following materials have been shipped. 1. 1 x RIC SJ64 series device 2. 1 x Power Adapter 3. 2 x Antennas 4. 1 x VESA Mount 5. -
Page 6: Product Specification
1.2 Product Specification Intel® Celeron® J6412 Processor (up to 2.60GHz) Processor Single 260-pin DDR4 SO-DIMM Socket, Supports Up to System Memory 32GB DDR4 3200MHz (non ECC Supported) Nuvoton NCT6126D I/O Chipset AMI BIOS,128M-bit SPI Flash ROM BIOS Information Programmable 1~ 255 sec, support system reset Watchdog Timer Infineon_ SLB9670VQ2.0 TPM 2.0... -
Page 7: System Overview And Dimensions
1.3 System Overview and Dimensions 1.3.1 Front View RIC SJ64... -
Page 8: Rear View
1.3.2 Rear View RIC SJ64... -
Page 9: Chapter 2 Installation Of Components
CHAPTER 2 Installation of components RIC SJ64... - Page 10 2.1 Installing SSD & Memory Step1. Remove 4 screws from the bottom of your system and take it off. Step2. Properly install the memory modules and press until properly seated. Step 3, Place back the cover and fasten 4 screws back to complete. RIC SJ64...
- Page 11 2.2 Installing 4G/5G Module Note: 4G/5G module is not included. Step 1. Remove the installed Wi-Fi module. Then install the bearing pad and the screw, so that the 4G/5G module can be installed. RIC SJ64...
- Page 12 Step 2. Insert 4G/5G module (M.2 B-Key card) into designated locations and fasten with the screws to complete installation. RIC SJ64...
- Page 13 2.3 Installing Mounting Bracket Step1. Remove 4 screws from the side. Step2. Insert and fasten screw on each side of the system to secure Mounting Bracket. RIC SJ64...
-
Page 14: Chapter 3 Bios Setup Utility
CHAPTER 3 BIOS Setup Utility RIC SJ64... -
Page 15: Introduction
3.1 Introduction This section explains how to use the BIOS SETUP UTILITY to configure your system. The BIOS chip on the motherboard stores the BIOS SETUP UTILITY. You may run the BIOS SETUP UTILITY when you start up the computer. Please press <Del> during the Power-On-Self-Test (POST) to enter the BIOS SETUP UTILITY, otherwise, POST will continue with its test routines. - Page 16 Serial Port 2 Configuration: Serial Port :[Enabled], [Disabled] COM Port Mode Setting :[RS232], [RS422], [RS485 TX] Device Settings :[IO=3F8h; IRQ=4;] Change Settings :[Auto], [IO=3F8h; IRQ=4;], [IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;] [IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;] [IO=3E8h;...
-
Page 17: Hardware Monitor
3.4 Hardware Monitor To check out the status of the device, go to BIOS > ‘Advanced’ > ‘Hardware Monitor’. Real time status of these information is available: [CPU temperature], [SYS temperature], [+5V], [Memory Vol] and [VCORE]. 3.5 FPANEL3 2.54mm port G3 specifies what state to go to when power is re-applied after a power failure. -
Page 18: Network Stack
3.7 Network Stack: Location: BIOS > ‘Advanced’ > ‘Network Stack Configuration’. This option is ‘Disabled’ by default. When ‘Enabled’, it allows you to set up below options: IPv4 PXE Support :[Disabled], [Enabled]. IPv4 HTTP Support :[Disabled], [Enabled]. IPv6 PXE Support :[Disabled], [Enabled]. -
Page 19: Chapter 4 Installation Of Os/Bios
CHAPTER 4 Installation of OS/BIOS RIC SJ64... -
Page 20: How To Install Linux Based
MINIX provide 2 kinds of operating system (OS) for users, they are Windows OS and Linux based OS. Also, we provide alternative BIOS versions. This chapter is about how to install the OS and flash the BIOS. 4.1 How to install Linux based OS. - Page 21 2) Choose the first one, and wait for a couple of seconds. 3) Choose a language for the OS. English is choosed here to make this instruction. 4) Choose a keyboard layout. RIC SJ64...
- Page 22 5) Choose ‘Start_Clonezilla Start Clonezilla’. work with disks or partitions using images’. 6) Choose ‘device-image Use local device (E.g.: hard drive, USB drive)’. 7) Choose ‘local_dev RIC SJ64...
- Page 23 8) Press ENTER key to continue. 9) Insert USB Drive B to RIC SJ64 device. This window will be refreshed automatically. When the USB Drive B is listed here, press combination key [Ctrl-C] to continue. 10) Choose USB Drive B. USB Drive B in this picture is ‘sdb1’.
- Page 24 11) Choose ‘no-fsck Skip checking/repairing the file system before mounting’. 12) Press [TAB] key to choose ‘Done’, and press ENTER. 13) Press ‘Enter’ to continue. RIC SJ64...
- Page 25 Expert mode: Choose your own options’. 14) Choose ‘Expert Restore_an_image_to_local_disk’. 15) Choose ‘restoredisk 16) The Ubuntu OS file is detected in this step. Choose it and continue. RIC SJ64...
- Page 26 17) Choose a disk where Ubuntu will be installed. ‘sda’ is the only disk on the RIC SJ64 device, so it is the only item here. 18) Choose the first one: ‘Reinstall grub in client disk MBR (only if grub config exists)’. Create partition table pproportionally’.
- Page 27 20) Choose ‘Yes, check the image before restoring’. 21) Choose ‘-p reboot Reboot’. 22) Press ‘ENTER’ to continue. RIC SJ64...
- Page 28 23) Now, it begins to install the Ubuntu OS. 24) A couple of minutes latere, it requires you to confirm. Just type ‘y’ and press ‘ENTER’. 25) Type ‘y’ and press ‘ENTER’ again. RIC SJ64...
- Page 29 26) Just wait a couple minutes until it finishes installing Ubuntu OS. Then the device will automatically restarted. Please note, if the Ubuntu is not properly started, go to the BIOS by pressing DEL key when you attempt to power on the RIC SJ64. Go to the ‘Boot’...
-
Page 30: How To Install Windows
4.2 How to install Windows OS 4.3 How to Flash the BIOS RIC SJ64...
