- Page 1 YORAHOME CROSSRIVER/SILVERBACK BENCHTOP CNC ROUTER 6060 VFD SPINDLE INSTALLATION Version 1.0 • January, 2024...
- Page 2 Purpose This Manual is intended for fitting the YoraHome VFD Spindle to the YoraHome SilverBack or CrossRiver Benchtop CNC Router; replacing the original 48VDC spindle motor. This manual is designed to cover this process only, and is not a complete manual.
- Page 3 Contents Part 1: Packing List Part 2: Mechanical Assembly Part 3: VFD Operation Part 4: FAQs...
-
Page 4: Packing List
Part 1 Packing List Item Picture Quantity Spindle Motor - 1.5kW Variable Frequency Drive (VFD) Silicone Tubing... - Page 5 Part 1 Packing List Item Picture Quantity Submersible Water Pump Spindle Cable Power Cord...
- Page 6 Part 1 Packing List Item Picture Quantity Wrench Set - 13/15mm & 14/17mm ER11 Collet Set - ⅛” & ¼”...
- Page 7 Part 1 Packing List Customer Supplied Items The following items are NOT included in the kit, and must be provided by the customer. ● Water Reservoir - a standard 5 gallon bucket will provide ample water storage for the system. A lid for the reservoir is highly recommended to prevent water contamination.
- Page 8 Part 2 Mechanical Assembly Preliminary Steps ● For ease of access, position the X axis near the middle of the machine; and the Y axis towards the front of the machine. ● After setting position, ensure that the Controller is turned off and the power cord unplugged.
- Page 9 Part 2 Mechanical Assembly Spindle Mount Installation ● If using this kit with the CrossRiver CNC, follow Step 1(CR) and Step 2(CR), starting on the Page 10. ● If using this kit with the SilverBack CNC, follow Step 1(SB), Step 2A(SB), Step 2B(SB), and Step 2C(SB), starting on Page 12.
- Page 10 Part 2 Mechanical Assembly Step 1(CR) - Removal of Stock Spindle/Holder Remove the 4 M5 screws which attach the stock Spindle and Holder to the Z axis faceplate. These screws will not be re-used; retain for reinstallation, if desired. Ensure that the spindle motor is supported during this process, to prevent damage to the brush holders.
- Page 11 Part 2 Mechanical Assembly Step 2(CR) - Install 80mm Spindle Holder Using M5x16mm Socket Head Screws (supplied with the original CrossRiver Hardware); attach the 80mm Spindle Holder to the Z axis faceplate. Note the 80mm Spindle Holder will only fit in one set of mounting holes on the faceplate;...
- Page 12 Part 2 Mechanical Assembly Step 1(SB) - Removal of Stock Spindle/Holder Remove the 4 M5 screws which attach the stock Spindle and Holder to the Z axis. (Top 2 screws shown in this picture) These screws will not be re-used; retain for reinstallation, if desired.
- Page 13 Part 2 Mechanical Assembly Step 2A(SB) - Install 80mm Spindle Holder The 80mm Spindle Mount for the SilverBack includes a mounting plate, spacers, and hardware: ● (4) M5x20 Socket Head Screws ● (4) M5x25 Socket Head Screws ● (4) M5 Flat Washers ●...
- Page 14 Part 2 Mechanical Assembly Step 2B(SB) - Install 80mm Spindle Holder Using M5x25mm Socket Head Screws, Mounting Plate, and Spacers; attach the Mounting Plate to the Z axis. The Mounting Plate should be oriented with the Spindle Mount holes towards the bottom of the plate.
- Page 15 Part 2 Mechanical Assembly Step 2C(SB) - Install 80mm Spindle Holder Using M5x20mm Socket Head Screws, Flat Washers, and Spring Washers; attach the 80mm Spindle Mount to the Mounting Plate.
- Page 16 Part 2 Mechanical Assembly Step 3 - Install Spindle Motor Install the Spindle Motor in the holder, ensuring that the motor is supported safely (NOTE - Motor Weight is approximately 8 lbs/3.6 kg). Tighten the thumb screw to secure the Spindle Motor - height can be adjusted as needed.
- Page 17 Part 2 Mechanical Assembly Step 4 - Motor Tubing Connections Remove the 2 compression fittings from the tubing connectors (14mm wrench). Remove the black protective covers that are on the tubing connectors.
- Page 18 Part 2 Mechanical Assembly Step 4 - Motor Tubing Connections Slide a compression fitting over one end of one of the lengths of tubing, as shown. Repeat with the other compression fitting, and other length of tubing.
- Page 19 Part 2 Mechanical Assembly Step 4 - Motor Tubing Connections Push the end of the tubing onto the fitting on the motor. Ensure that the end of the tubing sits flush against the shoulder on the fitting, as shown.
-
Page 20: Part 2 Mechanical Assembly
Part 2 Mechanical Assembly Step 4 - Motor Tubing Connections Slide the compression fittings down onto the fittings, and tighten securely (14mm wrench). Note in the picture that when the fitting is tight, you will not be able to see any exposed threads on the fitting, and the barbed fitting will be barely visible above the compression fitting. - Page 21 Part 2 Mechanical Assembly Step 5 - Pump Tubing Connection Route both lengths of tubing through the lid of the water reservoir. Attach one length of tubing to the pump outlet fitting as shown; the other length of tubing simply needs to be permitted to flow into the reservoir (can be secured with cable ties if desired).
- Page 22 Part 2 Mechanical Assembly Step 6 - Pump Test / Leak Check Add distilled water to the reservoir; if antifreeze is required, use RV antifreeze as noted in Part 1 (Packing List - Customer Supplied Items) Route pump power cord through hole in reservoir lid, and plug into a standard 120VAC outlet.
- Page 23 Part 2 Mechanical Assembly Step 7 - Motor Cable Connections Connect the 4-pin connector of the motor cable to the Spindle Motor. Cable connector has indexing points, and will only attach to the Spindle Motor in one orientation. Secure cable with threaded lock ring.
- Page 24 Part 2 Mechanical Assembly Step 7 - Motor Cable Connections Connect the 3-pin connector of the motor cable to port on the rear of the VFD Enclosure. Cable connector has indexing points, and will only attach to the VFD Enclosure in one orientation.
-
Page 25: Vfd Operation
Part 3 VFD Operation General Usage Frequency Range Display (Showing 0.00 - Not running) Ensure software is set to use Manual Spindle Control. VFD Speed Adjuster To start spindle, press the “RUN” green button and adjust speed. To stop spindle, press the “STOP” red button. - Page 26 Q. What if we have missing or broken parts? A. Please notify: support@yorahome.com Q. Where can I find additional resources for the YoraHome VFD Spindle Kit, CrossRiver, or SilverBack CNC Router? A. In our Blog https://yorahome.com/blogs/news, Knowledge Base https://my.yorahome.com/, and Facebook...
- Page 27 https://Facebook.com/groups/YoraHome.CNC...
