Summary of Contents for YEYIAN MA Series

  • Page 2 WELCOME TO YEYIAN A NEW LEVEL IN THE WORLD OF GAMING You’re one of millions upon millions of gamers. You can be socially engaged, sporty, an explorer, a soldier, a builder or a strategist. All of these archetypes require supernatural reflexes, powerful machines, consistency and a strong tolerance to being defeated hundreds upon hundreds of times before the fun kicks in.
  • Page 3 CAUTION Keep the monitor away from water sources or damp places, such as bathrooms, kitchens, basements and swimming pools. Make to place the monitor on a flat surface. If the monitor falls down, it could lead to injury or damage to the device. Store and use the monitor in a cool, dry and well-ventilated place, and keep it away from emission and heat sources.
  • Page 4: Package Contents

    PACKAGE CONTENTS Please check that the package for the monitor contains every part. If any part is lost, please contact the distributor. The color and shape of the parts may vary with models. Figures in this User Manual are for reference only. Wires supplied may vary depending on the purchased products.
  • Page 5: Installation Steps

    INSTALLATION STEPS Take out the bracket, align it with the interface on the back of the display, insert four screws and tighten it with a screwdriver; Insert the base interface into the bracket, insert a screw, and tighten it; finally put the decorative plastic cover in and fasten.
  • Page 6: Connection Steps

    CONNECTION STEPS Video • Connect the power cord. • Connect the signal line to the PC. • Press the power switch, the power indicator light is on. (Blue light when power on, blue light flashes when standby, no light when power off) •...
  • Page 7: Operation

    OPERATION Button Icon Button Description Activates OSD menu or function adjustment Menu confirmation < Preset mode Select menu up or right to adjust function > Signal switch Select menu down or left to adjust function ® Return/Exit Menu return or exit Power switch Switch monitor power...
  • Page 8 OSD MENU Input source [the Image below Is for reference only. Vendor needs to share the accurate osd Image] 1920*1080@280Hz 1920*1080@280Hz 1920*1080@280Hz...
  • Page 9 FCC Caution: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 10 TE DAMOS LA BIENVENIDA A YEYIAN UN NUEVO ESTÁNDAR EN GAMING DE NIVEL MUNDIAL Ahora formas parte de la comunidad de millones de gamers en el mundo. Puedes ser sociable, deportista, o tener espíritu guerrero, explorador, constructor o estratega. Todas de estas facultades requieren reflejos sobrenaturales, máquinas poderosas, consistencia y una fuerte tolerancia a sufrir cientos de derrotas a manos de otros jugadores antes de que comiences a divertirte.
  • Page 11 PRECAUCIÓN Mantenga el monitor alejado de fuentes de agua o lugares húmedos, como baños, cocinas, sótanos y piscinas. Procure colocar el monitor sobre una superficie plana. Si el monitor se cae, podría provocar lesiones o daños en el aparato. Guarde y utilice el monitor en un lugar fresco, seco y bien ventilado, y manténgalo alejado de fuentes de emisión y calor.
  • Page 12: Contenido Del Empaque

    CONTENIDO DEL EMPAQUE Por favor, compruebe que el paquete del monitor contiene todas las piezas. Si falta alguna pieza, póngase en contacto con el distribuidor. El color y la forma de las piezas pueden variar según el modelo. Las figuras de este Manual del usuario son sólo de referencia.
  • Page 13: Pasos Para La Instalación

    PASOS PARA LA INSTALACIÓN Saque el soporte, alinéelo con la interfaz de la parte posterior de la pantalla, inserte cuatro tornillos y apriételos con un destornillador; inserte la interfaz de la base en el soporte, inserte un tornillo y apriételo; por último, coloque la cubierta de plástico decorativa y fíjela.
  • Page 14 PASOS DE CONEXIÓN Video • Conecta el cable de alimentación. • Conecte la línea de señal al PC. • Pulse el interruptor de encendido, la luz indicadora de encendido se enciende. (Luz azul al encender, luz azul intermitente en modo de espera, sin luz al apagar). •...
  • Page 15: Operación

    OPERACIÓN Botón Icono Descripción del botón Activa el menú OSD o la confirmación de ajuste de Menú funciones Modo Seleccione el menú arriba o derecha para ajustar la < preestablecido función Seleccione el menú hacia abajo o hacia la izquierda >...
  • Page 16: Menú En Pantalla (Osd)

    MENÚ EN PANTALLA (OSD) Fuente de entrada [the Image below Is for reference only. Vendor needs to share the accurate osd Image] 1920*1080@280Hz 1920*1080@280Hz 1920*1080@280Hz...
  • Page 17 Precaución FCC: Este dispositivo cumple la parte 15 de las normas de la FCC. Su funcionamiento está sujeto a las dos condiciones siguientes: (1) Este dispositivo no puede causar interferencias perjudiciales, y (2) este dispositivo debe aceptar cualquier interferencia recibida, incluidas las interferencias que puedan causar un funcionamiento no deseado.
