Page 1 APERIO INTEGRATION INSTALLATION MANUAL IM2_ENG_REV0124_APERIO_INTEGRATION...
Page 2: Table Of Contents
12.2.READER ASSOCIATED TO HANDLE ..........................25 12.3. OTHERS ....................................25 13.MORE INFORMATION ABOUT THE SYSTEM OR EQUIPMENT .................... 26 13.1.MEANING OF THE LED STATUS ON THE HUBS ......................26 13.2.MEANING OF THE LED STATUS ON THE HANDLES ....................26 www.golmar-seguridad.es...
Page 3: Introduction
- The connection between the controller and the hub will be via RS485 bus. - The communication between the hub(s) and the handle(s) is done wirelessly. The maximum distance between the hub and the far- thest handle will be 20m (distance subject to optimal conditions: no obstacles, no interference, ...). www.golmar-seguridad.es...
Page 4: Topologies
12vdc power supply STAR CONNECTION HUB nº1 HUB nº4 GREEN GREEN 8-24VDC 8-24VDC aperio aperio HUB nº2 HUB nº5 GREEN GREEN 8-24VDC 8-24VDC aperio aperio HUB nº3 HUB nº6 GREEN GREEN 8-24VDC 8-24VDC aperio aperio 12vdc power supply www.golmar-seguridad.es...
Page 5: Maximum Distances And Elements
- The maximum distance between the hub and the farthest handle will be 20m (distance subject to optimal conditions: no obstacles, no interferences, ...). It is possible to use the 500ZB-EXTANT external antenna to better focus the coverage of the AH30. See the "HUBS LOCATIONS" chapter of this manual. www.golmar-seguridad.es...
Page 6: Handle Mounting
"H100 Installation Instructions" and "Lock Installation Instructions" with descriptive illustrations of the steps to be performed, as well as the assembly videotutorial. IMPORTANT In case you are not familiar with handle assembly, please trust this task to a locksmith. www.golmar-seguridad.es...
Page 7: Hubs
(hub on the roof and center of the room with external antenna) would be the option that would allow communication with all the handles. Cover a corridor EXAMPLE 1 EXAMPLE 2 Range covered by hub 1 Range covered by hub 2 www.golmar-seguridad.es...
Page 8 In this way, it is possible to define the most appropriate area for its placement (area with lower or weaker signals emission), as well as to adjust the hub to emit on channels that are not being used by other equipment or systems. www.golmar-seguridad.es...
Page 9: Hub Addressing
Hub nº12 Hub nº13 Hub nº14 Hub nº15 Hub nº16 Hub nº17 Hub nº18 Hub nº19 Hub nº20 Hub nº21 Hub nº22 Hub nº23 Hub nº24 Hub nº25 Hub nº26 Hub nº27 Hub nº28 Hub nº29 Hub nº30 Hub nº31 www.golmar-seguridad.es...
Page 10: Hub Connection
- The terminal board associated with the handle cannot be used, meaning that authorized access activates the handle but not the relay contact; if a reflex is generated, it must be to act on the relay contact of a door not occupied by a handle. www.golmar-seguridad.es...
Page 11: Connection Diagrams
- It is essential to use the same power supply from the controller to power the hubs. - Assign a different address to each hub. - Make sure that the end-of-line (DIPS 6 and 7 are ON) on the last hub. - Do not remove the end-of-line (EOL) jumper from the controller. www.golmar-seguridad.es...
Page 12 - It is essential to use the same power supply from the controller to power the hubs. - Assign a different address to each hub. - Make sure that the end-of-line (DIPS 6 and 7 are ON) on all hubs. - Do not remove the end-of-line (EOL) jumper from the controller. www.golmar-seguridad.es...
Page 13 - In case of having different controllers in the installation, each of them must be connected to the router or switch of the installation. - The address assignment of the hubs must be done in each of the serial lines. IMPORTANT: Do not combine star and serial installations on the same RS485 bus. www.golmar-seguridad.es...
Page 14 - In case of having different controllers in the installation, each of them must be connected to the router or switch of the installation. - The address assignment of the hubs must be done in each star connection made. IMPORTANT: Do not combine star and serial installations on the same RS485 bus. www.golmar-seguridad.es...
Page 15: Aperio Devices Pairing
- Encryption key file. A valid .XML file is required to run Aperio Programming Aplication. The .XML file will be provided by Golmar, this file acts as an encryption key for secure communication with Aperio systems. This encryption key must be handled with the same care as a Master Key in a traditional Master Key System, do not allow unauthorized personnel to access the encryption key.
Page 16 In case the dongle is not detected the software will display this other at the bottom: If the dongle does not have the latest version, it will ask to be updated. 4) Once the dongle is detected, click on the "Quick scan" option to detect the Aperio devices. www.golmar-seguridad.es...
Page 17 INTEGRACIÓN APERIO It will then display the detected elements (the following image shows the detection of an AH30 HUB). 5) Default hub configuration. www.golmar-seguridad.es...
Page 18 INTEGRACIÓN APERIO 6) Pairing of handle with hub. Successful pairing will display the following. www.golmar-seguridad.es...
Page 19 INTEGRACIÓN APERIO 7) Switch to customer mode" configuration of both hub/s and handle/s. Below is an image of a hub with two paired handles. www.golmar-seguridad.es...
Page 20: Ip Opener Configuration
1) Activate "Wireless locking device" in the feature menu. 2) It will then be necessary to associate APERIO integration activation cards to the controllers. 3) Navigate to the "Equipment & settings", then to "Wireless locking devices" menu and click on the "Creation by detection" option.
Page 21 NOTE: It is recommended to search using the "Creation by detection" option whenever possible. Below is an image of the manual search for a hub. 4) Set the priority level for "electronic locks" to priority value 5 or higher. www.golmar-seguridad.es...
Page 22 In case it does not match, modify in iP Opener the address by pressing the pencil and changing the EAC address value. 6) Access the settings of the added handle(s) (previous settings menu) and associate handle lock to the door reader that will control it. www.golmar-seguridad.es...
Page 23 7) Check that the association has been performed correctly by accessing the door associated to the handle. 8) Generate the different users of the installation with their corresponding credentials. 9) Check on the monitoring that the accesses made on the handle(s) are granted. www.golmar-seguridad.es...
Page 24: To Be Considered
The controllers must be marked with the APERIO RS485 type. On the doors, the type "wireless locking device" must be indicated and the lock (handle) must be selected. Finally, the readers must have the corresponding handle associated with them. www.golmar-seguridad.es...
Page 25: Reader Associated To Handle
3) The terminal block associated to the handle cannot be used, meaning that authorized access activates the handle but not the relay contact. In case a reflex is generated, it must be to act on the relay contact of a door not occupied by a handle. www.golmar-seguridad.es...
Page 26: More Information About The System Or Equipment
Ba�ery not fully charged, energy counter not reset, Ten red ﬂashes (125 sec.each) no Power on self-test done. IMPORTANT: In case of loss of communication or power supply, it will be possible to open the door by using the accessory: AH100-010. www.golmar-seguridad.es...
Page 27 INTEGRACIÓN APERIO NOTES ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................www.golmar-seguridad.es...
Page 28 INTEGRACIÓN APERIO NOTES ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................www.golmar-seguridad.es...
Page 29 INTEGRACIÓN APERIO NOTES ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................www.golmar-seguridad.es...
Page 30 Sistemas de comunicación S.A. C/ Silici 13. Poligon Industrial Famadas 08940 – Cornellà del llobregat – Spain golmar@golmar.es Tel: 93 480 06 96 www.golmar-seguridad.es Golmar deserves the right for any modification without prior notice.
