Summary of Contents for Novita AirCare Pro cNAS9000

Page 1 AIR/SURFACE STERILIZER NAS9000 UP TO 60 MILLION NEGATIVE IONS CM AWAY QUADSYSTEM PURIPRO AIRBORNE FIR PM2.5 MOVING EXTENSIVE ® MODE TECHNOLOGY FILTER STERILIZATION PARTICLE AVERAGE FIR COVERAGE & SURFACE SENSOR PM2.5 DISPLAY AREA DO NOT OPERATE AWAY MODE SANITIZATION IN OCCUPIED ROOM OPERATING INSTRUCTIONS AND E-WARRANTY APPLICATION...
Page 2: Table Of Contents
PRODUCT DESCRIPTION • Air/Surface Sterilizer NAS9000 • Unit LCD Display & Touch Panel Description • Remote Control Description QUADSYSTEM TECHNOLOGY USING THE NOVITA AIRCARE PRO AIR/SURFACE STERILIZER NAS9000 • Unit Setting Up • Unit Operating Notes 24 MONTHS PURIPRO FILTER REPLACEMENT ®...
Page 3: Product Features
PRODUCT FEATURES Powered by QuadSystem™ Technology, the novita AirCare Pro™ Air/Surface Sterilizer NAS9000 - Purify, Ionize, Sterilize and Sanitize, providing protected indoor air quality and beyond! Achieving a remarkable 99.99% air sterilization against total airborne bacteria, yeast and mould in just 3 minutes, NAS9000 also endowed a powerful 99.99% surface sanitization performance against surface-bound E.Coli &...
Page 4: Product Description
PRODUCT DESCRIPTION AIR/SURFACE STERILIZER NAS9000 01. Adjustable LCD Panel 09. Groove to lift up LCD Panel 02. Touch Panel with LCD Screen Display 10. Handle Grip 03. Remote Control Infrared Receiver Window 11. Corona Discharge Module (Built-in internally) 04. Far Infrared PM2.5 Particle Sensor (Built-in internally) 12.
Page 5: Remote Control Description
REMOTE CONTROL DESCRIPTION 01. Power ON/OFF Button 02. Childlock Button 03. Timer Button 04. Mode Button 05. Fan Speed Button Do not operate Away Mode in occupied room 06. Away Mode Button 07. UV Nano Photocatalytic-Oxidation Button 08. Anion Button •...
Page 6: Using The Novita Aircare Pro
Produces controlled ozone concentration levels which has an incredible oxidation capacity against airborne germs and surface-bound contaminants. its effective odour control also eliminates unpleasant odours that linger in the air we breathe. USING THE NOVITA AIRCARE PRO AIR/SURFACE STERILIZER Ensure that the power plug is disconnected from the power supply at all times during installation, maintenance and transportation.
Page 7: Unit Operating Notes
UNIT OPERATING NOTES STEP 01 Insert the power plug into the power supply. In OFF mode, unit “beep” once with all LCD screen indicators illuminate once then goes off. Only button illuminates on the unit’s LCD screen. STEP 02 To switch ON/OFF the unit, tap button on the unit’s touch panel once or press button on the remote control once.
Page 8 Service maintenance is available for purchase at estore.novita.com.sg/nas-services to ensure unit’s optimum performance. • After air sterilization/surface sanitization operations, it is recommended to leave the area vacant for another one (1) hour. During this time, the residual ozone will oxidize the surrounding airborne/surface germs and then revert back to oxygen molecules.
Page 9 At Silent Mode, unit is programmed to the lowest speed setting with minimal noise level. With energy conservation in mind, at Silent Mode, after one (1) minute of unit idling, unit’s LCD screen will auto dim by 50% and on the next minute of unit idling, unit’s LCD screen will be 100% dim, with only indicator illuminating on the LCD screen.
Page 10: Months Puripro ® Filter Replacement
24 MONTHS PURIPRO FILTER REPLACEMENT ® When unit is in operation for every twenty-four (24) months* (Approx. 6,000 hours), indicator illuminates and flashes on the unit’s LCD screen as an indication that PuriPRO Filter ® replacement is required for optimum performance. It is recommended to replace 4-In-1 PuriPRO ®...
Page 11: Cleaning & Maintenance
STEP 05 Insert the power plug into the power supply and switch ON the unit. Tap and hold indicator on the unit’s touch panel for five (5) seconds to reset the filter replacement timer indicator. • Unit “beep” three (3) times and indicator stops flashing to notify user that the filter reset procedure is completed.
Page 12: Service Maintenance
* Based on average eight (8) hours a day, seven (7) days a week usage under mormal domestic indoor environment. Service maintenance is available for purchase at estore.novita.com.sg/nas-services. An order confirmation email of the service maintenance will be sent to your registered email address within seven (7) working days upon the receipt of your submission.
Page 13 Damaged power cord can cord is damaged, DO NOT use the service technicians by novita. period of time or to prevent result in electric shock or fire unit. Contact novita customer care deteriorating in the power cord hazard. centre for replacement. insulation.
Page 14: Troubleshooting
Check that the power plug is connected properly Power plug is not properly connected Fuse has blown Contact novita customer care centre The front panel casing is not installed properly Remove and reinstall the front panel casing Fan is not working...
Page 15: Technical Specifications
◊ The recommended coverage area is based on normal domestic indoor environment usage. ¤ The Clean Air Delivery Rate (CADR) in terms of smoke (PM2.5) removal is performed in accordance to AHAM AC-1-2015 standard, based on novita PM2.5 Filter. CFM unit is equivalent to ft /min, m /hr unit is derived from CFM conversion.
Page 16: Novita Customer Service Guarantee
MINIMUM DOWNTIME Understanding that time is of the essence, for each servicing or repair, novita guarantees that we will only take up to 7 working days to get your product up and ready for collection.
Page 17: Warranty Terms & Conditions
Product. In the event that the Product is out of stock, obsolete or beyond repair, novita reserves all rights to replace the Product with another similar value as deem appropriate, subject to availability.
