Summary of Contents for Industrial Controls AI-2030-SP-1
- Page 1 AI-2030-SP-1 controller Operating Manual...
-
Page 2: Chapter 1: Customer Information
CHAPTER 1: CUSTOMER INFORMATION THANK YOU FOR PURCHASING AN INDUSTRIAL CONTROL PRODUCT Read all instructions and warnings carefully before mounting, installing and configuring the products. These instructions have been published by INDUSTRIAL CONTROL and are not subject to any guarantee. The instructions may be withdrawn or revised by INDUSTRIAL CONTROL at any time and without further notice. -
Page 3: About This Document
ABOUT THIS DOCUMENT Every care has been taken in the preparation of this manual. Please inform INDUSTRIAL CONTROL of any inaccuracies or omissions. These End user instructions cover general safety issues, main technical specifications, standard installation, operating instructions, general troubleshooting information and regulatory information. -
Page 4: Chapter 2: Product Description
CHAPTER 2: PRODUCT DESCRIPTION CONTROLLER FRONT VIEW ① ③ ② ④ ⑤ 1: Alarm & Fault Terminal 4: Ethernet connector 2: LCD 5: Input voltage ,4-20mA input & reset Terminal 3: LED indicator (Fault, Alarm 1, Alarm 2, Alarm 3 TERMINAL DESCRIPTION Terminal Port Description... -
Page 5: Chapter 3: Configuration
This section will show you how to configure your new AI controller using the web-based configuration utility. Web-based Configuration Utility If you wish to change the default settings or optimize the performance of the AI-2030-SP-1, you may use the web-based configuration utility. After power on, connect Ethernet cable from PC to AI-2030-SP-1 Go to control panel ->... - Page 6 To access the configuration utility, open a web browser such as Internet Explorer or Firefox and enter http://192.168.1.110 in the address field. Note: our recommendation is Microsoft edge browser. REV.00...
- Page 7 4-20mA Configuration Measure Range: It identifies the device measurement range or unit for the analogical devices. The available values are those listed in below: (%LEL, ppm, %02, mA, °C, rH, V, bar, dB, rpm) Zero Point Value: It identifies the zero point of range. It is possible to change this parameter by manually keying-in the number.
- Page 8 RS485 Configuration Check the box to enable the RS485. If you do not want to use extension module, uncheck the box to disable all the functions. This mode to use connect AI-2030-SP-1 controller to Master HMI ,PLC via RS485 Modbus. REV.00...
-
Page 9: Chapter 5: Guarantee, Service, Repairs And Maintenance
CHAPTER 5: GUARANTEE, SERVICE, REPAIRS AND MAINTENANCE INDUSTRIAL CONTROL products are covered by a guarantee/warranty against material, construction, and manufacturing faults. During the guarantee/warranty period, INDUSTRIAL CONTROL may replace the product or faulty parts. Work under guarantee/warranty must be carried out by INDUSTRIAL CONTROL or by an authorized service center specified by INDUSTRIAL CONTROL. - Page 10 REV.00...
