Summary of Contents for Mofi SourcePoint 888

  • Page 2 Thank You for Purchasing the SourcePoint 888. The name SourcePoint 888 is derived from the use of three 8-inch drivers. My goal for the SourcePoint 888 is to enhance the technology and sound quality of the SourcePoint 8 and elevate it to an even higher performance level.
  • Page 3 General Safety and Installation • Be sure to connect the speakers according to the • Do not install the speakers in a closed rack or in a Unboxing Your Speaker instructions in this manual. closed cupboard. • Continuous high volume may cause severe damage •...

  • Page 4: Connecting Your Speakers

    Bi-Wiring and Bi-Amping Connecting Your Speakers Warning; Before connecting for bi-wiring or bi- amping, you must remove the shorting straps. Failure to do so will either defeat the purpose or potentially damage your amplifier. Your speakers are equipped with two sets of binding posts to allow for bi-wire and bi-amp connectivity.

  • Page 5: Speaker Placement

    Optimizing Stereo Imaging Speaker Placement Imaging is often overlooked when listening of stereo speakers. If correctly spaced and arranged with an There is no golden rule for speaker placement, but optimal toe-in angle, these speakers can create a following a few general guidelines will help optimize large involving soundstage while retaining focused performance.

  • Page 6: Installing The Feet

    Installing the Feet The feet are supplied in four pieces: a threaded rod, a locking ring, a cone, and a flat foot. The cone is intended for use on carpeted floors and the flat foot for use on wood or tiled floors.
  • Page 7 SourcePoint888 Frequency Range 32Hz-30kHz Nominal Impedance 6 Ohms, 4.5 Ohms minimum Sensitivity 87dB/2.83V/1m Crossover Frequency 130, 1.6kHz Max Power Input 200W Tweeter 1.25" wide roll soft dome Midrange 8” Paper Cone Woofer 2 x 8" Paper Cone Inside Back Cover System Configuration 3-way vented box, concentric driver Baffle Finish...
  • Page 8 MoFi Electronics – 1811 W Bryn Mawr Ave Chicago IL...
