Summary of Contents for ASES Security AS-801-BEAM
- Page 1 ASES Security Pvt. Ltd. Beam Detector Model : AS-801-BEAM Conventional Reective Beam Detector Installation and Operation Manual ERTL (N) - IS.2189:1999 Known for Absolute Reliability... Sold All Over India and Abroad... I N S T R U C T I O N...
- Page 2 e ASES a leading Unit-1 Sahibabad Ind. Area manufacturer of Fire Alarm Systems, Fire Rated Doors, Fire Pump Control Panels, Emergency Lights, PA/VA Systems etc. With a sound infrastructure we manufacture wide range of Control Panels that are used by several institutions.
- Page 3 INTRODUCTION From the very beginning we are committed to safeguard the home, property and lives. As society is moving towards the modernization, our priority is to secure it by using latest technology in the field of safety & security products. Company has taken the responsibility of Fire Detection &...
-
Page 4: Product Safety
Phone:-0120-4152341 INTRODUCTION Overview AS-801-BEAM Conventional Re ective Beam Detector has built in Laser beam pointing and Digital guide display for real user friendly alignment method. The Laser beam pointing accurately point the exact location where to mount mirror and with... - Page 5 The AS-801-BEAM is ideal for use high ceiling and wide areas such as warehouses, large storages, shopping malls, leisure centres, exhibition halls, hotel lobbies, printing houses, garment factories, museums and prisons, as well as places where slight smoke particles or corrosive gas exist.
- Page 6 TECHANICAL SPECIFICATION Part Number ASES-801-BEAM Standard Listed LPCB Certi cation Fire Detection and BS 5839 Part 1:2017 Alarm Systems Speci cation Operating Voltage 20 V to 28 V DC Current Parameters Standby: 23mA Commission: 56mA Alarm: 33mA Beam Sensor Sensitivity Level 1: 2.6 dB High Sensitivity [via Encoder] Level 2: 3.8 dB Medium Sensitivity...
- Page 7 Relay Capacity [Fire & Fault] Normally Open & Close/ 2.0 A; 30 VDC Physical Material / Colour ABS / White Dimension / Weight L:190.87 x W:126.87 x H:91.96 mm / 440 gm Weight 0.130 Kg with base Environmental Operating Temperature -10°C to +50°C Ingress Protection Rating IP30 [IP66 glue seal-For...
-
Page 8: Product Appearance
PRODUCT APPEARANCE PRINCIPLE OF THE BEAM DETECTOR The AS-801-BEAM re ective optical beam smoke detector incorporates a light transmitter and the detector on the same unit. The light path is created by re ecting light emitted from the transmitter off a retrore ector, meaning it is re ecting light back to its source with a minimum of scattering, which is placed opposite the detector. - Page 9 Fire Status Normal Status Beam Beam Mirror Mirror Detector Detector Mounting Mounting Bracket Bracket Smoke Figure 1: Beam detector principle INSTALLATION PROCEDURES MOUNTING DETAILS...
-
Page 10: Led Indicators
LED INDICATORS Function LED Indicators Colour Illuminates when at least one re Fire alarm event occur Illuminates when at least one YELLOW Fault fault alarm event occur in the Detector Alignment GREEN Illuminates during the commissioning MOUNTING PREPARATION This beam detector must be installed, commissioned and maintained by a quali ed or factory trained service personnel. - Page 11 Below 8 meters ceiling height Above 8 meters ceiling height Ceiling Level Ceiling Level 0.5m min to 1m max 0.5m min Beam Detector Beam Detector Figure 3: Installation Details MOUNTING OF THE BEAM DETECTOR 1. Using the supplied bracket, mark the position of the xing holes.
- Page 12 MOUNTING OF THE REFLECTIVE MIRROR 1. Depending on the project requirement, if the distance between the detector and the re ector mirror is 8m-40m, install one re ector is enough; if the distance is 40m-100m, four re ectors is required. Refer to Figure 6. 2.
- Page 13 CABLING DETAILS Cables should be brought into the detector using the supplied glad cable. The maximum size of the cable which can be terminated is 1.5mm². Observe the polarity. Refer to Figure 7. 1. Terminal D1 (+) and D2 (-) for connecting Power supply [24VDC] 2.
- Page 14 Sensitivity Level 1 Level 2 Level 3 Span Span 1: 8~20m 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6 Span 2: 20~40m 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6 Span 3: 40~70m 1 2 3 4 5 6...
-
Page 15: Commissioning Preparation
Receiver Vertical Adjustment Laser Beam M4x12 Screw Pointer Horizontal Transmitter Adjustment DIP switch[SW2] Reed Switch [SW1] Digital Display Guide Terminals Green [HL3] [HL1] Yellow LED [HL2] Figure 13: Names and Location COMMISSIONING PREPARATION 1. Make sure both beam detector and re ective mirror are properly and securely mounted. - Page 16 100meters]. 5. Wiring should be done correctly. Step 1: Entering Commissioning Method a. Remove the detector cover and power on the device. b. Place the supplied magnetic tool alongside the Reed Switch. After a while the Green LED [HL1] should turn on steady or blinking, and then take out the magnetic tool to start the detector auto alignment process.
- Page 17 Note: If the number display nine [9] it means the setting of the Span is not appropriate. Power off the detector and re- programmed the appropriate distance between the detector and mirror through DIP switch or programmer. b. If Green LED [HL1] steady on, it means that the signal intensity is acceptable.
- Page 18 2 seconds to reset the detector. Step 6: Testing Fault Signal a. Using supplied Opaque/Translucent materials, cover-on the half of the beam using the opaque portion of the material. Right after the Yellow LED [Fault] turn on, indicating the fault signal.
- Page 19 Opaque Material Translucent Material Testing Material Fire Signal Test Fault Signal Test Figure 14: Testing Details Step 6: Other Function Automatic Compensation of Light When dust exists in the working environment of the detector, the emitting window, receiving window and re ector will be covered with dust, which will affect normal operation.
- Page 20 MAINTENANCE 1. Inform the suitable personnel before conducting the maintenance. 2. Disable the detector on the control panel to prevent false alarm. 3. Do not attempt to adjust or modify the detector, it may affect the ability of the detector to respond to a re condition and will void the manufacturer’s warranty.
- Page 21 SUPPLIED ACCESSORIES The following accessories are included in the package: 1. Four plastic expansion bolts. 2. Two M4*12*10 three combination cross recessed pan head screws. 3. Four ST4*30 tap cross recessed pan head screws. 4. Mounting Bracket. 5. Opaque/Translucent Material. 6.
- Page 22 detector working in good condition, please maintain the equipment continuously according to recommendations from manufacturers and relative nation codes and laws. Take speci c maintenance measures on the basis of different environments. Beam detector contains electronic parts. Even though it is made to last for a long period of time, any of these parts could fail at any time.
- Page 23 32° To 120° Fahrenheit This is certify that BEAM DETECTOR supplied as per details has been manufactured by ASES Security Pvt. Ltd. tested provision laid down AS-801-BEAM and the Electronics Regional Test Laboratory (ERTL). Issue Date: Quality Assurance for ASES Security...
- Page 24 Mapping Our Growth ASES Security is a registered trademark of ASES Security in India and other countries. © Copyright ASES Security, 2015. All rights reserved. Any unauthorized reproduction or use of logos, design elements is strictly prohibited by law. No part of the compilation may be reproduced in any manner or translated without written permission.
