Altelix TBP12 Series Installation Manual

Page-4
Mounting the TBP12 Phone Box
The TBP12 series enclosures feature (3) mounting feet on the rear of the
enclosure. Using the included hardware, mount in the desired location.
For more secure installation, (4) mounting locations on the rear of the
enclosure can be used.
For models requiring drilling, using a ¼" drill bit, drill through enclosure in
locations shown.
Drill Locations (4)
Rear of Enclosure
Step 1 Step 2
Place (4) Rubber Secure the enclosure
Sealing Washers into to the wall using the
(4) mounting holes as (4) Screws.
shown.
Mounting Feet (3)
Screws with
Wall Anchors
Rubber Sealing
Washers
The mounting kit Included with
the enclosure includes (4)
Rubber Sealing Washers and (4)
Screws with Wall Anchors.
Step 3
When mounting
enclosure,
rubber sealing
completely
enclosure mounting holes
to provide a water-tight
seal.
Page-1
Wiring the TBP12 Phone Box
2. Once the aluminum plate
is removed,
punch
rubber
grommet located on the
bottom of the phone box.
Run your phone cable
into the box through this
grommet.
Note: For rear wiring,
see page 3.
Rubber Phone Cable Grommet
the
ensure the
washers
cover the
Altelix LLC USA: 866-660-WIFI (9434) International: +1 561-660-9434 sales@altelix.com www.altelix.com
Copyright (C) 2017 Altelix LLC. All rights reserved. Altelix and the Altelix logo are Trademarks and/or Registered Trademarks of Altelix LLC.
Specifications are subject to change without notice. See www.altelix.com for most current information
IS0185 Rev A 07/30/21
TBP12 Series Phone Box Installation Guide
Aluminum Plate
carefully
a hole in the
phone cable
Phone Cable
(not included)
1. Remove the (4) screws
securing the aluminum
plate.
Note the TBP12 is shipped
with the phone jack plate
removed to facilitate wiring.
Mounting Plate Screws (4)
