- Page 1 FLUX SMART OUTLET User Guide Document Number: T0006623 - FLUX Document Version: Release Date: 7 June 2024...
-
Page 2: Table Of Contents
Smart Outlet ........................7 Remote Operation ......................7 Local Operation ........................ 7 LED Behaviour ........................7 Basic Downlinks ......................8 Data converters ......................10 Safety Precautions...................... 11 Compliance Statements ..................... 12 TEKTELIC Communications Inc. T0006623-FLUX_UG_v2 User Guide Confidential Page 2 of 13... -
Page 3: Product Description
Figure 1-1 FLUX form factor FLUX is a C-class device which means one can send a downlink to FLUX and get a reply in real time without the wait of an uplink to transmit the downlink. Connected via LoRaWAN, enables seamless transmission and reception in US915 frequency band. - Page 4 16 mm (5/8”) strip length Torque terminal screw to 2.3 N.m (20 lbf-in) Surge Prot. IEEE C62.41 Category A Impulse Voltage 2500 V Approvals cUL (E515077) FCC Pt. 15, RSS-247, FCC Pt. 27 TEKTELIC Communications Inc. T0006623-FLUX_UG_v2 User Guide Confidential Page 4 of 13...
-
Page 5: Operating Instructions
2.3 Installation Procedure The following steps are required to install FLUX: 1. Locate the electrical box into which the FLUX will be installed. 2. Remove power to the wiring by turning off circuit power at the circuit breaker or fuse panel. -
Page 6: Commissioning
Network Server Quick Start Guide you get in the box with the device (also available online in the Knowledge Base). TEKTELIC Communications Inc. T0006623-FLUX_UG_v2 User Guide Confidential Page 6 of 13... -
Page 7: Operation
• line voltage • load current • load power (real, reactive, and apparent) • load power factor For details please refer to the TEKTELIC Communications Technical Reference Manual (TRM). 3.3 Local Operation The load of the bottom receptacle can be turn on or off by pressing the button. This load status change will be reported over the LoRa network. -
Page 8: Basic Downlinks
To Change the Core Report to Every 15 Minute Send the Downlink: a0 00 00 03 84 port 100. FLUX doesn’t have a decoder included in Atlas. However, it is possible to send the downlink in online mode as shown in the picture. - Page 9 ▪ Total elapsed time: 86400 seconds (= 24 hours) ▪ Total energy consumed: 27216 W-h (= 27.216 kW-h) o Energy Consumption Meter Status Indicator: ▪ Status: Idle (stopped) Example of data on LeapX Figure 4-4 LeapX application TEKTELIC Communications Inc. T0006623-FLUX_UG_v2 User Guide Confidential Page 9 of 13...
-
Page 10: Data Converters
TEKTELIC’s data converters conform to the LoRa Alliance Payload Codec Specification and can be used with any 3 party Network Server / Application Server that supports this specification. https://resources.lora-alliance.org/technical-specifications/ts013-1-0-0-payload-codec-api TEKTELIC Communications Inc. T0006623-FLUX_UG_v2 User Guide Confidential Page 10 of 13... -
Page 11: Safety Precautions
6 Safety Precautions The following safety precautions should be observed for FLUX installation: • TO AVOID FIRE, SHOCK, OR DEATH, ALWAYS TURN OFF POWER at the circuit breaker or fuse panel before wiring the module! • If you are unsure or uncomfortable with installation of this module, consult an electrician. -
Page 12: Compliance Statements
7 Compliance Statements Federal Communications Commission: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. - Page 13 WARNING: This product can expose you to chemicals including lead, nickel, and carbon black, which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. TEKTELIC Communications Inc. T0006623-FLUX_UG_v2 User Guide...
