KISTERS HyQuant L+V Quick Installation Manual

HyQuant | Quick installation guide
Package contents
1x HyQuant Sensor Unit
1x two-part mounting bracket (tilt and swivel)
1x 10 m cable w/ 8-pin female connector and open-ended wires
1x Torx key
1x Magnet
1x Test Certificate
1x Quick installation guide
Specifications summary
Radar frequency: 60 GHz
Radar band: V
Radar modulation:
– FMCW (level)
– Doppler (surface velocity)
Dual antenna:
– Looking 0° downwards for level
– Looking 45° downwards for velocity
Beam angle (azimuth x elevation):
– Level: 8° x 8°
– Surface velocity: 8° x 12°
Measuring range (model dependent):
– L20: 0,10 m ... 20 m/0.32 ... 65.61 ft
– L50: 0,15 m... 50 m/0.49... 164.04 ft
Operating voltage: 10...30 V DC
Power consumption @ 12V:
– Typical < 15 mA
– Peak < 80 mA
Operating temperature range: -40 ° ... +80 °C/ -40 °... 176 °F
Signal connector: M12 8-Pin male
Rating: IP68*
Compliance
CE, RoHS, FCC Class B, UL
Classification: Public © KISTERS AG 02/2024
Main parts
1 Cover with integrated radome
2 M12 8-pin male connector for
2
signal cable (supplied)
3 Pressure compensating gland
4 Die-cast aluminium housing
5 Rear mounting plate
6 U-bracket
7 Mounting bracket
Optional: pole mounting bracket 1"/2"
Enable local Wi-Fi communication
1. Manual activation: Swipe the
supplied magnet along the
red arrow (↑).
2. Enable via SDI-12: Use ex-
tended command aXWIFI!
3. Modbus: Write '1' to holding
register (FC06) 81.
If there is no Wi-Fi connection to
4. Power Cycle: Wi-Fi hotspot
an external device, the system
is activated when the device
will automatically switch off af-
is switched on.
ter a few minutes to save power.
Mounting instructions
Positioning:
0°
45°
1. Install sensor with black lid
parallel to water surface
2. The "
should always face up-
stream
Mounting:
1. HyQuant comes with a standard tilt and swivel bracket for prop-
er mounting adjustment to the water surface and flow direction.
2. Attach it to the support using M6 screws.
3. Use the provided bolt and torx key to fix the U-bracket to the
HyQuant backplate.
Mounting instructions
Mounting:
4. Adjust the device's tilt and swivel until it's positioned correctly:
3
6
Beam width/footprint for level and velocity:
1
7
Metric (m)
D W
50,0 6,99
4
30,0 4,20
20,0 2,80 28,28
5
15,0 2,10
10,0 1,40
7,0 0,98
5,0 0,70
3,0 0,42
2,0 0,28
1,0 0,14
0,5 0,07
R =
m
" on the cover
*IP68: dustproof and protected against continuous submersion in
water; max. depth 1,5 m for max. 3 h. No protection from other
liquids. Required: M12 connector inserted and securely fastened.
KISTERS Europe I hydromet.sales@kisters.eu I kisters.eu
Imperial (ft)
Rm L D W Rm
— — 164.04 22.93 —
— — 98.43 13,78 —
5,95 65.62 9,19 92.80
21,21 4,46 49.21 6,89 69.60
14,14 2,97 32.81 4,59 46.40
9,90 2,08 22,97 3,22 32.48
7,07 1,49 16,40 2,30 23.20
4,24 0,89 9,84 1,38 13.92
2,83 0,59 6,56 0,92 9.28
1,41 0,30 3,28 0,46 4.64
0,71 0,15 1,64 0,23 2.32
8°
2
12°
2
Level
Velocity
0°
45°
D
R
m
L W
8° 8°
12° 8°
L
—
—
19.51
14.63
9.75
6.83
4.88
2.93
1.95
0.98
0.49
