Mounting instructions BG Display
LASERSTOP
for warp knitting and weaving machines
Phone
Fax
Email
Internet
CAMSCAN
PROTECHNA Herbst GmbH & Co. KG
Lilienthalstr. 9
85579 Neubiberg
Germany
+49 (0)89 608 114-0
+49 (0)89 608 114-48
info@protechna.de
www.protechna.de
Mounting instructions BG Display V1 english
4180
5203
Advertisement
Table of Contents
Related Manuals for Vandewiele PROTECHNA LASERSTOP 4180
Summary of Contents for Vandewiele PROTECHNA LASERSTOP 4180
- Page 1 Mounting instructions BG Display V1 english Mounting instructions BG Display LASERSTOP 4180 CAMSCAN 5203 for warp knitting and weaving machines PROTECHNA Herbst GmbH & Co. KG Lilienthalstr. 9 85579 Neubiberg Germany Phone +49 (0)89 608 114-0 +49 (0)89 608 114-48 Email info@protechna.de Internet...
- Page 3 Copyright This manual is protected by copyright. All rights reserved. This document must not be copied, reproduced, minimised or translated in any form, neither partly nor entirely, using neither mechanical nor electronic means, without obtaining prior consent in writing from PROTECHNA Herbst GmbH &...
-
Page 4: Table Of Contents
Inhalt Safety instructions Demounting the display Different designs of control units Demounting the housing shape cover Demounting the separation panel housing Unplugging the grounding cable Disconnecting the flat ribbon plug Demounting the display Mounting the display Mounting the display Connecting the flat belt tongue Connecting the grounding cable Mounting the separation panel housing Mounting the housing shape cover... -
Page 5: Safety Instructions
Safety instructions • Always follow all warnings and information that is attached to the device itself or included in this manual. • This device is sensitive to electrostatic discharge, which may cause damage to the interior of the device or affect its normal operation. Please observe the required precautions when handling components liable to damage through electrostatic discharge. -
Page 6: Demounting The Display
Demounting the display Different designs of control units The control unit is available in two different designs. • Control unit 5203 with mounting on housing shape cover (1) • Control unit 5203 and 4180 with mounting on control unit base (2) Demounting the housing shape cover Loosen the three upper screws (13438) (2) of the side panel left (13450) and the three upper screws (13438) (4) of the side panel right (13451) of the control unit. -
Page 7: Demounting The Separation Panel Housing
Demounting the separation panel housing Then loosen the three screws (13429) (1) to remove the separation panel housing (13460) (2). Unplugging the grounding cable Remove the grounding cable (1) from the display (15121) (2). -
Page 8: Disconnecting The Flat Ribbon Plug
Disconnecting the flat ribbon cable In this step, the flat ribbon cable of the display (15121) (1) must be unplugged. To do this, the locking mechanism of the connector (2) must be opened. Then the flat ribbon cable (1) can be carefully pulled vertically out of the connector (2). -
Page 9: Mounting The Display
Mounting the display Mounting the display Remove the new display (15121) (2) from the packaging. Fix the display (15121) (2) with the four lock nuts (11547) (1). -
Page 10: Connecting The Flat Belt Tongue
Connecting the flat ribbon cable Next, the flat ribbon cabke of the display (15121) (1) must be connected. If necessary, open the locking mechanism of the flat connector. Then the flat ribbon cable (1) can be carefully inserted vertically into the connector (2). The locking mechanism must then be closed. Connecting the grounding cable Connect the grounding cable (1) to the display (15121) (2). -
Page 11: Mounting The Separation Panel Housing
Mounting the separation panel housing The separation panel housing (2) is then fixed in the control unit with the three screws (13429) (1). Mounting the housing shape cover Place the housing shape cover (13461) (1) on the control unit. Subsequently, fix the housing shape cover (13461) (1) with three screws (13438) (2) to the side panel left (13450) and with three screws (13438) (4) to the side panel right (13451). -
Page 12: Notizen
Notes...
