vsm LCD Button Panels

User Manual

Version: 4.0/1

Edition: 31 March 2017

Revision History

Version

4.0/1

for any reason is expressly prohibited, unless prior written consent is obtained from the Lawo AG.

All trademarks and registered trademarks belong to their respective owners. It cannot be guaranteed that all

product names, products, trademarks, requisitions, regulations, guidelines, specifications and norms are free from

trade mark rights of third parties.

All entries in this document have been thoroughly checked; however no guarantee for correctness can be given.

Lawo AG cannot be held responsible for any misleading or incorrect information provided throughout this manual.

Lawo AG reserves the right to change specifications at any time without notice.

To obtain the latest documentation and software downloads, please visit:

www.lawo.com/downloads

Edition

2014-05-20

2014-06-13

2014-08-27

LBP 51 Pow er Consumption corrected

2017-03-31

New Overview graphics & template

Changes

Initial draft

Initial Release

Firm w are Version

2.40

2.46

Table of Contents

Need help?

Do you have a question about the vsm LBP and is the answer not in the manual?

Questions and answers

Summary of Contents for LAWO vsm LBP

Page 1 All rights reserved. Permission to reprint or electronically reproduce any document or graphic in whole or in part for any reason is expressly prohibited, unless prior written consent is obtained from the Lawo AG. All trademarks and registered trademarks belong to their respective owners. It cannot be guaranteed that all product names, products, trademarks, requisitions, regulations, guidelines, specifications and norms are free from trade mark rights of third parties.
Page 2: Table Of Contents
vsm LCD Button Panels (LBP) Table of Contents Welcome ............................3 Important Safety Instructions ......................4 Introduction ............................6 Overview ............................7 E3 Buttons ..........................7 NKK Buttons ........................12 LBP Accessories ......................... 13 Operating Conditions ........................14 Preparing Panels for Operation ......................15 Preparing Accessories for Operation ....................
Page 3: Welcome
· vsm Software User Manual - more about vsmStudio, the main configuration and administration tool, plus other software components: vsmPanel, vsmWebPanel, vsmTimeSync, etc. · vsm Gear User Manuals - more about other hardware panel and interface options. All Lawo manuals are available from the Download-Center at www.lawo.com (after Login).
Page 4: Important Safety Instructions
vsm LCD Button Panels (LBP) Important Safety Instructions General Safety Warning Exposure to excessive sound pressure levels can lead to impaired hearing and cause damage to the ear. Please read and observe ALL of the following notes: · Check all of the hardware devices for transport damage. ·...
Page 5 vsm LCD Button Panels (LBP) Eye Safety Warning This equipment may use Class 1 Laser products which emit invisible laser radiation that may lead to eye injury. · NEVER look directly into optical components or optical fibre cables. · Fit protection caps to close any unused optical components. ·...
Page 6: Introduction
vsm LCD Button Panels (LBP) Introduction The vsm LCD Button Panels (LBP) are remote panels specifically designed for use with vsmStudio. The panels can be configured to meet every production environment’s requirement. A Single Destination, a Multiple Destination, a XY configuration or a combination of those alternatives is possible. The hardware panels provide multiple pages like the virtual panels.
Page 7: Overview
vsm LCD Button Panels (LBP) Overview E3 Buttons LBP 8 Number of buttons 8 LCD Buttons [E3] R/G/B-Backlight Options VSM SNAP Communication port 1xEthernet Dimensions 258mm x 43,7mm x 52mm (WxHxD):1RU/2 Weight approx. 0,5KG Power Consumption < 3W @12VDC/0,25A max Working Env ironment 0°C-50°C non condensing humidity LBP 17...
Page 8 vsm LCD Button Panels (LBP) LBP 24 Number of buttons 24 LCD Buttons [E3] R/G/B-Backlight Options VSM SNAP Communication port 1xEthernet Dimensions 258mm x 88mm x 53mm (WxHxD):2RU/2 Weight approx. 0,8KG Power Consumption < 5W @12VDC/0,42A max Working Env ironment 0°C-50°C non condensing humidity LBP 32 Number of buttons...
Page 9 vsm LCD Button Panels (LBP) LBP 31e-DT Number of buttons 31 LCD Buttons [E3] R/G/B-Backlight + 1 Encoder Options Communication port 1xEthernet Dimensions 256mm x 83,6mm x 140,6mm (WxHxD) Weight approx. 3,6KG Power Consumption < 6W @12VDC/0,5A max Working Env ironment 0°C-50°C non condensing humidity LBP 34 Number of buttons...
Page 10 vsm LCD Button Panels (LBP) LBP 51 Number of buttons 51 LCD Buttons [E3] R/G/B-Backlight Options VSM SNAP Communication port 1xEthernet Dimensions 483mm x 88mm x 52,8mm (WxHxD):2RU Weight approx. 1,7KG Power Consumption < 8,5W @12VDC/0,71A max Working Env ironment 0°C-50°C non condensing humidity LBP 50e Number of buttons...
Page 11 vsm LCD Button Panels (LBP) LBP 34V (vertical) Number of buttons 34 LCD Buttons [E3] R/G/B-Backlight Options VSM SNAP Communication port 1xEthernet Dimensions 65,1mm x 483mm x 59mm (WxHxD) Weight approx. 1,4KG Power Consumption < 6,5W @12VDC/0,54A max Working Env ironment 0°C-50°C non condensing humidity LBP 39V (vertical) Number of buttons...
Page 12: Nkk Buttons
vsm LCD Button Panels (LBP) NKK Buttons LBP 42 Number of buttons 42 LCD Buttons [NKK] R/G/B-Backlight Options VSM SNAP Communication port 1xEthernet Dimensions 483mm x 43,7mm x 53,3mm (WxHxD):1RU Weight approx. 1,3KG Power Consumption < 7,1W @12VDC/0,59A max Working Env ironment 0°C-50°C non condensing humidity LBP 41e Number of buttons...
Page 13: Lbp Accessories
vsm LCD Button Panels (LBP) LBP 83e Number of buttons 83 LCD Buttons [NKK] R/G/B-Backlight + 1 Encoder Options VSM SNAP Communication port 1xEthernet Dimensions 483mm x 87,2mm x 70,5mm (WxHxD):2RU Weight approx. 1,7KG Power Consumption < 12,3W @12VDC/1,02A max Working Env ironment 0°C-50°C non condensing humidity LBP Accessories...
Page 14: Operating Conditions
vsm LCD Button Panels (LBP) Operating Conditions This device is built to be used in a non-condensing environment within a temperature range of 0-50°C. Under or overshooting this working temperature range may cause fast aging of components or even malfunction of the whole device.
Page 15: Preparing Panels For Operation
Panel ID button will switch to a Panel ID configuration screen as long the device is not connected to any vsmStudio. All Lawo devices will be shipped with DHCP enabled network configuration. If you don’t have a DHCP network ask your administrator for static network settings and edit the “Network” section if required.
Page 16: Preparing Accessories For Operation
vsm LCD Button Panels (LBP) Preparing Accessories for Operation Do the following settings in VSM Discover: To connect an external serial device like an ENC17 or a RF-ID-Tag Reader, please use the “Option: External Encoder” or “Option: RFID” field on the corresponding LBP panel to enable this feature. A software reset is necessary for proper working external serial interface.
Page 17: Technical Specifications
vsm LCD Button Panels (LBP) Technical Specifications Status LEDs 8.1.1 LBP Panels Rear-view 1 (R/G/B): Lights blue: internal serial I/O controller OK, green: serial TX, red: serial RX. 2 (R/G/B): Pulses red: no connection to the network. Blinks fast red: device in bootloader-mode. Pulses yellow: network connection established.
Page 18: Connectors (Lbp Panels)
vsm LCD Button Panels (LBP) The LCD backlight colour is R/G/B, so basically all colours desired can be used. The key stroke of the tactile buttons is about 2.0mm +/-0.1mm using an operation force of approximately 1.3N +/- 0.2N. Button-spacing of LBP panel is (X x Y) 25,4mm x 24,13mm. All E3-buttons are placed on the PCB by sockets, so they can easily be exchanged, if damaged or worn out.
Page 19 vsm LCD Button Panels (LBP) 8.3.2 GPI-Interface Connectors for rear GPI-interface: 8-Pin connector locked with two screws (MC 1,5/ 8-STF-3,81) Separate plug not included for standard LBP delivery. Each LBP panel features two dry relays-outputs and 2 opto-coupled TTL-inputs. Looking at the picture of the connector on the right hand side, you will find it labled: –...
Page 20 vsm LCD Button Panels (LBP) GPO-contact-wiring “dry relay output”: 8.3.3 External Serial Interface Connector for data drive for external accessories: § 1 x RS422 via RJ45 connector § 1 x RS422 (loop through) via RJ45 connector § Serial Baud Rate will be configured automatically by the device to 115200 Baud. RS422 is a differential signal transfer.
Page 21: Connectors (Accessories)
vsm LCD Button Panels (LBP) Signal Color of a standard TIA-568A-shielded twisted pair patch cable (CAT5 or higher) green white/orange blue white/blue orange white/brown brown Notice for wiring: NC: No connection; do not connect to any signal or supply. Only use shielded CAT5 (or higher standard) -specified networkable. Refer to TIA-568A or TIA-568B for wiring. Do not use cable-traces longer than 100m (328ft) between the device and network-switch for 100BASE-T communication.
Page 22 vsm LCD Button Panels (LBP) 8.4.2 Rotary Encoder Each rotary-encoder is a 50-click-per-360°-rotation encoder with three R/G/B LEDs. LEDs are controlled by the corresponding 8.4.3 Serial Interface Connector for data drive for external accessories: § 1 x RS422 via RJ45 connector §...
Page 23: Cleaning The Lbp Panels
vsm LCD Button Panels (LBP) Cleaning the LBP Panels The best way to clean the button-front of LBP panels is to use a soft cloth and smooth window-cleaner-fluid. Do not expose the window-cleaner directly to the buttons, but to the cloth and then wipe softly over LBP panel-front. Do not use polish remover, oil, alcoholic- or gasoline based cleaner for the buttons as this will destroy the button- glass.
