vsm Under Monitor Display

User Manual

Version: 4.0/1

Edition: 31 March 2017

Revision History

Version

4.0/1

for any reason is expressly prohibited, unless prior written consent is obtained from the Lawo AG.

All trademarks and registered trademarks belong to their respective owners. It cannot be guaranteed that all

product names, products, trademarks, requisitions, regulations, guidelines, specifications and norms are free from

trade mark rights of third parties.

All entries in this document have been thoroughly checked; however no guarantee for correctness can be given.

Lawo AG cannot be held responsible for any misleading or incorrect information provided throughout this manual.

Lawo AG reserves the right to change specifications at any time without notice.

To obtain the latest documentation and software downloads, please visit:

www.lawo.com/downloads

Edition

2014-05-20

2014-06-13

2017-03-31

New Overview graphics & template

Changes

Initial draft

Initial Release

Firm w are Version

1.15

Table of Contents

Need help?

Do you have a question about the vsm UMD SD and is the answer not in the manual?

Questions and answers

Summary of Contents for LAWO vsm UMD SD

Page 1 All rights reserved. Permission to reprint or electronically reproduce any document or graphic in whole or in part for any reason is expressly prohibited, unless prior written consent is obtained from the Lawo AG. All trademarks and registered trademarks belong to their respective owners. It cannot be guaranteed that all product names, products, trademarks, requisitions, regulations, guidelines, specifications and norms are free from trade mark rights of third parties.
Page 2: Table Of Contents
vsm Under Monitor Display (UMD) Table of Contents Welcome ............................3 Important Safety Instructions ......................4 Introduction ............................6 Overview ............................7 Operating Conditions ........................8 Preparing for Operation ........................9 Technical Specifications ........................10 Status LEDs ........................10 Addressing the UMDs ......................10 Mounting UMDs ........................
Page 3: Welcome
· vsm Software User Manual - more about vsmStudio, the main configuration and administration tool, plus other software components: vsmPanel, vsmWebPanel, vsmTimeSync, etc. · vsm Gear User Manuals - more about other hardware panel and interface options. All Lawo manuals are available from the Download-Center at www.lawo.com (after Login).
Page 4: Important Safety Instructions
vsm Under Monitor Display (UMD) Important Safety Instructions General Safety Warning Exposure to excessive sound pressure levels can lead to impaired hearing and cause damage to the ear. Please read and observe ALL of the following notes: · Check all of the hardware devices for transport damage. ·...
Page 5 vsm Under Monitor Display (UMD) Eye Safety Warning This equipment may use Class 1 Laser products which emit invisible laser radiation that may lead to eye injury. · NEVER look directly into optical components or optical fibre cables. · Fit protection caps to close any unused optical components. ·...
Page 6: Introduction
vsm Under Monitor Display (UMD) Introduction The vsm Under Monitor Display (UMD) displays information such as labels and tally quickly, clearly and precisely. The UMD layout can be configured freely with the vsmStudio assigned via IDs. The special surface avoids finger prints and reflection. Text can be displayed in variable sizes, character sets, centred and inverse. Four external Tally hardware inputs can be used for individually customised messages to be displayed during stand-alone use.
Page 7: Overview
vsm Under Monitor Display (UMD) Overview UMD-SD 19” Number of Pixel 170x7 (X/Y ) + 1 Line of red/green/y ellow-Tally Communication port RS422 (Ethernet communication v ia SmartHub) Dimensions 483mm x 43,7mm x 33,2mm (WxHxD):1RU Weight approx. 0,7KG Power Consumption <...
Page 8: Operating Conditions
vsm Under Monitor Display (UMD) Operating Conditions This device is built to be used in a non-condensing environment within a temperature range of 0-50°C. Under or overshooting this working temperature range may cause fast aging of components or even malfunction of the whole device.
Page 9: Preparing For Operation
vsm Under Monitor Display (UMD) Preparing for Operation First configure a Smarthub port as UMD-Proxy as described in the VSM-SmartHub User Manual and setup the bus address on the rear side of the UMD. If there is more than one UMD in the chain, consider following daisy chain rules for the RS422 bus: ·...
Page 10: Technical Specifications
vsm Under Monitor Display (UMD) Technical Specifications Status LEDs Rear-view 1 Red: Blinks: Life-pulse/Incoming data. 2 Green: Light, internal voltage OK. Addressing the UMDs Each UMD has rotary encoders on the rear side of the UMD for applying a unique address in each RS422-chain. Valid addressing for each unique UMD can be done between 0...EF [hex] which will be 0...239 [dec].
Page 11: Connectors
vsm Under Monitor Display (UMD) UMD SD ½ - 19”: Connectors 7.4.1 Power All UMDs work with 12V low ripple direct current (12VDC). The power consumption of the 12V-line depends on the amount of pixels illuminated and also if text is displayed inverted. We suggest to only using the enclosed capsuled single power supply for each UMD.
Page 12 vsm Under Monitor Display (UMD) RS422 is a differential signal transfer. Each Tx and each Rx line has both a positive and a negative pole. It is therefore absolutely necessary that twisted pair is used for Tx and Rx is used. UMD connections can easily be done by preconfigured standard shielded network cable (CAT5 or higher standard).
Page 13: Cleaning The Display
vsm Under Monitor Display (UMD) Cleaning the Display The best way to clean the finger-print-save UMD-front is to use a soft cloth and smooth window-cleaner-fluid. Do not expose the window-cleaner directly to the UMD, but to the cloth and then wipe softly over the UMD-front. Do not use polish remover, oil, alcoholic- or gasoline based cleaner for the UMDs as this will destroy the plexiglass front cover.
