NovaStar TU20 Pro User Manual

NovaStar TU20 Pro User Manual

Led playback control processor
Hide thumbs Also See for TU20 Pro:
Table of Contents

Advertisement

Quick Links

TU20 Pro & TU15 Pro
LED Playback Control Processor
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TU20 Pro and is the answer not in the manual?

Questions and answers

Related Manuals for NovaStar TU20 Pro

Summary of Contents for NovaStar TU20 Pro

  • Page 1 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual...

  • Page 2: Change History

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Change History Document Version Release Date Description  Updated the getting started instructions.  Added instructions for the secondary screen and device diagnostics.  Added instructions for managing device files.

  • Page 3: Table Of Contents

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Contents Change History ................................. i 1 Introduction ..................................1 2 Getting Started ................................2 3 Usage of the Remote ..............................7 Buttons on the Remote ............................7 Bluetooth Pairing Method ............................7 4 Screen Mirroring ................................
  • Page 4 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual 8.7.3 System Update ............................... 45 8.7.4 Factory Reset ..............................47 8.7.5 Screen Dehumidification ..........................48...

  • Page 5: Introduction

    Control Processor User Manual Introduction This document introduces the operating method of the TU20 Pro and TU15 Pro to help users get started with the LED playback control processors quickly. The TU20 Pro and TU15 Pro are playback control processors specially designed by Xi’an NovaStar Tech Co., Ltd.

  • Page 6: Getting Started

    Figure 2-1 Hardware architecture Step 4 Connect the Ethernet cables from the LED screen to the Ethernet output ports of TU20 Pro/TU15 Pro in the order shown below. Figure 2-2 Rear panel – TU20 Pro (6 Ethernet ports) / TU15 Pro (4 Ethernet ports) Step 5 Connect the power cable to power on the device.
  • Page 7 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual  With VNNOX Care, you can easily perform screen configuration, screen topology, seam correction, and automatic screen configuration backup. Step 3 Configure the LED Screen Step 1 Open VNNOX app and connect to the LED playback control processor.
  • Page 8 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 2-3 Select a language Step 2 To pair the remote using Bluetooth, point it at the device's infrared sensor. Then, simultaneously press and hold the Home and Menu buttons on the remote until you see the Connecting to the remote window pop...
  • Page 9 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 2-6 Select a time zone Step 5 Select the Wi-Fi network you want to connect to and enter the password. Then, click Connect. Figure 2-7 Connect to Wi-Fi...
  • Page 10 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 2-9 Rename your device Note The hotspot name will be updated automatically if you rename the device. Step 7 The initialization settings are done. You can start using the LED playback control processor.

  • Page 11: Usage Of The Remote

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Usage of the Remote Buttons on the Remote Figure 3-1 Description of buttons on the remote Bluetooth Pairing Method Point the remote at the device's infrared sensor and hold down the Menu and Home buttons simultaneously until the Connecting to the remote window appears at the bottom of the screen.

  • Page 12: Screen Mirroring

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Screen Mirroring Wireless Mirroring Ensure that the network is connected before using wireless screen mirroring. For details, please refer to Step Getting Started. 4.1.1 Mirror from Mobile Phone Screen mirroring on ViPlex Handy...
  • Page 13 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 4-2 Screen interaction Step 7 Do the following as required.  Display image: Select an image from the album and display it on the screen. Swipe left or right to switch between images.
  • Page 14 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 4-4 Display video  Display document: Select a document from the file explorer and display it on the screen. Use the remote to scroll through pages and move the cursor (Supported file formats include PPT, WORD, PDF, and EXCEL.
  • Page 15 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 4-6 Screen mirroring & Stop mirroring Note:  on top of the interface and then tap Stop to stop.  Please enable the floating window permission for ViPlex Handy before mirroring screen.
  • Page 16 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 4-7 Remote Mirroring from iOS Step 1 Connect your phone to the hotspot of the LED playback control processor (default name: TUxx Pro_xxxx; default password: SN2008@+). Step 2 Open the control center.

  • Page 17: Mirroring From Pc

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual 4.1.2 Mirroring from PC Mirroring from Windows On the PC, open a browser, enter the website address “meexus.cn/English.html” and download the Step 1 LinkED for Windows client. Step 2 Connect the PC to hotspot of the LED playback control processor (default name: TUxx Pro_xxxx;...

  • Page 18: Mirroring Via Dongle

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 4-9 Screen mirroring - Mac 4.1.3 Mirroring via Dongle Step 1 For the first-time use, or after you change the device name, hotspot name or hotspot password, you must insert the mirroring dongle into the USB port of the LED Playback control processor for pairing.

  • Page 19: Mirror Screen Settings

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual 2. Double click the Client program to run it. 3. Follow the instructions to complete the authorization. 4.1.4 Mirror Screen Settings Step 1 On the main screen, click to navigate to the screen mirroring settings.
  • Page 20 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual  Version: Check the mirroring dongle version.  Activation information: Click to check the activation status, activation code, MAC address, and split-screen quantity.  Smart whiteboard pen: Click to use the smart whiteboard pen.

  • Page 21: Wired Mirroring

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Wired Mirroring 4.2.1 Connect Signal Source Connect the LED playback control processor to the device you want to mirror the screen from via HDMI cable. Figure 4-13 Wired mirroring 4.2.2 Switch Signal Source...

  • Page 22: Secondary Screen

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Secondary Screen Access the Secondary Screen Step 1 To access the secondary screen interface, first navigate the cursor to the left of the home screen, then press the Left button on the remote again. In this interface, you can find details such as the device name, system version, product serial number (SN), memory status, and storage information.
  • Page 23 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Step 2 Press the Left/Right buttons on the remote to navigate through Pair with Remote, Pair with Dongle, Home App Customization, App Switcher, and Effect Mode.  Click Pair with Remote to open the remote pairing instruction screen.
  • Page 24 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 5-5 Home app customization  Click App Switcher to open the app switcher instruction screen. Figure 5-6 App switcher  Click Effect Mode to open the effect mode instruction screen.

  • Page 25: Diagnostics

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 5-7 Effect mode Step 3 On the right side of the secondary screen's homepage, you can click Wired Network, Wi-Fi, Hotspot, and Bluetooth to redirect to Settings > Network > Wired Network\Wireless Network\Hotspot\Bluetooth.

  • Page 26: Faq

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 5-9 Running diagnostics Step 3 Once the diagnostic process is complete, you will see either Device normal or Device abnormal displayed on the left. On the right, you can view the test items categorized as Normal, Abnormal, or Not tested.

  • Page 27: File Explorer

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 5-11 FAQ Step 2 Use the remote's Up and Down buttons to toggle between the categories of issues on the left, then press OK to view the specific questions.
  • Page 28 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 6-2 Manage single files − Copy: Example: To copy the "Alarms" folder, first bring up the pop-up menu and select Copy. Next, navigate to the target location where you want to paste the folder. Finally, click the Paste icon on the right side of the screen and wait until the process is completed.
  • Page 29 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 6-4 Pasting single files − Cut: The Cut operation is similar to the Copy operation. You can refer to the instructions above. − Delete: Bring up the pop-up menu and select Delete.

  • Page 30: Manage Files By Type

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 6-6 Pasting multiple files Note  Only files located in the Device tab can be pasted; copying, cutting, and pasting are not avilable in the video, image, document, and package tabs.
  • Page 31 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 6-7 File explorer Step 2 You can view and manage files by file types.  In the Documents tab, you can short press the OK button on the remote to open the selected document, or long press the OK button to delete it.
  • Page 32 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 6-9 Videos  In Images tab, you can short press the OK button on the remote to preview the selected image, short press the Left or Right button to switch between images, and double-press Return button to exit preview mode.

  • Page 33: Media Player

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 6-11 Packages Media Player Manage Media Library Step 1 On the main screen of the system, click to open the Player interface. Step 2 Select Library from the navigation bar on the left.
  • Page 34 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 7-2 Import Note You need to insert a USB drive first before you can import images and videos. Step 4 After selecting a media file, long press the OK button on the remote to access options such as renaming, bulk selection, and deletion.

  • Page 35: Manage Program

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 7-4 Media playback Note If using touch input: The menu area can be scrolled up and down or selected by a single tap; the list area can be swiped left or right or selected by a single tap; the function items are to be selected by a single tap for execution.
  • Page 36 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 7-6 Create a program Step 4 After selecting a program, long press the OK button on the remote to access options such as renaming, batch selection, and deletion (The default program cannot be edited).

  • Page 37: Search

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 7-8 Program playback Note If using touch input: The menu area can be scrolled up and down or selected by a single tap; the list area can be swiped left or right or selected by a single tap; the function items are to be selected by a single tap for execution.

  • Page 38: Settings Management

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Settings Management Network Settings 8.1.1 Wired network Step 1 On the main screen of the system, click to open the settings interface. Step 2 Select Network > Wired Network to open the wired network interface.

  • Page 39: Bluetooth

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Step 3 Select an available Wi-Fi network near you and enter the password in the displayed window. Step 4 Press OK to connect to the Wi-Fi network. 8.1.3 Bluetooth...

  • Page 40: Hotspot

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual 8.1.4 Hotspot Step 1 On the main screen of the system, click to open the settings interface. Step 2 Select Network > Hotspot to open the hotspot interface. Step 3 Toggle the hotspot option on ( ) and set the device name, hotspot password, and channel information.

  • Page 41: Eye Comfort

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Step 2 Select Display and Effects > Effects to open the effect adjustment interface. Figure 8-6 Effect adjustment Step 3 Select a mode according to your need.  Standard: Suitable for most content viewing.

  • Page 42: Image Enhancement

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 8-7 Eye comfort 8.2.3 Image Enhancement Step 1 On the main screen of the system, click to open the settings interface. Step 2 Select Display and Effects > Image Enhancement.

  • Page 43: General Settings

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 8-9 Sound settings Step 3 You can adjust the system volume and select an Audio Output option from the following: Default Audio, Force 3.5mm Audio Output, and SPDIF Audio.

  • Page 44: Language And Keyboard

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual 8.4.2 Language and Keyboard Step 1 On the main screen of the system, click to open the settings interface. Step 2 Select General > Language and Keyboard to open the language and keyboard interface.

  • Page 45: Screensaver

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual  When enabled, the device will automatically redirect to the main screen upon detecting a signal source connection.  If this option is disabled, a popup alert will appear when the main screen receives a signal source input.
  • Page 46 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 8-14 Assistive touch  : Back button. Click to go back to the previous interface.  : Home button. Click to go back to the main screen. ...

  • Page 47: Playback Settings

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Note The remote cannot operate the assistive touch menu. You need to connect a mouse or use a touchscreen for control. Playback Settings 8.5.1 Play Program at Startup Step 1 On the main screen of the system, click to open the settings interface.

  • Page 48: System Settings

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 8-16 Wallpaper System Settings 8.7.1 About Step 1 On the main screen of the system, click to open the settings interface. Step 2 Select Settings > System> About to open the corresponding interface.

  • Page 49: Auto Standby/Wake-Up

    TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 8-17 About 8.7.2 Auto Standby/Wake-up Step 1 On the main screen of the system, click to open the settings interface. Step 2 Select Settings > System> Auto Standby/Wake-up to open the corresponding interface.
  • Page 50 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 8-19 System update Step 3 Select Local Update or Online Update.  Local update: Insert the USB drive that contains the update package into the USB port of the device. The update package has a file extension of *.nuzip and the package must be placed in the root directory of the...
  • Page 51 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual Figure 8-21 Online update Note  Before starting the online update, make sure you are connected to the Internet.  The online update consists of two stages: After detecting the latest version, click Update Now. If the installation package for the current version is already available locally, the system will proceed directly to install it.
  • Page 52 TU20 Pro & TU15 Pro LED Playback Control Processor User Manual 8.7.5 Screen Dehumidification Step 1 On the main screen of the system, click to open the settings interface. Step 2 Select Settings > System to open the system settings interface.
