Wohler HDCC-GPINHL-OG1 Configuration Manual

Vanc/audio gpi cue inserter/receiver with cea-608/708 monitoring
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HDCC-GPINHL-OG1
VANC/Audio GPI Cue Inserter/Receiver
with CEA-608/708 Monitoring
Configuration Guide
Firmware Version: V1.10
Software Version: V0.17
Part Number 821065, Revision B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDCC-GPINHL-OG1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Wohler HDCC-GPINHL-OG1

  • Page 1 HDCC-GPINHL-OG1 VANC/Audio GPI Cue Inserter/Receiver with CEA-608/708 Monitoring Configuration Guide Firmware Version: V1.10 Software Version: V0.17 Part Number 821065, Revision B...
  • Page 2 Wohler Technologies, Inc. reserves the right to change or improve our products at any time and without notice. In no event will Wohler Technologies, Inc. be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect in the hardware, software, or its documentation, even if advised of the possibility of such damages.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1. Getting Started ......1 Introduction ..............1 Overview..............1 Goals for This Chapter..........1 Topics ..............1 Product Description ............2 Quick Start Guides ............2...
  • Page 4 Chassis.............11 Hardware............11 Installation ...............12 Rear Panel DIP Switch ............14 Next Steps ..............15 Chapter 3. TCP/IP Configuration and Virtual Serial Ports (VSPs) ......17 Introduction..............17 Overview ..............17 Goals for This Chapter ..........17...
  • Page 5 Software GPI Control ..........40 VANC GPI Rx Control ..........41 VANC GPI Tx Control..........41 GPO Control............41 The Setup Tab .............. 42 Chapter 5. Using the General Purpose Inputs/Outputs . . 43 Introduction ..............43 Overview..............43 Topics ..............43 Functionality..............44 GPIs ..............
  • Page 6 Appendix A. Register Set ......59 Introduction..............59 Overview ..............59 Topics ..............59 Accessing the Engineering Menu ........60 Modifying the Register Settings ........60 Appendix B.

  • Page 7: Getting Started

    Getting Started Introduction Overview This chapter describes the basic captioning functions that you can perform using your Wohler HDCC-GPINHL-OG1 (for the Ross DFR-8321 frame). Goals for This Chapter Provide a Quick Start process that gives an overview of the installation.

  • Page 8: Product Description

    ® through DashBoard software. Refer to Using DashBoard on page 33 for instructions. The HDCC-GPINHL-OG1 is a one-channel card; It allows a single HD/ SD-SDI stream to pass through. Figure 1–1 HDCC Card Quick Start Guides Figure 1–2 on page 3 illustrates the installation and configuration process for the Ross DFR-8321 frame.
  • Page 9 C h a p t e r 1 Getting Started Q u ic k S t a r t G ui d e s Figure 1–2 Quick Start, Ross DFR-8321 Frame Start Set up Ross DFR-8321 frame per manufacturer’s instructions Install Ross DashBoard Control System software on your host PC Configure (initial) IP address...

  • Page 10: I/O Connections

    C h a p t e r 1 G et t in g St a r t e d I / O C o nn e c t io n s I/O Connections Front Edge The HDCC card’s front edge has a power LED (lit when power is applied), a USB port, and a USB override switch.

  • Page 11: Hdcc In Ross Dfr-8321 Frame

    C h a p t e r 1 Getting Started I / O C o n ne c t io n s HDCC in Ross DFR-8321 Frame The HDCC-OG1 consists of two main parts: the HDCC board which goes into a DFR-8321 slot, and the OG1 Rear Panel which is attached to the rear of the frame.

  • Page 12: Relay Bypass

    C h a p t e r 1 G et t in g St a r t e d F u n ct i o ns Relay Bypass To prevent the loss of the broadcast signal in the event of power failure, the input is bypassed via a relay to its output, ensuring the signal will always pass through the card.

  • Page 13: Gpi Cue Reception

    C h a p t e r 1 Getting Started F un c t io n s Figure 1–6 Cue GPI Insertion ChA In: Video ChA Out: Video + GPI Cues HDCC (GPI Cue Control Equipment Insertion) GPI In (Cues) Connections Port Data...

  • Page 14: Monitoring

    CHA MON shows the captions “burned” into the video. The HDCC-GPINHL-OG1 can be configured to have both outputs burned-in or both clean, as well. 8 21 06 5 : HD C C- G PI N HL-O G 1 C o nf i g urat io n G u id e...

  • Page 15: Hardware Installation

    CHAPTER 2 Hardware Installation Introduction Overview This chapter explains how to install your HDCC card in the Ross DFR- 8321 frame. Goals for This Chapter Install your HDCC card in a Ross DFR-8321. to configure a static IP address or DHCP for your HDCC card.

  • Page 16: Safety Instructions

    If any items are missing or damaged, please contact your Wohler sales representative immediately. 8 21 06 5 : HD C C- G PI N HL-O G 1 C o nf i g urat io n G u id e...

  • Page 17: Installing The Hdcc In The Ross Dfr-8321

    C h a p t e r 2 Hardware Installation I n s t a lli n g t he H DC C i n t h e R o s s D F R - 8 32 1 Installing the HDCC in the Ross DFR-8321 Requirements Tools...

  • Page 18: Installation

    C h a p t e r 2 H a rd w a r e I ns t a l la t i o n I ns t al li n g t h e H D C C i n t h e R o ss DF R- 83 2 1 Installation To install the HDCC board and OG1 Rear Panel in the frame, follow the steps below:...
  • Page 19 C h a p t e r 2 Hardware Installation I n s t a lli n g t he H DC C i n t h e R o s s D F R - 8 32 1 After you have inserted the screw into the OG Rear Panel, place the O-ring on the screw.

  • Page 20: Rear Panel Dip Switch

    C h a p t e r 2 H a rd w a r e I ns t a l la t i o n Re a r Pa n e l DI P S w i t ch Figure 2–3 Install in DFR-8321 Frame Note: Ensure that...

  • Page 21: Next Steps

    C h a p t e r 2 Hardware Installation N ex t S t e p s Table 2–1 Rear Panel DIP Switch Position Functionality Position Default Use static IP Use internal address settings for IP determined by address. position 2.
  • Page 22 C h a p t e r 2 H a rd w a r e I ns t a l la t i o n N e x t St ep s I m p or t a n t : This concludes the procedure for installing the HDCC card and its rear panel.

  • Page 23: Chapter 3. Tcp/Ip Configuration And Virtual Serial Ports

    CHAPTER 3 TCP/IP Configuration and Virtual Serial Ports (VSPs) Introduction Overview This chapter describes how to configure your HDCC card for use on a TCP/IP network and how to install virtual serial ports (VSPs) to communicate with you HDCC card. N ot e : Unless there is a need to access the terminal with a virtual serial port, this chapter may be skipped.

  • Page 24: Functional Overview

    C h a p t e r 3 TC P / I P C o n f ig u r a t i on a nd V ir t ua l S e r ia l Po r t s (V S P s ) F u n ct i o na l O v e r v ie w Topics Page...

  • Page 25: Finding The Hdcc On The Network

    The default IP address can be set by SW1. See the previous chapter Assigning a Static IP Address/Enabling DHCP Double-clicking on the Wohler Serial-Ethernet Bridge (see Figure 3–2 above) will open a web browser and take you the card’s configuration page where you can set a static IP address, if desired.
  • Page 26 C h a p t e r 3 TC P / I P C o n f ig u r a t i on a nd V ir t ua l S e r ia l Po r t s (V S P s ) A s s ig ni n g a S t a t ic I P A d d r e s s / En a b l in g DH C P You can also reach the HDCC card configuration screen through a web browser by entering the IP address in the address bar.
  • Page 27 C h a p t e r 3 TCP/IP Configuration and Virtual Serial Ports (VSPs) A s si g n in g a S t a t i c I P A d d r es s / E na b li ng D H C P If your network administrator provides you with a Default , enter that, too.
  • Page 28 C h a p t e r 3 TC P / I P C o n f ig u r a t i on a nd V ir t ua l S e r ia l Po r t s (V S P s ) A s s ig ni n g a S t a t ic I P A d d r e s s / En a b l in g DH C P Figure 3–5 IP Address Change...

  • Page 29: Creating Vsps With The Lantronix Redirector

    C h a p t e r 3 TCP/IP Configuration and Virtual Serial Ports (VSPs) C r e a t in g V S Ps w it h t h e La n t r o n ix R e d i r ec t o r Creating VSPs with the Lantronix Redirector The Lantronix Redirector software allows you to create VSPs quickly...
  • Page 30 C h a p t e r 3 TC P / I P C o n f ig u r a t i on a nd V ir t ua l S e r ia l Po r t s (V S P s ) C r e a t in g V S Ps w i t h t h e L a n t r o n ix R e d i re c t o r Figure 3–7 Open File - Security Warning...
  • Page 31 C h a p t e r 3 TCP/IP Configuration and Virtual Serial Ports (VSPs) C r e a t in g V S Ps w it h t h e La n t r o n ix R e d i r ec t o r Figure 3–9 InstallShield screen will quickly display and then return...
  • Page 32 C h a p t e r 3 TC P / I P C o n f ig u r a t i on a nd V ir t ua l S e r ia l Po r t s (V S P s ) C r e a t in g V S Ps w i t h t h e L a n t r o n ix R e d i re c t o r Figure 3–11 Setup Status...

  • Page 33: Vsp Configuration

    C h a p t e r 3 TCP/IP Configuration and Virtual Serial Ports (VSPs) C r e a t in g V S Ps w it h t h e La n t r o n ix R e d i r ec t o r VSP Configuration Now that the software is installed, you can set up VSPs.
  • Page 34 C h a p t e r 3 TC P / I P C o n f ig u r a t i on a nd V ir t ua l S e r ia l Po r t s (V S P s ) C r e a t in g V S Ps w i t h t h e L a n t r o n ix R e d i re c t o r Figure 3–14 Com Setup...
  • Page 35 C h a p t e r 3 TCP/IP Configuration and Virtual Serial Ports (VSPs) C r e a t in g V S Ps w it h t h e La n t r o n ix R e d i r ec t o r Figure 3–16 Port Settings Check...
  • Page 36 C h a p t e r 3 TC P / I P C o n f ig u r a t i on a nd V ir t ua l S e r ia l Po r t s (V S P s ) C r e a t in g V S Ps w i t h t h e L a n t r o n ix R e d i re c t o r Figure 3–19 Config Info...

  • Page 37: Creating Vsps With The Later Versions Of Windows

    C h a p t e r 3 TCP/IP Configuration and Virtual Serial Ports (VSPs) C re a t i n g V S P s w it h t h e L a t e r V e r si o ns of W in d o w s Creating VSPs with the Later Versions of Windows Windows 7 or 8 users need to install an alternative COM port...
  • Page 38 C h a p t e r 3 TC P / I P C o n f ig u r a t i on a nd V ir t ua l S e r ia l Po r t s (V S P s ) C r e a t in g V S Ps w i t h t h e L a t e r V e r s io n s o f W i nd o ws 8 21 06 5 : HD C C- G PI N HL-O G 1 C o nf i g urat io n G u id e...

  • Page 39: Chapter 4. Using Dashboard

    CHAPTER 4 Using DashBoard Introduction Overview This chapter explains how to use the DashBoard Control System™ (the PC graphic user interface, from here on referred to as DashBoard) to configure your HDCC card. Topics Topics Page Introduction Starting DashBoard Configuring the Channel Common Controls The Setup Tab 8 21 06 5:...

  • Page 40: Starting Dashboard

    C h a p t e r 4 U si n g D a s h B oa r d St a r t in g Da s h B o a rd Starting DashBoard The operations of the HDCC card are controlled by the settings of internal registers, which are easily and intuitively configured with DashBoard.
  • Page 41 S t a r t in g Da s h B o a r d Figure 4–2 DashBoard Main Screen (Top) Note: The Wohler HDCC-GPINHL-OG1 card will appear as in the list of cards installed in WTI-GPINHL1 (GPINHL1) the frame.

  • Page 42: Common Controls

    C h a p t e r 4 U si n g D a s h B oa r d C o m m o n C on t r o ls Figure 4–3 Center Pane Figure 4–3 above shows some product details about the HDCC that may be helpful at a future date, including the software and FPGA firmware part numbers and revisions.

  • Page 43: Configuring The Channel

    C h a p t e r 4 Using DashBoard C o n fi g u r in g t h e C h a n n el Configuring the Channel Click the channel tab in DashBoard and change the settings in the Channel A submenu (see Figure 4–4 below) to customize your...

  • Page 44: Video Lines

    C h a p t e r 4 U si n g D a s h B oa r d C o n fi g u r in g t h e C h a n n el Figure 4–5 Channel A (Bottom) You'll notice that the submenu is divided into sections, each with a heading that describes the features below.

  • Page 45: Video Output Control

    C h a p t e r 4 Using DashBoard C o n fi g u r in g t h e C h a n n el Table 4–1 Caption Lines Specification Register Default SD VANC Line for GPI Data HD VANC Line for GPI Data Video Output Control Video Outputs, CHA: Selects how captions are displayed on...

  • Page 46: Software Gpi Control

    C h a p t e r 4 U si n g D a s h B oa r d C o n fi g u r in g t h e C h a n n el Table 4–3 Caption Lines Specification Register...

  • Page 47: Vanc Gpi Rx Control

    C h a p t e r 4 Using DashBoard C o n fi g u r in g t h e C h a n n el VANC GPI Rx Control GPI Rx[0-3] Polarity, CHA: Selects how the polarity of received VANC cues will be interpreted, either Active High or Active Low.

  • Page 48: The Setup Tab

    C h a p t e r 4 U si n g D a s h B oa r d Th e S e t u p Ta b The Setup Tab tab allows you to set the Com port speed for both channels Setup and reload the factory default settings.

  • Page 49: Using The General Purpose Inputs/Outputs

    CHAPTER 5 Using the General Purpose Inputs/Outputs Introduction Overview This chapter describes the functionality of the GPI/O connectors on the adaptors. Topics Topics Page Introduction Functionality Connector Pin Assignments Connector Pin Assignments 8 21 06 5: H D CC- G PI N HL-O G 1 C on f ig u rat io n G u id e ©...

  • Page 50: Functionality

    C h a p t e r 5 U si n g t he Ge n e r a l Pu r p o s e I n p u t s / O u t p ut s F u n ct i o na l it y Functionality The GPI interface allows the user to encode contact closure triggers into a HD or SD video stream frame accurately.

  • Page 52: Gpis

    The GP outputs are optically isolated and “open collector” so the user must provide the appropriate pull-up resistor for each GP output. See Figure 5–3 below. The HDCC-GPINHL-OG1 provides two GPOs. (See Connector Pin Assignments on page 47 for connectivity.)

  • Page 53: Connector Pin Assignments

    C h a p t e r 5 Using the General Purpose Inputs/Outputs C o nn e c t o r P in A s si g n m e n t s Figure 5–3 Output Diagram User Supplied Load In Controlled Equipment GP Output Terminal...

  • Page 54: Gpi/O Polarities

    C h a p t e r 5 U si n g t he Ge n e r a l Pu r p o s e I n p u t s / O u t p ut s G PI / O P o la r it i e s Figure 5–4 RS-232/GPI/O RJ-45 Pin-Out 1 2 34 5 6 7 8...

  • Page 55: Gpi Encoded Polarity (Tx)

    Values 0=Disable 1=Enable The HDCC-GPINHL-OG1 can be configured to enable or disable transmission of GPI data by setting bit 7 of register 12h. 8 21 06 5 : HD C C- G PI N HL-O G 1 C o nf i g urat io n G u id e...
  • Page 56 C h a p t e r 5 U si n g t he Ge n e r a l Pu r p o s e I n p u t s / O u t p ut s G PI / O P o la r it i e s 8 21 06 5 : HD C C- G PI N HL-O G 1 C o nf i g urat io n G u id e ©...

  • Page 57: Terminal

    CHAPTER 6 Terminal Introduction Overview This chapter describes how to access the Terminal to change the HDCC card’s registers directly. Goals for This Chapter Explain the purpose and operation of the Terminal. Explain how to access the Terminal with any serial connection. Topics Topics Page...

  • Page 58: Background

    C h a p t e r 6 Te r m in a l B a ck g r ou n d Background The HDCC card’s operation is governed by several registers. These registers are modified automatically when you use the DashBoard. However, more advanced users may prefer to configure these registers manually.

  • Page 59: Accessing The Terminal Via The Rs-232 Port

    Note: If you’re using the Wohler MC-1RU frame, you can access the Terminal with the same serial port you use to connect to the HDCCRegEdit. (HDCCRegEdit is really a user interface that uses the Terminal.)

  • Page 60: Accessing The Terminal Via The Virtual Serial Ports

    C h a p t e r 6 Te r m in a l A c c es s i ng t h e T e rm in a l v ia t h e V ir t u a l S e ri a l Po r t s Figure 6–2 BOOTOPT Jumper Location BOOTOPT Jumper...

  • Page 61: Accessing The Terminal Via The Usb Port (Front Of Card)

    C ha p t e r 6 Terminal A c ce s s in g t h e T er m i n a l v ia t he U SB Po r t (F r on t of C a r d ) Verify the SW3 is set to Verify that Eth1 is installed per Chapter 2 of this document.

  • Page 62: Main Menu

    C h a p t e r 6 Te r m in a l M a i n M en u Open a terminal emulator (e.g., HyperTerminal, PuTTY, etc.) with USB serial port set to 115.2k, 8 data bits, 1 stop bit, no parity, and no handshaking.
  • Page 63 C ha p t e r 6 Terminal M a i n M e n u Figure 6–3 Main Menu Software and Firmware Part Numbers and Versions Engineering Menu Refer to Appendix A for a detailed list of registers. I m p or t a n t : Change Register Settings: Allows you to modify any available register value.
  • Page 64 C h a p t e r 6 Te r m in a l M a i n M en u Reset: Reboots the hardware. Note: If the jumper is not removed, the card will boot BOOTOPT back to the Main Menu. 8 21 06 5 : HD C C- G PI N HL-O G 1 C o nf i g urat io n G u id e ©...

  • Page 65: Appendix A. Register Set

    APPENDIX A Register Set Introduction Overview The registers can be modified directly using the terminal. Refer to Chapter Terminal on page I M PO R TA N T We highly recommend that Dashboard be used for configuration changes. The registers should be modified directly only when absolutely necessary.

  • Page 66: Accessing The Engineering Menu

    A p p e nd ix A R e g i s t e r S et A c c es s i ng t h e E n g in e e r in g M e n u Accessing the Engineering Menu To access the Engineering Menu, refer to the Hardware Installation Guide (part number 821150).
  • Page 67 A p p e n d ix A Register Set M od if y i ng t h e R e g is t er Se t t i n g s Table A–1 Register Table Summary Description Display Attributes—Reserved Not Used Not Used Not Used...
  • Page 68 A p p e nd ix A R e g i s t e r S et M o d i f y in g t h e R e g is t e r S e t t i ng s Table A–2 Register Settings, Descriptions, and Default Values Description...
  • Page 69 A p p e n d ix A Register Set M od if y i ng t h e R e g is t er Se t t i n g s Table A–2 Register Settings, Descriptions, and Default Values Description Default Audio GPI Settings...
  • Page 70 A p p e nd ix A R e g i s t e r S et M o d i f y in g t h e R e g is t e r S e t t i ng s Table A–2 Register Settings, Descriptions, and Default Values Description...
  • Page 71 A p p e n d ix A Register Set M od if y i ng t h e R e g is t er Se t t i n g s Table A–2 Register Settings, Descriptions, and Default Values Description Default Special Features—2...
  • Page 72 A p p e nd ix A R e g i s t e r S et M o d i f y in g t h e R e g is t e r S e t t i ng s Table A–2 Register Settings, Descriptions, and Default Values Description...
  • Page 73 A p p e n d ix A Register Set M od if y i ng t h e R e g is t er Se t t i n g s Table A–2 Register Settings, Descriptions, and Default Values Description Default Inbound Data Routing 2/2—to Registers...
  • Page 74 A p p e nd ix A R e g i s t e r S et M o d i f y in g t h e R e g is t e r S e t t i ng s Table A–2 Register Settings, Descriptions, and Default Values Description...

  • Page 75: Appendix B. Specifications

    APPENDIX B Specifications Introduction Overview This chapter lists the specifications of the HDCC and provides the pin- outs for its connectors. Topics Topics Page Introduction Specifications Technical Functional Overview 8 21 06 5: H D CC- G PI N HL-O G 1 C on f ig u rat io n G u id e ©...

  • Page 76: Specifications

    A p p e nd ix B S p e ci fi c a t io n s Sp e ci fi ca t io n s Specifications Table B–1 Physical Specifications Specification Card: 3” x 12.75”x 0.5” (76.2 mm x 323.85 mm x 12.7 mm) Dimensions (H x W x D) Rear Panel: 2.5”...
  • Page 77 A p p e n d i x B Specifications Te c h n ic a l F u nc t i on a l O v e rv ie w Figure B–1 HDCC Block Diagram 8 21 06 5 : HD C C- G PI N HL-O G 1 C o nf i g urat io n G u id e ©...
  • Page 78 A p p e nd ix B S p e ci fi c a t io n s Te c h ni c al F un c t io n a l O v er v ie w 8 21 06 5 : HD C C- G PI N HL-O G 1 C o nf i g urat io n G u id e ©...

  • Page 79: Appendix C. Troubleshooting

    APPENDIX C Troubleshooting Introduction Overview This appendix provides instructions for correcting the most common problems. Topics Topics Page Introduction DashBoard Network VSPs GPI Cue Insertion GPI Cue Reception 8 21 06 5: H D CC- G PI N HL-O G 1 C on f ig u rat io n G u id e ©...

  • Page 80: Dashboard

    A p p e nd ix C T r ou b le s ho o t i ng Da s h B o a r d DashBoard Table C–1 Common DashBoard Problems and Solutions Symptom Possible Cause Solution Frame not power up. Apply power to frame.

  • Page 81: Gpi Cue Insertion

    A p p e n d i x C Troubleshooting G P I C u e I n s e r t io n GPI Cue Insertion Table C–4 Common Cue Insertion Problems and Solutions Symptom Possible Cause Solution SD/HD VANC Line for HD/SD Video Line for cues to correct GPI Data, CHA...
  • Page 82 A p p e nd ix C T r ou b le s ho o t i ng G PI C u e R e ce p t io n Table C–5 Common Cue Reception Problems and Solutions Symptom Possible Cause Solution GPI Tx1-4 Polarity Output is opposite polarity.
