CONFIDENCE IS EVERYTHING.™
World Leader of In-Rack, Audio, Video, Data Monitoring, and Closed Captioning Solutions
HDCC-200A (OP-47/WST)
Multi-Function Card
Multi-Purpose Closed Caption Card:
Inserter, Decoder, Bridger, Monitor, and
Transcoder
Configuration Guide
Software Version: V2.34
PIC Code Version: V1.09
Part Number 821047, Revision A
