Genius Scanner – HR6X Slim
Physical
435 x 265 x 73 mm
dimensions
Weight 2.5 Kgs (5.51 Lbs)
Operating
10 C to 40 C (50 F to 104 F)
Temperature
Reflective: 8.5 x 11.69 in. (216 mm x 297 mm)
Max. Scan Area Transparency: Positive or negative films of 35 mm filmstrip, 3 pcs 35 mm
slides or 120/220 film (max. 6 x 9 cm)
Scan Method Single-Pass
48 bit Color
Scan Modes 8 bit Grayscale
1 bit Line-Art (Black & White)
Resolution Optical 600 dpi (19200 dpi software interpolated)
Scaning Reflective color or black-and-white originals, 35 mm slides,
Materials 35mm filmstrip, 120/220 film (max. 6 x 9 cm)
Protocols TWAIN Compliant
Connection USB Port
Lamp type Cold Cathode Lamp
Power adapter Power Output DC 24V, 550mA
Power Operation: 13.2 watts maximum
Consumption Idle: 6 watts
EMI FCC Class B
Genius Scanner
Genius Scanner – HR6X Slim
