    EK VIDEO INTERCOM INSTALLER MANUAL 1 - Product Description EK Video Door Entry is a non-polarized two-wire video door entry solution for community buildings. 1.2 General characteristics • Two wires not polarized system. • Stainless steel outer plate with high-quality color image camera with auto-detection system for lack of brightness.
  • Page 5: Elements Of The Ek Video Intercom

    PCD-E board and the DPL-4 /DPL-4F taps. 2.3 DPL-4 / DPL-4F Shunts DPL-4 / DPL-4F Shunts, they have 4 outputs for monitors / intercoms with the possibility of...
  • Page 6: Monitores Mon 43V / 43W E Interfonos Uad

    EK VIDEO INTERCOM INSTALLER MANUAL 2.4 Monitores MON 43V / 43W e Interfonos UAD MON43 monitor with high-quality 4.3" color display. UAD intercom for audio communication. Both references are hands-free and can be opened without the need for prior dialing. The MON 43 has the possibility of external viewing of the video intercom from the same panel of the monitor.
  • Page 7: Electrical Diagram

    EK VIDEO INTERCOM INSTALLER MANUAL 3 – Electrical diagram 3.1. Connection diagram with a DPL-4F shunt To make a connection to the DPL-4F shunt, make the connection as indicated in the schematic. For the same home you can make a cascade connection between monitors/intercoms (maximum 3 per home), it is recommended to configure it with the same identifier per home.
  • Page 8: Cascade Wiring Scheme With Dpl-4 And Dpl-4F Taps For Up To 64 Intercoms Per Installation

    EK VIDEO INTERCOM INSTALLER MANUAL 3.2. Cascade wiring scheme with DPL-4 and DPL-4F taps for up to 64 intercoms per installation If you want to make a connection with more than four intercoms, you must make a cascade connection between the DPL-4 modules by connecting them as indicated in the diagram, and use the DPL-4F reference as the final module.
  • Page 9: Downspout With A Total Of 24 Total Per Installation

    4.1 Master Card Access To access the configuration mode, it is necessary to have a Master card that is inside the PCD-E box previously configured. All you need to do is swipe it through the Mifare card reader and it will activate your access.
  • Page 10: Plate Bridge Access

    IMPORTANT!! Only one unsubscribe card can be registered. Once you register a leave card, if you re-register another card, the old card will be automatically deleted. If you have two PCD-E outer boards, you must do the same process independently.
  • Page 11: Adding Access Cards

    4.5.1 Adding Access Cards Using Monitor ID If you want to add access cards using monitor identification, go to the Outer Plate (PCD-E) settings and select "Add Card". Next, type the ID of the monitor you want to associate the card with and press OK.
  • Page 12: Exporting The Data To An Sd Card

    4.9 Exporting the data to an SD card If you want to make a copy of the existing PCD-E configuration to an SD card, you first need to disconnect the voltage from the PCD-E board, insert the SD card, and power the device again.
  • Page 13: Connecting The Door Opener

    No bridge: Tension-free connection (dry contact). 5.1 Connecting the door opener by DC 12v For connection to 12v c/c, a direct output is available in the PCD-E board connection at the NO/GND outlets for open contact and NC/GND for closed contact.
  • Page 14: Connecting The Door Opener For Relay Output (Dry Contact)

    EK VIDEO INTERCOM INSTALLER MANUAL 5.2 Connecting the Door Opener for Relay Output (Dry Contact) If you want to have a voltage-free contact, you have a configuration for it. Connect the wires to the NO/COM outlet for open contact or NC/COM for closed contact. To make this connection, remove the jumper.
  • Page 15: Monitor Mon 43V

    Then press the "call button" once, it will activate the display of the outer board, if you press again a long press, it will switch to the next outer board (PCD-E) and/or the camera in your installation. First of all, you need to set up the outer plates and additional cameras.
  • Page 16: Configure Outer Plate Camera And Additional Cameras

    EK VIDEO INTERCOM INSTALLER MANUAL 6.1.4 Configure Outer Plate Camera and Additional Cameras. Press and hold the "call and open" buttons until you hear a long beep. Start setting the status of the multi-door station and additional camera. Tap as many times as the amount of code specific to the status of the door.
  • Page 17: Mon 43V Monitor Connection

    EK VIDEO INTERCOM INSTALLER MANUAL 6.2 MON 43V Monitor Connection 7 – UAD Intercom Door Opening Function: When the visitor calls from the outside plaque, the UAD will sound. Press the call button to talk to the visitor, then to open the door press the open button. ITS Partner O.B.S S.L ·...
  • Page 18: Uad Intercom Configuration

    EK VIDEO INTERCOM INSTALLER MANUAL Doorbell call button (optional): An additional doorbell call button can be connected to the UAD, so that visitors can ring the doorbell again in front of the user's apartment. When the button is pressed, the UAD intercom will emit the ringtone.
  • Page 19: Table Of Identification Codes

    9 – Identify intercoms (MON 43V and UAD) on outer board To identify the monitors to your installation you must add them to the PCD-E board, go to settings and select "Add Monitor". Once inside it will ask you to insert the keypad code that you want to give to the monitor you want to add, Once you add the code it will then ask you for the number of the monitor code that you have previously configured.
  • Page 20: Editing Files Exported To Sd Card

    Once the values are inserted, confirm again and a saved data message will appear. 10 - Editing Files Exported to SD Card 10.1 - Config_Table.csv The information you'll find in the Config_Table.csv file will show you the PCD-E board configuration. Parameter Default Notes...
  • Page 21: Uid_Table.csv

    EK VIDEO INTERCOM INSTALLER MANUAL Monitor Code Numerical Monitor ID Number 1-32 Example table: Name Floor Calling Code Monitor Code Miguel Garcia Pedro M.F. IMPORTANT!! When modifying the Floor_Table.csv file, the modified text must be separated by "commas". If the characters in the "Name" or "Floor" section are exceeded the character limit, these characters will be deleted and therefore will not appear on the screen.
  • Page 22: Wiring Cross-Section And Distances

    To activate the passcode to unlock the door opener using a passcode, it must first be activated. Access the PCD-E board settings, go to the "Configuration Options" and "Door Opener Code" section, and select YES. You will then be asked for the access code for the door opener, the code must be at least 4 digits long, and a maximum of 9 digits.
