Summary of Contents for Norcool 60000007
- Page 1 English OPERATING & INSTALLATION INSTRUCTIONS WINE DRAWER...
- Page 2 Please visit www.norcool.no for operating & installation instructions in other languages.
-
Page 3: Table Of Contents
Content Handling of waste ..................4 Safety rules and warnings................5 Product information ..................8 4. Measures for energy conservation ............9 Important information ................10 6. Dimensions and technical specifications ..........11 Back legs adjustments ................12 Pre-installation ....................13 9. -
Page 4: Handling Of Waste
1. Handling of waste Waste management of the packaging: The packaging protects the product against damage during transport. All packaging may be recycled and is labelled for recycling. Make sure that all packaging is discarded in a safe manner and is stored out of reach of children since irresponsible use may be dangerous. -
Page 5: Safety Rules And Warnings
2. Safety rules and warnings THE MANUFACTURER OF THE PRODUCT CANNOT BE HELD RESPONSIBLE FOR DAMAGE THAT IS DUE TO THESE SAFETY RULES AND WARNINGS NOT BEING FOLLOWED. 1. Read the use and installation instructions carefully before you start using the product. - Page 6 checked regularly. In the event of any doubts, the wiring network in the house must be checked by a qualified electrician. The manufacturer cannot be held responsible for product damage or personal injuries that are due to a deficient or insufficient grounding system, such as electrical shocks for example. 9.
- Page 7 This appliance is intended to be used in household and similar applications such • Staff kitchen areas in shops, offices and other working environments. • Farm houses and by clients in hotels, motels and other residential type environments. • Bed and breakfast type environments. •...
-
Page 8: Product Information
3. Product information Wine Drawer is a wine serving drawer, with two external and three internal drawers. The module has a capacity of approx. 46 bottles and is usually sold for private use. The drawer has a smoked glass front and LED lighting. This protects the wine against harmful UV rays which can reduce its shelf life. -
Page 9: Measures For Energy Conservation
4. Measures for energy conservation Measures for energy conservation The most important energy conservation measure is that the Wine Drawer door must not be left open, this will cause increased running time and increased energy consumption. Having good order and organization in your Wine Drawer will save you much searching and time, and you will reduce the running time and energy consumption. -
Page 10: Important Information
5. Important information To ensure proper installation and use and thereby prolong the lifetime of the product, you must study this installation and user manual carefully prior to installation. Repairs must only be made by qualified personnel. The manufacturer will not assume liability for any damage resulting from non-compliance with the following instructions. -
Page 11: Dimensions And Technical Specifications
6. Dimensions and technical specifications A 795mm B 700mm C 565mm D Min 820 – Max 870mm E Min 120mm – Max 170mm F 340mm G 788mm Exterior dimensions W795 x H820 - 870 x D565 mm Climate class Ambient/room temperature Niche dimensions W800 x H825 (min) x D570 mm... -
Page 12: Back Legs Adjustments
7. Back legs adjustment Insert the slot type screwdriver into the hinge (red arrow indicated), rotate the screwdriver to adjust the height of the Wine Drawer, after adjust the height of back leg, raise up the Wine Drawer and adjust the height of front leg. -
Page 13: Pre-Installation
8. Pre-installation Check for transport damage after unpacking. Do not use a damaged product. In the event of damage, please contact the shipping company and make sure that the damage is noted on the consignment note. Check that you have all the parts on the parts list at the back of this guide. -
Page 14: Installation
9. Installation Requires a space of W 800 x H 825 (min) – 870 (max) x D 570 mm Adjust the back levelling legs so that the back edge of the Wine Drawer just clears the underside of the worktop. Fig 1. Extract retaining brackets Fig. 2. Carefully slide the product into position and adjust the front legs so that the front edge squeezes firmly against the underside of the worktop. -
Page 15: Fitting/Removing Drawers
10. Fitting/removing drawers 10.1 Removing front/drawer Tip up the cover and pull Turn screw driver to release Lift the release handle and out. the drawer front. pull out the drawer. 10.2 Side adjustment Left & right adjustment. Up & down adjustment. Slide into the cabinet. -
Page 16: Use And Maintenance
Place the towel in water tray when defrosting to avoid water overflow. 11.4 Noises Norcool Wine Drawer is quiet, but some noise can be expected. • Humming from the compressor. Can increase when the motor starts up. -
Page 17: Display Panel
• Gurgling can occur from coolant in the pipes • Humming from the circulation fans 11.5 Display panel Light/ Turn up Mute ON/OFF Turn down 1. Temperature Setting • The range is 4-22˚C. Default is 12˚C. • Short press “up” and “down” to set. Support long press to continuous adjustment. -
Page 18: Troubleshooting And Service
Defrost probe error Order service on our website For service, visit our web site at www.norcool.com. By having checked these points before summoning help, you will help the service technician with the parts that might need to be brought along and the specific measures that may need to... -
Page 19: Delivery Terms And Conditions
12.1 Consumer purchases These terms and conditions govern customer rights with respect to the supplier (Norcool) when purchasing new Norcool products that will be used in a normal manner in private housekeeping. Such as is determined in the following points, the supplier is obligated to remedy defects/omissions that arise. - Page 20 the supplier/ dealer and customer by road of max. 20 km. If the distance is more than 20 km, and the dealer is the entity located closest to the customer, then the supplier will pay the travel costs regardless. If this would bring about unreasonable costs or drawbacks, then the obligation to undertake the remediation as mentioned above at no cost to the customer does not apply! Normally, this instance would be if the customer is unable to be reached by...
-
Page 21: Business Purchases
c) Repairs or interventions performed by unauthorised persons, or use of nonoriginal parts. d) Accidents or other circumstances after delivery to the customer that lie outside the control of the supplier/dealer, including voltage fluctuations beyond +/- 10 % of the rated voltage, lightning strikes, and electrical power outages. -
Page 22: Package List
13. Package list Figure Description Ref. no Qty. Wine drawer for integration Plate screw 4.2 x 16 8900013865 Air grid black 8900013866... - Page 24 Scandinavian Appliances AS Postboks 61 NO-1740 Borgenhaugen Norway T: +47 815 69 117 post@norcool.no www.norcool.no Please visit our website for operating & installation instructions in other languages. Version 1.1 - May 2024...
