Homelegance 1313NK-1CK Manual

Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts which
may have come loose inside the carton during shipment. Identify and count all parts and compare with the Parts
List below.
For items use on wooden floor, hard surfaces or carpets , it is recommended to Install protective pads under
all legs and supports to avoid/ prevent from damages/ scratches and discoloration.
Pour les articles Utilisés sur un plancher en bois, des surfaces dures ou tapis , il estrecommandé dinstaller
des mordaches de protection sous tous les jambes et prend en charge pour évitêr/empecher de
dommages/rayures et la décoloratio
HARDWARE LIST OF FOOTBOARD
HARDWARE PACK IS IN-1313NK-2CK
DRESCRIPTION
NO DRAWING
1 #8*1" Screw
HARDWARE LIST OF BED RAIL
HARDWARE PACK IS IN-1313NK-3CK
NO DRAWING
2 Ø 5/16"-18*3-1/2" Hanger Bolt
Ø 50 Arc Washer
3
Ø 5/16"*16*2mm Flat Washer
4
Ø 5/16" Lock Washer
5
6
Ø 5/16"*L17 Nut
7
Ø 5/16" Open Wrench
1 of 3
ITEM:
n.
DRESCRIPTION
1313NK-1CK CK Uph Headboard
1313NK-2CK CK Storage Footboard & Slats
1313NK-3CK 6/0 Side Rail
Q'TY
A HEADBOARD
22Pcs
B
FOOTBOARD DRAWER
C SIDE RAIL
D
SLAT (11PCS)
E
SLAT SUPPORT LEG SHORT(32*32*314mm)
Q'TY
8Pcs
8Pcs
8Pcs
8Pcs
8Pcs
1Pc
COMPONENT LIST
1PC
1PC
2PCS
1SET
10PCS
