TWO-SIDED CART USER'S MANUAL
Part No. JDI-MBS1-EV
FOR WARRANTY INFORMATION, PLEASE CALL 800-433-0708
DATE OF PURCHASE:
READ AND SAVE THIS MANUAL
FOR SERVICE ASSISTANCE, CALL 800-433-0708 OR VISIT JOHNDOW.COM
Rev 03/2024
151 Snyder Ave.
EVCART-MAN
Barberton, OH 44203
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for JohnDow Industries JDI-MBS1-EV
Summary of Contents for JohnDow Industries JDI-MBS1-EV
- Page 1 ™ TWO-SIDED CART USER’S MANUAL Part No. JDI-MBS1-EV FOR WARRANTY INFORMATION, PLEASE CALL 800-433-0708 DATE OF PURCHASE: READ AND SAVE THIS MANUAL FOR SERVICE ASSISTANCE, CALL 800-433-0708 OR VISIT JOHNDOW.COM Rev 03/2024 151 Snyder Ave. EVCART-MAN Barberton, OH 44203...
- Page 2 GETTING STARTED If there are any parts are missing or damaged per the contents list below, please contact us. CONTENTS Ref. Part Name Qty. Ref. Part Name Qty. T-Frame M6 x 10 Pan Head Screw, Flat Washers Stem Caster Upper Channel Stem Caster, Locking Top Header M10 Nut, Lock Washer, Flat...
- Page 3 ASSEMBLY INSTRUCTIONS 1. Assemble stem casters to lower T-frames using (4) M10 nut, lock washer, and flat washers (Figure 1). Figure 1 2. Assemble base covers to the lower T-frames using (16) M6 x 42 pan head cap screws, washers, and nylon insert nuts. Do not tighten until the next step (Figure 2).
- Page 4 5. Insert upper frames tubes. Tap on end to make sure it fits tightly. Secure the upper and lower frame joint using (4) M6 x 10 pan head screws (Figure 5). Figure 5 6. Place top header between frame sides and fasten using (4) M6 x 42 pan head screws, and washers.
