engelmann C1 Installation Manual

Wireless smoke detector

Advertisement

Available languages

Available languages

Quick Links

TG56xA / 910180000x
Montageanleitung
e
Funk-Rauchwarnmelder,
10 Jahre Batterie-Lebensdauer
OMS
OPEN METERING SYSTEM
Installation guide
z
Wireless smoke detector,
Battery life: 10 years
OMS
OPEN METERING SYSTEM
- S. 2
- p. 9
6LE004298E

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C1 and is the answer not in the manual?

Questions and answers

Summary of Contents for engelmann C1

  • Page 1 TG56xA / 910180000x Montageanleitung - S. 2 Funk-Rauchwarnmelder, 10 Jahre Batterie-Lebensdauer OPEN METERING SYSTEM Installation guide - p. 9 Wireless smoke detector, Battery life: 10 years OPEN METERING SYSTEM 6LE004298E...
  • Page 2: Table Of Contents

    Inhaltsverzeichnis 1. Einführung ............................................2 1.1. Funktionsprinzip ........................................2 1.2. Funktionen und Vorteile ......................................2 1.3. Funktion zur Umfeldüberwachung ................................... 2 1.4. Geräteaufbau ..........................................3 2. Installation ............................................3 2.1. Wahl des Montageortes ......................................3 2.2. Montage des Melders - Erstinbetriebnahme ................................4 2.3.
  • Page 3: Geräteaufbau

    1.4. Geräteaufbau Befestigungsplatte 10 J. Bat. TypCOMS C1/ T1 A r t . N r : SN120AD Rauchwarnmelder, 10 J. Bat. TypCOMS C1 Serial Number: 95299999 A r t . N r : SN120AD Encryption Key: 12345678901234567890123456789012 Serial Number:...
  • Page 4: Montage Des Melders - Erstinbetriebnahme

    • am höchsten Punkt von (A-förmigen) Spitzbogendecken, da ein Luftsack an dieser Stelle verhindern könnte, dass der Rauch an den Melder gelangt (Abb. C), • direkt auf einer Metallwand: In diesem Fall eine Unterlage aus nicht magnetischem Material (Holz oder Kunststoff) einlegen. d >...
  • Page 5: Inbetriebnahmetest

    Sie haben 10 Sekunden Zeit, um sich vom Melder zu entfernen (mindestens 50 cm), damit der Funktionstest (max. 90 Sek.) nicht beeinträchtigt wird. >50 cm 2.3. Inbetriebnahmetest Nach Abschluss des Tests, Die Inbetriebnahme ist erfolgreich verlaufen: Tonsignal 4 x 2 schnelle akustische Tonfolgen mit Unterbrechung Zwei Arten von Störungen werden unterschieden: •...
  • Page 6: Funktionstest

    3. Funktionstest • Der Rauchwarnmelder muss auf dem Montagesockel montiert sein, um den Test durchführen zu können. • Vor dem Test eines Rauchwarnmelders wird empfohlen, die Nachbarn zu informieren und entsprechende Vorsichtsmaßnahmen zu ergreifen, um die Gefahr von Hörschäden auszuschließen. •...
  • Page 7: Demontage Und Austausch

    Störungen werden je nach Höhe des Risikos unterschiedlich signalisiert: Eine gravierende Störung wird wie folgt signalisiert: Signalton 3 kurze Signaltöne alle 5 Min. Visuelle Meldung 1 Blinksignal alle 5 Sek. Eine geringfügige Störung wird wie folgt signalisiert: Signalton Keine Signalisierung Visuelle Meldung 2 Blinksignale alle 30 Sek.
  • Page 8: Technische Daten

    6. Technische Daten • OMS Security Profile B, AES128 CBC + CMAC encryptions (ENC-Mode 7) • Funkverbindung: 868 MHz - 870 MHz, max. 25 mW, Duty Cycle: 0,1% - Sendeintervall: alle 2 Minuten • Meldertyp: optischer Rauchwarnmelder • Durchschnittlich abgedeckte Fläche: 50 m •...
  • Page 9: Introduction

    Contents 1. Introduction ............................................. 9 1.1. Overview ............................................ 9 1.2. Features and benefits ....................................... 9 1.3. Obstacle detection and adapting to surroundings ..............................9 1.4. Device components ........................................ 10 2. Installation ............................................. 10 2.1. Choosing a location ........................................ 10 2.2. Installing the smoke detector ....................................11 2.3.
  • Page 10: Device Components

    1.4. Device components Mounting plate TypCOMS C1/ T1 10 J. Bat. A r t . N r : SN120AD Rauchwarnmelder, 10 J. Bat. TypCOMS C1 Serial Number: 95299999 A r t . N r : SN120AD Encryption Key: Serial Number:...
  • Page 11: Installing The Smoke Detector

    d > 50 cm d > 50 cm Minimum protection: One smoke detector in the hall or stairwell on each story and in each bedroom. Optimum protection: Recommended Minimum protection plus location smoke detectors installed in each living room or in the Acceptable basement.
  • Page 12: Testing For Correct Installation

    You have 10 seconds to move away from the detector (at least 50 cm) to avoid interfering with the function test (max 90 sec.). >50 cm 2.3. Testing for correct installation After the test is complete, initial installation was successful: Audio signal 2 bips each second repeated 4 times Two different types of errors may occur: •...
  • Page 13: Testing The Alarm Function

    3. Testing the alarm function • The detector must be mounted on the mounting plate to conduct tests. • Before testing the smoke detector, it is recommended that you inform the neighbours and take appropriate safety measures to avoid the risk of hearing damage.
  • Page 14: Disassembly And Replacement

    5. Disassembly and replacement 5.1. Renovation work The smoke detector must not be covered, wrapped, soiled, painted or exposed to high levels of dust! The smoke detector may be removed from its installed location for no more than 14 days; after this time, the red LED signal will flash twice every 30 seconds to indicate an installation error.
  • Page 15: Technical Specifications

    6. Technical specifications • OMS Security Profile B, AES128 CBC + CMAC encryptions (ENC-Mode 7) • Radio connection: 868 MHz - 870 MHz, max. 25 mW, Duty Cycle: 0.1 % - transmission interval: every 2 minutes • Detection type: optical smoke detector •...
  • Page 16 Hager SAS 132 Boulevard d’Europe BP 78 F-67212 OBERNAI CEDEX Tél. +333 88 49 50 50 www.hager.com Hager 2023-10 6LE004298E...
